Поз.
Артикул
Описание
2
STEERING BOX ASSEMBLY , FOR BREAK-DOWN,SEE UNIT MICROFICHE,MODEL: 762.002 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
2
STEERING BOX ASSEMBLY , Replaced By: A3084600001
2
STEERING BOX ASSEMBLY , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3094601501
2
STEERING BOX ASSEMBLY , FOR L.H.D. UP TO CHASSIS 422483 FROM CHASSIS SEE SPARE PARTS LIST 814
2
STEERING BOX ASSEMBLY , Replaced By: A3444601201
2
STEERING BOX ASSEMBLY , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A3274606501
8
STEERING BOX WITH BEARING BUSHING
8
STEERING BOX
10
BUSHING REPAIR SIZE I 47.6 MM
10
BUSHING47.1 MM
12
SEAL RING
12
SEAL RING
15
SCREW PLUG
15
PLUG , Replaced By: N000906016000
18
STEERING NUT
18
STEERING NUT , Replaced By: A4064600218
18
STEERING WORM , Replaced By: A3274600018
20
SEAL RING , 032,033,040,041: UP TO CAB 1600091 132,133,140,141: UP TO CAB 1600091
22
BARREL-TYPE BEARING
22
BARREL-TYPE BEARING STEERING WORM, FOR L.H.D. UP TO CHASSIS 422483 FROM CHASSIS SEE SPARE PARTS LIST 814
22
BARREL-TYPE BEARING , Replaced By: A3459817006
24
STEERG. WORM SECTOR SHAFT
26
BALL CUP
28
SNAP RING STEERING SHAFT BEARING IN COVER, FOR L.H.D. UP TO CHASSIS 422483 FROM CHASSIS SEE SPARE PARTS LIST 814
30
SEAL RING
32
OIL LEVEL CHECK PIPE
34
SEAL RING OIL FILLING AND OIL DRAIN
36
SCREW PLUG OIL FILLING
36
SCREW PLUG STEERING BOX
38
STEERING BOX COVER STEERING BOX
38
STEERING BOX COVER ,297463, Replaced By: A3214600514, +001A0029900251
38
STEERING BOX COVER
38
STEERING BOX COVER , Replaced By: A3214600414, +001A0029900251
40
BUSHING STEERING SHAFT BEARING IN COVER, FOR L.H.D. UP TO CHASSIS 422483 FROM CHASSIS SEE SPARE PARTS LIST 814
42
GASKET
42
GASKET , Replaced By: A3524610180
44
SCREW , Replaced By: N000931008049
46
SCREW
48
SPRING
50
THRUST PIECE
52
THRUST WASHER
54
LOCK
58
NUT
60
RING
62
SEAL RING
64
SEAL RING
66
GROOVED NUT
66
NUT , Replaced By: A6743560226
68
LOCK
70
NUT
75
PITMAN ARM
75
PITMAN ARM
77
SCREW STEERING TO STEERING BRACKET
79
SCREW STEERING TO STEERING BRACKET
81
NUT STEERING TO STEERING BRACKET TO 327 990 01 14,322 990 09 14
999
STEERING WHEEL ,5 057904 NO.8316INO.7C52INO.7B90INO.9051I II I
999
NEEDLE , 005,006,007,011,012,021,031,106,108 UP TO CHASSIS A 011990
999
SEAL RING
999
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
999
BEARING BUSHING , 005,006,007,011,012,021,031,106,108 UP TO CHASSIS A 011990
999
BEARING BUSHING O.D., 28.024 BIS 28.036 MM
999
UNIVERSAL JOINT CROSS , UP TO IDENT NO. 622785 EXCEPT FOR 500001-599999
999
SEAL HOLDER , UP TO IDENT NO. 622785 EXCEPT FOR 500001-599999
999
RUBBER RING , UP TO IDENT NO. 622785 EXCEPT FOR 500001-599999
999
SNAP RING1.50 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
999
SNAP RING1.55 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
999
SNAP RING1.60 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
999
SNAP RING1.65 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
999
SNAP RING1.70 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
999
SNAP RING1.75 MM, 032,033,040,041: UP TO CHASSIS 039639 132,133,140,141: UP TO CHASSIS 000510
999
STEERING WORM , Replaced By: A3094601018
999
STEERING NUT WITH WORM AND INCLINED SELF-ALIGNING ROLLER BEARING
999
NUT ,297463
999
NEEDLE SET192 PIECES, UP TO IDENT NO. 622785 EXCEPT FOR 500001-599999
999
STEERING WORM , Replaced By: A3094600708, +001N007603030400, +001N007604030100
999
WASHER UNIVERSAL JOINT COVERING
999
BOOT UNIVERSAL JOINT COVERING
999
COTTER PIN SHIFT LEVER TO CASE
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN
999
LOCK PLATE
999
NUT , Replaced By: N308673012002
999
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
999
RIVET REAR CROSS MEMBER 12X42 MM
