Поз.
Артикул
Описание
5
CROSS STRUT REAR CROSS MEMBER
6
BRACKET TRAILER PLUG SOCKET
7
SCREW OIL LINE TO CRANKCASE
8
NUT SPRING-LOADED PUSH ROD
20
PLATE 0
35
HEXAGON HEAD BOLT. SCREW RUBBER BUFFER TO SUPPORT M 12X90
40
NUT BRACKET TO SIDE MEMBER M12X1.5
70
TRAILER COUPLING
85
CAP BOLT. SCREW BELT TIGHTENER TO SUPPORT M10X50,*0211352
85
SCREW ROLLER ON SUPPORT
90
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
100
SCREW PIPE ELBOW TO CHARGING AIR INTERCOOLER M 10X35,5 708090
110
ALTERNATING PLATE VARIO BLOCK
115
PLATE WITH COVERING CAP 3,25T
120
SCREW BASE PLATE TO TRAILER COUPLING
130
COUPLING MOUTH (MOUTH-TYPE COUPLING)
135
COUPLING PINROCKINGER TYP 243 U115 EO/EK
140
COVERROCKINGER TYP 243 U115 EA/EL
145
LEVER
150
HANDLE
155
SPRINGROCKINGER TYP 243 U115 EO/EK
160
GREASE NIPPLE PROTECTIVE TUBE
165
LOCK
170
COTTER PIN CYLINDER TO BRACKET
175
WASHER PUMP TO CONSOLE
175
WASHER EXHAUST MUFFLER TO STRAP
180
STUD BOLT TRAILER COUPLING TO REAR CROSS MEMBER M10X40
185
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
