Поз.
Артикул
Описание
4
P.T.O.
4
P.T.O.
4
P.T.O.
4
P.T.O.
4
P.T.O.
4
P.T.O.
4
P.T.O.
4
P.T.O. , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 210942, Replaced By: A3812602905, +001A0002607663
4
P.T.O. , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 210942, Replaced By: A3812603005, +001A0002607663
4
P.T.O. , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 210942, Replaced By: A3812603105, +001A0002607663
4
P.T.O. , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 395048, Replaced By: A3812602905
4
P.T.O. , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 395048, Replaced By: A3812603005
4
P.T.O. , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 395048, Replaced By: A3812603105
4
P.T.O. , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 315386, Replaced By: A3812602705
4
P.T.O.
10
SCREW PLUG SHIFT CASE
10
TRANSMISSION CASE , Replaced By: A3812602012, +001A1009970430, +001N007603012110
10
TRANSMISSION CASE , Replaced By: A3812602012, +001A1009970430, +001N007603012110
10
TRANSMISSION CASE , Replaced By: A3812604012, +001A0019976530, +001N007603012106
10
TRANSMISSION CASE , Replaced By: A0019976530, +001A3812603912, +001N007603012106
10
TRANSMISSION CASE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO P.T.O. 017926, Replaced By: A3812603912, +001A0019976530, +001N007603012106
10
TRANSMISSION CASE
12
SCREW PLUG , Replaced By: A0019976530
12
SCREW PLUG SHIFT CASE
14
SEAL RING COMPRESSED AIR LINE TO PARKING BRAKE VALVE
16
RING P.T.O. TO TRANSMISSION
18
GASKET CASE PART I TO CASE PART II
22
CYLINDER PIN P.T.O. HOUSING
26
CORE BAR , FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB5 470513
26
CORE BAR
30
EXPANSION PLUG EXHAUST FLAP BEARING
32
SCREW SUPPORT TO FENDER
32
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL
32
SCREW , Replaced By: N304017008018
32
SCREW , Replaced By: N304017008053
36
SCREW , Replaced By: N304017008067
36
SCREW , Replaced By: N000933008134
36
SCREW , Replaced By: N000931008408
36
SCREW TWO-WAY VALVE TO FRAME M 8X140
36
SCREW BRACKET TO RIGHT SIDE MEMBER,5 434014
36
SCREW FRONT AXLE REGULATING SOLENOID VALVE
38
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
38
SPRING WASHER , Replaced By: N000137008212
40
NUT
42
COVER HOUSING,TOP
42
COVER CASE PART II
44
SCREW SHIFTING FORK TO SHIFTING ROD
46
GASKET CASE COVER
46
GASKET COVER TO P.T.O. CASE
48
SPRING WASHER CAB FLOOR
48
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
52
SCREW COVER TO P.T.O. CASE M 12X22
52
SCREW , Replaced By: N304017012022
52
SCREW CYLINDER TO P.T.O. HOUSING
56
SEAL RING SHIFTING SHAFT
56
SEAL RING
61
SEAL RING DRIVE SHAFT 30 X 50 MM
61
SEAL RING
61
SEAL RING DRIVE SHAFT
66
GASKET , Replaced By: A3212640080
66
GASKET CASE PART I
70
TRANSMISSION CASE COVER CASE PART I TO CASE PART II
72
SPRING WASHER , Replaced By: N000137008212
72
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
74
SCREW , Replaced By: N304017008021
74
SCREW PIPE CLAMP
76
CONNECTOR , Replaced By: A3812640133
76
CONNECTOR (SHIFTING SHAFT)
80
DRIVE SHAFT , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 391855, Replaced By: A3812641306
80
DRIVE SHAFT (SHIFTING SHAFT)
84
CYLINDRICAL ROLLER (SHIFTING SHAFT),4 395047
88
SPACER TUBE (SHIFTING SHAFT),4 395047
90
NEEDLE BEARING (SHIFTING SHAFT),4 395048
92
SLIDING COLLAR (SHIFTING SHAFT)
96
GEAR
96
GEAR DRIVE
100
CYLINDR. ROLLER BEARING
100
GROOVED BALL BEARING (SHIFTING SHAFT)
102
STOP RING
105
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.80 MM
105
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.05 MM
105
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.40 MM
105
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.20 MM
105
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.10 MM
124
GEAR DRIVE
124
GEAR DRIVE
124
GEAR P.T.O.,4 210943-4 395048
124
GEAR DRIVE
124
GEAR , FIRST EXHAUST STOCK OF OLD PARTS FROM IDENT NO. 4 315387-4 395048, Replaced By: A3812600608
128
CYLINDR. ROLLER BEARING REAR
128
CYLINDR. ROLLER BEARING TWIN GEAR
132
LOCK RING DISC SUPPORT
136
SPACER WASHER AS REQUIRED 3.10 MM
136
SPACER WASHER AS REQUIRED 2.85 MM
138
SPACER WASHER AS REQUIRED 0,20 MM
146
SHAFT BOTTOM
146
SHAFT , Replaced By: A3812640618, +001A0049975048
148
SEAL RING SPRING SUSPENSION
150
GEAR INTERMEDIATE AXLE
150
GEAR 33/37 TEETH
150
GEAR INTERMEDIATE AXLE
150
GEAR 33 TEETH
150
GEAR INTERMEDIATE AXLE
150
GEAR INTERMEDIATE AXLE
150
GEAR 33/41 TEETH
156
CYLINDR. ROLLER BEARING TWIN GEAR
156
CYLINDR. ROLLER BEARING FRONT
158
CYLINDR. ROLLER BEARING TWIN GEAR
158
CYLINDR. ROLLER BEARING REAR
160
LOCK RING DISC SUPPORT
164
SPACER TUBE , Replaced By: A3812640153
164
SPACER TUBE
168
SPACER WASHER AS REQUIRED 2.85 MM
168
SPACER WASHER AS REQUIRED 3.10 MM
170
SPACER WASHER AS REQUIRED 0,20 MM
172
SHAFT TOP
172
SHAFT , Replaced By: A3812640518, +001A0049975048
174
SEAL RING SPRING SUSPENSION
176
BRACKET
178
SPRING WASHER , Replaced By: N000137008212
178
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
180
SCREW INTERMEDIATE AXLE 8X16
180
SCREW , Replaced By: N910107008016
182
DRIVE SHAFT , Replaced By: A3812640906
182
DRIVE SHAFT , FIRST EXHAUST STOCK OF OLD PARTS FROM IDENT NO. 4 210943-4 395048, Replaced By: A3812641006
182
DRIVE SHAFT , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 395048, Replaced By: A3812641206
182
DRIVE SHAFT , FIRST EXHAUST STOCK OF OLD PARTS FROM IDENT NO. 4 210943-4 395048, Replaced By: A3812641106
182
DRIVE SHAFT 12 TEETH
182
DRIVE SHAFT TOP
182
DRIVE SHAFT TOP
182
DRIVE SHAFT 20 TEETH
182
DRIVE SHAFT 16 TEETH
182
DRIVE SHAFT TOP
182
DRIVE SHAFT TOP
184
TAPERED ROLLER BEARING FRONT
186
TAPERED ROLLER BEARING DRIVE SHAFT
188
SPACER WASHER AS REQUIRED 5.00 MM
188
SPACER WASHER AS REQUIRED 5.40 MM
188
SPACER WASHER AS REQUIRED 5.20 MM
188
SPACER WASHER AS REQUIRED 3.90 MM
188
SPACER WASHER AS REQUIRED 4.60 MM
188
SPACER WASHER AS REQUIRED 3.80 MM
188
SPACER WASHER AS REQUIRED 5.30 MM
188
SPACER WASHER AS REQUIRED 4.70 MM
188
SPACER WASHER AS REQUIRED 4.50 MM
188
SPACER WASHER AS REQUIRED 4.20 MM
188
SPACER WASHER AS REQUIRED 4.00 MM
188
SPACER WASHER AS REQUIRED 4.90 MM
188
SPACER WASHER AS REQUIRED 0.05 MM
188
SPACER WASHER AS REQUIRED 4.10 MM
188
SPACER WASHER , Replaced By: A3212640852
188
SPACER WASHER , Replaced By: A3212640852
188
SPACER WASHER , Replaced By: A3212641152
188
SPACER WASHER , Replaced By: A3212641452
194
FLANGE INTERMEDIATE SHAFT BEARING TO TRANSFER CASE CROSS MEMBER
200
COUPLING FLANGE
204
WASHER FLANGE TO SHAFT
208
SCREW , ONLY INSTALL 360 990 13 04,SEE SERVICE INFORMATION DATED 15.07.1977,GROUP 03/33, Replaced By: A3609901304
208
SCREW FLANGE TO SHAFT
210
KEY COUPLING FLANGE TO P.T.O.
212
NUT DRAG LINK TO LEVER
214
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
259
GASKET , Replaced By: A3522611680
259
GASKET , Replaced By: A3522611980
259
GASKET COVER TO CASE REAR COVER
259
GASKET P.T.O. TO TRANSMISSION
264
GASKET P.T.O. TO TRANSMISSION
264
GASKET , Replaced By: A3522611780
264
GASKET
266
SPRING WASHER , Replaced By: N000137008212
266
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
268
SCREW OIL PIPE WITH OIL DIPSTICK GUIDE TUBE TO OIL PAN
268
SCREW , Replaced By: A0089902701
268
SCREW P.T.O. TO TRANSMISSION 8X110
268
SCREW P.T.O. TO TRANSMISSION 8X130
268
SCREW P.T.O. TO TRANSMISSION
999
COVER AT TRANSMISSION CASE REAR COVER,4 473926 FROM IDENT NO. SEE MICROFICHE MODEL 714.0 FROM IDENT NO. SEE MICROFICHE MODEL 714.0
999
SCREW PLUG , Replaced By: N000908014009
999
SCREW PLUGTO 000 553 03 05,000 553 18 05,
999
SEAL RING FUEL LINE TO FEED PUMP
999
CLAMPING PIN THRUST PIECE TO SHIFTING ROD
