Поз.
Артикул
Описание
10
15
PROPELLER SHAFT FROM TRANSMISSION TO INTERMEDIATE BEARING 1038 MM
25
GREASE NIPPLE PROTECTIVE TUBE
27
DRIVE FLANGE
29
UNIVERSAL JOINT CROSS
31
GREASE NIPPLE
33
BEARING BUSHING , SHAFT TO BE BALANCED AFTER REPAIR4 805070
35
NEEDLE
37
LOCK1.800 MM
37
LOCK1.700 MM
37
LOCK1.775 MM
39
BRACKET LEFT
45
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
45
SCREW , Replaced By: N308676012012
49
WASHER BRACKET TO PROPELLER SHAFT BEARING HOUSING
49
DISK , Replaced By: A1232420366
51
LOCK WASHER FITTING TO BRACKET
53
NUT STRAP TO SUPPORT
60
HOUSING INTERMEDIATE BEARING NO.1
70
BALL BEARING , Replaced By: A3844100051, +002A9734110052
75
BEARING RING INTERMEDIATE BEARING NO.1
80
CENTERING FLANGE INTERMEDIATE BEARING NO.1
85
NUT FOLLOWER FLANGE TO PROPELLER SHAFT
85
NUT FOLLOWER FLANGE TO PROPELLER SHAFT TO 384 410 70 30
85
NUT COUPLING FLANGE TO DRIVE SHAFT,5 298189
100
PROPELLER SHAFT , BEARING BUSHING O..D.,45 MM, Replaced By: A3854109307
100
PROPELLER SHAFT FROM INTERMEDIATE BEARING II TO REAR AXLE 1328 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
105
PROPELLER SHAFT , BEARING BUSHING O..D.,45 MM, Replaced By: A3854109707
105
PROPELLER SHAFT FROM PROPELLER SHAFT BEARING TO REAR AXLE I 1550 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
120
GASKET
122
UNIVERSAL JOINT
122
UNIVERSAL JOINT ,4 805070
124
GREASE NIPPLE , Replaced By: N071412008102
124
GREASE NIPPLE
135
PROPELLER SHAFT , BEARING BUSHING O..D.,45 MM, Replaced By: A3854102107
135
PROPELLER SHAFT FROM REAR AXLE I TO REAR AXLE II 740 MM,5 249277,184 KW (250 PS) 625.0055 322984,184 KW (250 PS) 625.009 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
139
UNIVERSAL JOINT , BEARING BUSHING O..D.,45 MM
150
HEXAGON HEAD BOLT , Replaced By: A0029902704
150
SCREW , Replaced By: N308676012013
152
LOCK WASHER FITTING TO BRACKET
154
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
154
NUT , Replaced By: N308673012002
999
GREASE NIPPLE , Replaced By: N071412008102
999
SCREW CONSOLE TO SIDE MEMBER
999
UNIVERSAL JOINT CROSS WITH BUSHINGS
999
DRIVE FLANGE
999
DRIVE FLANGE
999
UNIVERSAL JOINT CROSS , Replaced By: A9734100031
999
BRACKET RIGHT
999
BALL BEARING INTERMEDIATE BEARING NO.1
999
REPAIR KIT INTERMEDIATE SHAFT BEARING
999
REPAIR KIT INTERMEDIATE SHAFT BEARING,4 398113, 10/20
999
DRIVE FLANGE , SHAFT TO BE BALANCED AFTER REPAIR4 805070
999
LOCK1.800 MM
999
DISK , Replaced By: A1232420366
999
SCREW CROSS MEMBER AND GUSSET PLATE TO SIDE MEMBERS M 12X35
999
LOCK AS REQUIRED 1.85 MM
999
LOCK AS REQUIRED 1.80 MM
999
LOCK AS REQUIRED 1.70 MM
999
LOCK , Replaced By: A0069941441
999
LOCK , Replaced By: A0069941241
999
LOCK , Replaced By: A0069940841
