Mercedes N000094004051 - ШПЛИНТ КРЕПЛЕНИЯ ЦИЛИНДРА

AL 7/8 D-8 731.043

42 FRONT WHEEL BRAKE - 220 BRAKE CYLINDER,ATTACHMENT PARTS

Поз.
Артикул
Описание
5
A0024202724
BRAKE CYLINDER WITH FORDING ABILITY 30"WABCO
14
A0159972448
SEAL RINGWABCO TO 002 420 27 24
17
A0004215286
CUPWABCO
23
A0004216286
DIAPHRAGMWABCO
26
A0004210111
FITTINGWABCO
35
N910113016002
NUT COMBINATION CYLINDER TO BEARING BRACKET
35
N913004016004
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
38
A3619910005
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
38
N001444014209
PIN , Replaced By: A3619910005
38
N001444014216
PIN WHEEL CYLINDER TO SLACK ADJUSTER
41
N000433015005
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
44
N000094004051
COTTER PIN STRAP TO SUPPORT
