Поз.
Артикул
Описание
5
VALVE 3/2-WAY,TRANSMISSION LOCK
5
VALVE 3/2-WAY,TRANSMISSION LOCK
5
VALVE 3/2-WAY,TRANSMISSION LOCK
8
SWITCH 3/2-WAY VALVE WABCO
11
PIN PRESSURE SWITCH
14
GASKET 3/2-WAY VALVE
17
HEXALOBULAR BOLT CLAMP ON BRACKET M8X45
17
SCREW , Replaced By: N910105008017
17
HEXAGON HEAD BOLT. SCREW BRACKET MOUNTING M8 X 30
20
VALVE DOUBLE 3/2-WAY
20
VALVE 3/2-WAY,P.T.O. CONTROL, FOR COMPONENT PARTS SEE SPARE PARTS LIST
20
VALVE (SHIFTING CYLINDER)
20
VALVE DOUBLE 3/2-WAY
23
SUPPORT 3/2-WAY VALVE
23
SUPPORT , Replaced By: A9702600460, +002A0049971389
23
SUPPORT 3/2-WAY VALVE
23
SUPPORT 3/2-WAY VALVE
26
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10
26
SEAL RING SPRING LOAD ACCUMULATOR CYLINDER TO M10 / VOSS 230,D 259885
29
LOCK SPRING LOAD ACCUMULATOR CYLINDER TO M10 / VOSS 230,D 259885
29
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10
32
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10, VOSS 230
32
UNION SCREW PNEUMATIC CONNECTION,SUPPLY UNIT M 10, VOSS 232, SDF
32
UNION SCREW SPRING LOAD ACCUMULATOR CYLINDER M10X1 / VOSS 230,D 259885
35
HEXAGON HEAD BOLT SHIFTING CYLINDER M5X55
38
SCREW 3/2-WAY VALVE TO BRACKET
41
SENDER UNIT DECREASE IN NUMBER OF REVOLUTIONS B61.1
41
SENDER UNIT ELECTROPNEUMATIC POWER SHIFT 62 MM
41
SENDER UNIT ELECTROPNEUMATIC POWER SHIFT 25 MM
41
PULSE GENERATOR ACTUATION OF ELECTRONIC SPEEDOMETER 63,2MM
41
SENDER UNIT ACTUATION OF ELECTRONIC SPEEDOMETER 25MM
41
PULSE GENERATOR ACTUATION OF ELECTRONIC SPEEDOMETER 25MM
41
SENDER UNIT ACTUATION OF ELECTRONIC SPEEDOMETER 25 MM
41
SENDER UNIT , Replaced By: A0165421717
41
SENDER UNIT ACTUATION OF ELECTRONIC SPEEDOMETER 25MM, Replaced By: A0155427617
41
SENDER UNIT , Replaced By: A0155423717
41
SENDER UNIT , Replaced By: A0155422417
41
SENDER UNIT , Replaced By: A0145427817
41
PULSE SENDER UNIT. SENDER UNIT (COUNTER WHEEL SENDER)
44
PLUG SOCKET COMPRESSOR
47
SCREW PLUG, FILLING HOUSING,BOTTOM M18X1.5
47
SCREW PLUG BELL HOUSING TO 620 251 07 01,620 251 16 01, 426,427,428,521,522 5 095724 532 5 104253
50
SWITCH BACK-UP LIGHT M20X1,5
50
TAPPET SWITCH ADDITIONAL GEARBOX M20X1.5
50
SWITCH ADDITIONAL GEARBOX, Replaced By: A0015457409
50
SWITCH , Replaced By: A0015454709
50
SWITCH , Replaced By: A0015452909
50
SWITCH BACK-UP LIGHT M20X1.5
55
SWITCH BACK-UP LIGHT M20X1.5
55
SWITCH ADDITIONAL GEARBOX, Replaced By: A0015457409
55
SWITCH , Replaced By: A0015454709
55
TAPPET SWITCH ADDITIONAL GEARBOX M20X1.5
56
SWITCH BACK-UP LIGHT M20X1,5
57
BULKHEAD FITTING RETARDER
59
PIN NEUTRAL POSITION SWITCH 35.2 MM
62
SENDER UNIT TEMPERATURE SENDER UNIT B47
65
SEAL RING TEMPERATURE GAUGE SENDER UNIT
69
FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION M 10X1/ M 10X1
70
UNION SCREW PNEUMATIC CONNECTION,SUPPLY UNIT M 10, VOSS 232, SDF
71
REPAIR KIT O-RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10, SDF
72
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10, 4 MM
72
COUPLING. ELBOW FITTING P.T.O., IN CONJUNCTION WITH CODE: 9N2N
73
CONNECTION PIECE COMPRESSED-AIR-LINE PLUG-CONNECTION TO M10, 4MM, SDF
74
BRACKET TRANSMISSION CASE,FRONT, SIMPLE PART-PLEASE HAVE SHOP MADE
77
BRACKET TRANSMISSION CASE,FRONT
80
BRACKET TRANSMISSION CASE,FRONT
95
HEXALOBULAR BOLT. SCREW
95
HEXALOBULAR BOLT BRACKET TO TRANSMISSION CASE M8X20
95
SCREW , Replaced By: N000000001139
95
SCREW , Replaced By: N000000001139
95
HEXALOBULAR BOLTM8X20
98
HEXALOBULAR BOLT HORN TO BRACKET M10X20,V 207570
98
SCREWM 10X20
107
LOOM TIE LINE MOUNTING 280 MM
999
SEAL RING LOCKING VALVE 20X24
999
BRACKET TRANSMISSION CASE FRONT PART TO REAR PART
999
LINE LOCKING VALVE TO P.T.O.
999
LINE LOCKING VALVE TO SOLENOID VALVE
999
SEAL RING. REPAIR KIT COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10
