Поз.
Артикул
Описание
10
POWER STEERING PUMP
10
HYDRAULIC PUMP
20
SCREW BRACKET TO SIDE MEMBER M8X20
20
SCREW. HEXALOBULAR BOLT MOUNTING FRAME TO SUPPORT M 8X30
50
OIL TANK POWER STEERING PUMP
50
OIL TANK , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004602883
60
HEXALOBULAR BOLT. SCREW STAY TO CYLINDER HEAD M 6X23
70
HOSE DELIVERY LINE TO POWER CYLINDER
80
CLAMP POWER STEERING PUMP TO OIL TANK, FROM MODEL YEAR 2000CODE 800
100
POWER STEERING PUMP
100
POWER STEERING PUMP
110
HOUSING COVER WITH INNER BAYONET
110
FILLER CAP WITH OUTER BAYONET TO A 0024667501, 7601, Replaced By: A0014662705
120
PULLEY POWER STEERING PUMP
130
HEXAGON HEAD BOLT CONTROL ARM, LINKAGE ADJUSTER ON BEARING BRACKET M8X12
140
SCREW 3/2-WAY VALVE TO BRACKET
200
POWER STEERING PUMP
200
POWER STEERING PUMP , D803354820130719
200
HYDRAULIC PUMP , Replaced By: A0064667801
205
FILLER CAP WITH OUTER BAYONET TO A 0024667501, 7601, Replaced By: A0014662705
205
HOUSING COVER WITH INNER BAYONET
210
SCREW. HEXALOBULAR BOLT MOUNTING FRAME TO SUPPORT M 8X30
230
LINE HOLDER TO PUMP
300
HYDRAULIC PUMP
310
SCREW 3/2-WAY VALVE TO BRACKET
330
OIL TANK
340
HOSE FROM OIL TANK TO STEERING PUMP
350
CLAMP POWER STEERING PUMP TO OIL TANK, FROM MODEL YEAR 2000CODE 800
360
BRACKET OIL TANK
370
TAPPING SCREW. SHEET METAL SCREW BRACKET TO CAB
380
LOCK NUT CENTER REINFORCEMENT TO HOUSING CENTER CONSOLE 4.8/0.5-2.5 MM
390
HEXALOBULAR BOLT BRACKET ON TUBULAR SUPPORTING FRAMEWORK M6X12
390
HEXALOBULAR BOLT. SCREW
400
POWER STEERING PUMP
400
POWER STEERING PUMP
410
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
410
HEXALOBULAR BOLTM8X34
410
HEXALOBULAR BOLT PUMP TO TIMING CASE M8X44, THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: N000000001141
430
OIL TANK POWER STEERING PUMP
440
RETAINING DISK TO OIL RESERVOIR FEED FITTING
