Поз.
Артикул
Описание
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE GRAU
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE BOSCH
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE KNORR
5
WHEEL BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE WABCO
11
DIAPHRAGMTO 008 420 60 18,62 18,KNORR
11
DIAPHRAGMBOSCH
11
DIAPHRAGMTO 008 420 23 18,WABCO
14
PLUGTO 694 420 71 18/72 18
14
PLUGBOSCH
17
CUPBOSCH/WABCO
17
CUPKNORR
17
CUPTO 007 420 68 18,WABCO
26
PIN WHEEL CYLINDER TO SLACK ADJUSTER
26
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
29
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
32
COTTER PIN STRAP TO SUPPORT
38
BRACKET LINE TO REAR AXLE, NOT USED
41
NUT COMBINATION CYLINDER TO BEARING BRACKET
41
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
44
BRAKE CAMSHAFT , Replaced By: A6234210136
44
BRAKE CAMSHAFT , Replaced By: A6234210236
44
BRAKE CAMSHAFT WITH LUBRICATING BORE,LEFT
44
BRAKE CAMSHAFT WITH LUBRICATING BORE,RIGHT
47
BRAKE ANCHOR RIGHT
47
BEARING BRACKET , Replaced By: A6584210606
47
BEARING BRACKET , Replaced By: A6584210706
47
BRAKE ANCHOR LEFT
50
BUSHING OUTSIDE
53
BUSHING INSIDE
56
SEAL RING INSIDE BEARING BRACKET
56
SEAL RING INSIDE BEARING BRACKET
56
SEAL RING INSIDE BEARING BRACKET
56
SEAL RING , Replaced By: A0149972247
56
SEAL RING , Replaced By: A0129974147
59
GREASE NIPPLE , Replaced By: N071412008102
59
GREASE NIPPLE
62
CONNECTOR LINE CONNECTION M 8X1
62
CONNECTOR BEARING BRACKET
65
SEAL RING OUTSIDE BEARING BRACKET
65
SEAL RING OUTSIDE BEARING BRACKET
65
SEAL RING OUTSIDE BEARING BRACKET
68
SCREW BEARING BRACKET TO BRAKE ANCHOR
71
NUT BEARING BRACKET TO BRAKE ANCHOR
71
NUT , Replaced By: A0009905750
74
ADJUSTER , Replaced By: A9454200038
74
ADJUSTER , Replaced By: A9454200138
74
ADJUSTER , Replaced By: A9454200138
74
ADJUSTER , Replaced By: A9454200038
74
ADJUSTER AUTOMATIC,RIGHT WABCO
74
ADJUSTER AUTOMATIC,LEFT,E 397780
74
ADJUSTER AUTOMATIC,LEFT WABCO
74
ADJUSTER AUTOMATIC,RIGHT,E 397780
77
SPACER WASHER ADJUSTER TO BRAKE CAMSHAFT
80
STOP WASHER SLACK ADJUSTER TO BRAKE SHAFT
83
SPACER WASHER ADJUSTER TO BRAKE CAMSHAFT 7.50 MM
83
SPACER WASHER ADJUSTER TO BEARING BRACKET 5.00 MM
83
SPACER WASHER ADJUSTER TO BRAKE CAMSHAFT
83
SPACER WASHER ADJUSTER TO BRAKE CAMSHAFT 6.00 MM
83
SPACER WASHER BRAKE SHAFT TO BEARING BRACKET 4,00MM
86
SPACER WASHER ADJUSTER,AS REQUIRED 2.00 MM
86
SPACER WASHER ADJUSTER,AS REQUIRED 1.50 MM
86
SPACER WASHER ADJUSTER,AS REQUIRED 2.50 MM
86
SPACER WASHER ADJUSTER,AS REQUIRED 0.50 MM
89
FITTED WASHER SLACK ADJUSTER TO BEARING BRACKET
89
FITTED WASHER SLACK ADJUSTER TO BEARING BRACKET
92
HEXAGON HEAD BOLT CONTROL ARM, LINKAGE ADJUSTER ON BEARING BRACKET M8X12
95
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
98
WASHER EXHAUST MUFFLER TO STRAP
98
WASHER , Replaced By: N000125008443
101
LOCK RING ADJUSTER TO BRAKE CAMSHAFT
104
PIN ADJUSTER STOP
