Поз.
Артикул
Описание
50
VALVE PARKING BRAKE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
50
VALVE RELAY VALVE KNORR
50
VALVE (RELAY VALVE) GRAU
52
VALVE SEATGRAU
54
SEAL RING22.3X2.4 MM,GRAU
54
SEAL RINGTO 000 429 28 95,GRAU
54
SEAL RING28X2 MM,GRAU
54
SEAL RING86X2 MM,GRAU
55
WASHER BRACKET TO LEFT SIDE MEMBER
55
WASHER , Replaced By: A3609902340
56
GASKET34X2X6 MM,GRAU
57
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
58
REPAIR KITKNORR
58
REPAIR KITWABCO
59
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
60
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
60
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
61
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
62
SEAL RING LINE CONNECTION
63
UNION NUT BUTT SCREW CONNECTION
64
SCREW PLUG , Replaced By: N000908022011
64
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
65
GLAND LINE CONNECTION
66
T-FITTING INSIDE AND OUTSIDE AIR RESERVOIRS, FRONT CONNECTION
67
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
68
O-RING CHECK VALVE TO AIR RESERVOIR
69
THRUST RING BUTT SCREW CONNECTION
70
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
70
THRUST RING CHECK VALVE TO AIR RESERVOIR
71
SEAL RING , Replaced By: N007603012121
71
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
72
NUT CHECK VALVE TO AIR RESERVOIR
73
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
73
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
74
WASHER , Replaced By: N000125008443
74
WASHER EXHAUST MUFFLER TO STRAP
76
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
77
SCREW , Replaced By: N304017006016
77
SCREW PUMP TO BRACKET
78
NUT
79
NUT , Replaced By: N913004006001
79
NUT PUMP TO BRACKET
80
BRACKET RELAY VALVE
81
SCREW , Replaced By: N304017008021
81
SCREW PIPE CLAMP
82
SCREW BRACKET TO SIDE MEMBER
83
NUT , Replaced By: N913004008001
83
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
83
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
84
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
85
CLAMP DELIVERY AND SUCTION LINES TO STEERING
86
NUT BRACKET TO SUPPORT AND TO END PIECE
87
SCREW , Replaced By: N304017006016
87
SCREW PUMP TO BRACKET
87
SCREW , Replaced By: N304017006020
87
SCREW LICENSE PLATE TO BRACKET
89
NUT , Replaced By: N913004006001
89
NUT PUMP TO BRACKET
107
GASKET34X2X6 MM,GRAU
110
REPAIR KITTO 001 431 37 05,4 375193
110
REPAIR KIT VALVE KIT TO 001 431 37 05,4 375193
110
REPAIR KIT , Replaced By: A0024306581
110
REPAIR KITTO 001 431 37 05,4 375193
110
REPAIR KIT VALVE KIT TO 001 431 37 05,4 375193
111
SEAL RING7X1.5,TO GRAU
111
SEAL RING21.3X2.4 TO 001 431 74 05,
113
SEAL RING18X2.5,TO GRAU
115
VALVE SEATTO GRAU
117
SEAL RING39.2X3 TO 001 431 74 05,
117
SEAL RING64.77X2.62,TO GRAU
118
T-FITTING SHIFT VALVE,CONNECTION: "11", 415 5 014668 416 5 000515 417 4 972023
118
T-FITTING SHIFT VALVE,CONNECTION: "11", 415 5 014668 416 5 000515 417 4 972023
119
SEAL RING90X3,TO GRAU
121
SEAL RING44.2X3,TO GRAU
123
SEAL RING100X3,TO GRAU
125
BRAKE VALVE SEAL RING TO 001 431 18 05,4 412020
127
T-FITTING CHECK VALVE TO RELAY VALVE
129
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
131
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
133
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
135
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
139
SCREW REINFORCEMENT TO ROCKER PANEL
141
NUT , Replaced By: N910113010000
141
NUT STRAP TO BRACKET
145
SEAL RING30X2 MM,BOSCH
147
COVERTO 000 429 38 30
149
SEAL RING"GRAU"
151
COVER SUPPLY, RED "WABCO"
153
REPAIR KITTO 000 429 37 30
153
REPAIR KITTO 000 429 63 30
153
REPAIR KITTO 000 429 78 30,4 434236
159
BRACKET BRAKE LINE COUPLING,"SUPPLY"
161
NUT CHECK VALVE TO AIR RESERVOIR
163
SCREW , Replaced By: N304017008034
165
NUT , Replaced By: N913004008001
165
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
167
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
173
BRAKE LINE COUPLING BRAKE,YELLOW GRAU
173
BRAKE LINE COUPLING BRAKE,YELLOW BOSCH
173
BRAKE LINE COUPLING BRAKE,YELLOW WESTINGHOUSE
173
BRAKE LINE COUPLING BRAKE,YELLOW KNORR
175
COVERTO 000 429 38 30
175
COVER"WABCO", NOT USED
177
SEAL RINGTO 000 429 38 30
178
BRACKET FUEL LINES TO TRANSMISSION
179
SEAL RING , Replaced By: A0004296930
179
BRAKE LINE COUPLINGTO 000 429 38 30
180
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
181
SEAL RING"WABCO"
181
SEAL RING"WABCO"
182
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
183
REPAIR KIT"KNORR"
185
BRACKET (REAR CROSS MEMBER)
187
NUT CHECK VALVE TO AIR RESERVOIR
189
SCREW , Replaced By: N304017008034
191
NUT , Replaced By: N913004008001
191
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
193
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
193
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
195
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
197
FITTING BRAKE LINE COUPLING TO BRACKET
199
NUT BRACKET TO SIDE MEMBER
999
FITTING ,4 667210
999
FITTING , Replaced By: A0029971372
999
FITTING , Replaced By: A0029971172
999
T-FITTING COMPRESSED AIR VALVE CONNECTION
999
WASHER HYDRAULIC HOSE TO BRACKET
999
T-FITTING ,5 936365, Replaced By: A0029902570
999
BRACKET COMPRESSED AIR LINE TO VALVE
999
BRACKET , Replaced By: A3854290840
999
CLAMP , Replaced By: A6739950001
999
BRACKET , Replaced By: A3853530440
999
BRACKET , Replaced By: A3604292940
999
BRACKET COMPRESSED AIR LINES TO FRAME
999
BRACKET , Replaced By: A3604292940
999
BRACKET COVERING
999
BRACKET , Replaced By: A3604292940
999
BRACKET LINE MOUNTING
999
FITTING , Replaced By: A0029906171
999
FITTING , Replaced By: A0029905971
999
SEAL RING
999
LOOM TIE , Replaced By: A0019978490
999
LOOM TIE , Replaced By: A0019978390
999
REPAIR KIT , Replaced By: A0004304606
999
VALVE , Replaced By: A0034295244
999
T-FITTING , Replaced By: A0019901070
999
BRAKE LINE COUPLING , Replaced By: A0004297930
999
SEAL RING , Replaced By: A0004292184
999
LINE , Replaced By: A0005516256
