Главная
›
Mercedes
›
VAN
›
314, 308CDI, 311CDI, 313CDI, 316CDI
›
903.673 FROM IDENT-NR. R337627, 5337627, A901274
›
62 COWL,FRONT PANEL
›
090 FRONT END CENTER PIECE & PANELING
Mercedes A0009842429 - Болт
314, 308CDI, 311CDI, 313CDI, 316CDI 903.673 FROM IDENT-NR. R337627, 5337627, A901274
62 COWL,FRONT PANEL - 090 FRONT END CENTER PIECE & PANELING
Поз.
Артикул
Описание
5
A9017200305
DOOR SHELL LEFT, TO BE ADAPTED DURING ASSEMBLY
5
A9017200405
DOOR SHELL RIGHT, TO BE ADAPTED DURING ASSEMBLY
5
A9017200705
DOOR SHELL LEFT
5
A9017200805
DOOR SHELL RIGHT
10
A9017200237
HINGE RIGHT TOP
10
A9017200137
HINGE LEFT TOP
15
A0019840829
SCREW DOOR SLIDE MECHANISM TO DOOR
20
A9017200837
HINGE RIGHT BOTTOM
20
A9017200737
HINGE LEFT BOTTOM
20
A9017200337
HINGE LEFT BOTTOM
20
A9017200437
HINGE RIGHT BOTTOM
25
A0009847529
BOLT. SCREW HINGE TO BODY M8 X 25
30
A9017201116
DOOR CHECK. SOOR CHECK, RIGHT
30
A9017201016
DOOR CHECK LEFT
35
A0007230020
DOOR CHECK. HOLDER RH RIGHT
35
A0007230120
DOOR CHECK LEFT
40
A0019908712
SCREW HINGE TO DOOR M8 X 20
45
N910112006002
HEXAGON NUT. NUT LINE TO SIDE MEMBER
45
N913002006009
NUT OIL TANK TO BRACKET
50
A9017200198
SEAL DOOR STRAP AT A-PILLAR, RIGHT
55
A9018630408
COVERING. COVER
55
A9018630308
COVERING. COVER
60
A0009873844
EXPANSION PLUG
65
A6906970298
SEAL , TO BE PROCURED FROM MBA ONLY
65
A9016970398
SEAL LEFT
70
A6387211480
SEAL CO-DRIVER'S DOOR AND SLIDING DOOR RIGHT
75
A3819973186
STOP PLUG. PLUG
80
A9019970052
HOSE PROTECTIVE HOSE
85
A9016821809
INSULATION DOORS
90
A9017200806
REINFORCEMENT RIGHT
90
A9017200706
REINFORCEMENT LEFT
95
A0009842429
SCREW FENDER TO BRACKET
999
A6906910097
PAD , TO BE PROCURED FROM MBA ONLY
