Поз.
Артикул
Описание
10
CROSS MEMBER (REAR CROSS MEMBER)
15
GUSSET PLATE BOTTOM RIGHT
15
GUSSET PLATE BOTTOM LEFT
20
BRAKE LINE COUPLING SUPPLY, RED "WABCO"
20
BRAKE LINE COUPLING SUPPLY, RED "KNORR"
20
BRAKE LINE COUPLING SUPPLY, RED "GRAU"
20
BRAKE LINE COUPLING SUPPLY, RED "BOSCH"
25
BRAKE LINE COUPLING BRAKE,YELLOW "WABCO"
25
BRAKE LINE COUPLING BRAKE,YELLOW "KNORR"
25
BRAKE LINE COUPLING BRAKE,YELLOW "GRAU"
25
BRAKE LINE COUPLING BRAKE,YELLOW "BOSCH"
30
SEAL RING"GRAU"
30
SEAL RING30X2 MM,BOSCH
35
SEAL RING25X2 MM,BOSCH
40
SEAL RING33X2.5 MM,BOSCH
45
SEAL RING22X4 MM,BOSCH
50
VALVE TAPPET22X4 MM,BOSCH
55
COVER SUPPLY, RED "WABCO"
60
COVER BRAKE,YELLOW "WABCO"
70
BRACKET AT FRAME
75
BRACKET AT FRAME
80
BRAKE VALVE (SERVICE BRAKE VALVE) KNORR
80
BRAKE VALVE (SERVICE BRAKE VALVE) BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
80
BRAKE VALVE (SERVICE BRAKE VALVE) WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
85
REPAIR KIT SERVICE BRAKE VALVE WABCO
85
REPAIR KIT , Replaced By: A0004308506
90
WASHER , NOT USED
95
COVER BATTERY/APPARATUS SUPPORT
100
GUIDE SIGN LOAD-DEPENDING BRAKE
110
CONSOLE CENTRAL LUBRICATION PUMP TO SUBSTRUCTURE AND TO SUPPORT,RESP.
999
REPAIR KIT BRAKE LINE COUPLING "WABCO"
