Поз.
Артикул
Описание
5
OIL PAN
5
OIL PAN ALUMINUM
5
OIL PAN , Replaced By: A9040103113
5
OIL PAN ALUMINUM
8
OIL PAN
11
SCREW PLUG
14
SCREW PLUG, FILLING CHARGE AIR PRESSURE M20X1.5
17
SEAL RING
20
SEALING RINGTO A957 490 05 14
20
SEAL RING TEMPERATURE GAUGE SENDER UNIT
23
SCREW PLUG
26
SEALING RING ,760252
27
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
28
SEALING RING. SCREW TO PLUG LONGITUDINAL OIL DUCT,FAN SIDE
29
GASKET OIL PAN TO CYLINDER CRANKCASE TO A 904 010 38 13
29
GASKET , Replaced By: A9040140722
32
STOP PLUG. PLUG OIL LEVEL SENDER UNIT TO OIL PAN
35
GASKET OIL PAN TO CYLINDER CRANKCASE TO A 904 010 08 13 / 31 13
35
GASKET OIL PAN TO CYLINDER CRANKCASE
36
SCREW , Replaced By: A0049900300
36
SCREW CLAMP ON BRACKET
36
HEXAGON HEAD BOLT , REPLACE BOLTS WHEN CARRYING OUT REPAIRS
38
COMBINATION BOLT OIL PAN TO CYLINDER CRANKCASE M 8X40
41
SCREW PLUG, FILLING HOUSING,BOTTOM M18X1.5
44
SEALING RING OIL LINE TO CYLINDER CRANKCASE
47
GUIDE TUBE OIL DIPSTICK,OUTSIDE
47
GUIDE TUBE OIL DIPSTICK,*0055087
47
GUIDE TUBE OIL DIPSTICK,OUTSIDE
47
GUIDE TUBE OUTSIDE OIL MEASURING DEVICE
50
GUIDE TUBE OIL DIPSTICK,OUTSIDE
53
GROMMET
56
GUIDE TUBE OIL DIPSTICK,INSIDE
56
GUIDE TUBE OIL DIPSTICK,INSIDE
56
GUIDE TUBE INSIDE ON CRANKCASE
56
GUIDE TUBE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 310375, Replaced By: A9060102366
59
BRACKET BRACKET FOR DIPSTICK GUIDE TUBE,*0310375
62
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
65
FITTING GUIDE TUBE TO CYLINDER CRANKCASE
68
CABLE TIE. CLAMP GUIDE TUBE TO CYLINDER CRANKCASE
68
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
71
BRACKET GUIDE TUBE TO CYLINDER HEAD,*0042809
74
CLAMP OIL DIPSTICK TO RADIATOR
77
SCREWM 10X20
80
SCREW STOP TO BATTERY CASE
83
SCREW STOP TO BATTERY CASE
86
NUT ENGINE MOUNTING M8
89
OIL DIPSTICK , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 035251, Replaced By: A9040101372
89
OIL DIPSTICK , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 417215, Replaced By: A9040108272
89
OIL DIPSTICK , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 502967, Replaced By: A9040108472
89
OIL DIPSTICK , NOTE FOLLOWING WIS DOCUMENT WIS-NET#AH18.40-N-0001-01A#, Replaced By: A4440101372
89
OIL DIPSTICK
89
OIL DIPSTICK
89
OIL DIPSTICK
89
OIL DIPSTICK
89
OIL DIPSTICK , NEW VERSION IS SHORTER,NO PROBLEMS WITH OIL CAPACITY
92
CAP
95
SEAL RING
95
SEAL RING
98
BRACKET BRACKET
101
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
104
WASHER RADIATOR TO RUBBER MOUNTING
107
CLAMP CLAMP
110
SCREW SCREW 1/4-20,3AM 685442 50 038885
113
WASHER BRACKET TO CROSS MEMBER, INAPPLICABLE TO BM 685.458-002
116
NUT NUT
119
LOCKING CAP , Replaced By: A3845067033
122
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
122
CLAMP25-40X13 MM
125
SCREW PLUG
128
SCREW PLUG, FILLING CHARGE AIR PRESSURE M20X1.5
131
SEALING RING ,760252
134
SEALING RINGTO A957 490 05 14
