Mercedes A0009845429 -

SPRINTER 410 D,412 D 904.413

88 ATTACHMENT PARTS - 300 FENDERS,SPLASH GUARDS

Поз.
Артикул
Описание
5
A9018820105
SPLASH GUARD FRONT LEFT
5
A9018820405
SPLASH GUARD FRONT RIGHT, Replaced By: A9018820905
8
A9018820114
BRACKET SPLASH GUARD
10
A0009845529
SCREW BRACKET TO CAB
12
A0009845429
SCREW , Replaced By: A2029840429
12
A2029840429
SCREW , Replaced By: N000000000825
12
N000000000825
TAPPING SCREW BRACKET TO CAB REAR PANEL 6.3X16
14
A9048820201
REAR FENDER
18
N000603006045
SCREW COVERING
21
N912004006102
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
24
N304032006004
NUT SPRING-LOADED PUSH ROD
26
A9048820305
SPLASH GUARD REAR LEFT AND RIGHT
29
N007985008152
SCREW JUNCTION BOX TO BRACKET
32
N006797008244
TOOTHED WASHER MASKED TAIL/STOP/BLINKER LAMP TO TAIL LAMP BRACKET
35
N000440009103
WASHER HIGH PRESSURE HOSE TO BRACKET
38
N304032008006
NUT
