Поз.
Артикул
Описание
5
FUEL TANK TO BE MOUNTED ON THE LEFT 300 L, UP TO: 04.98
5
FUEL TANK RIGHT 300L
5
FUEL TANK RIGHT 300L
10
SCREW PLUG FUEL TANK
15
SEALING RING. SEAL RING FUEL TANK
20
FILLER CAP ,K 057755
25
SEAL RING
30
TUMBLER WITH KEY, ANY LOCK,K 057755
35
TUMBLER WITH LOCK DEFINED, STATE LOCK NUMBER WHEN ORDERING
40
KEY BLANK, STATE LOCK NUMBER WHEN ORDERING
45
VALVE (VENT VALVE)
45
VALVE , Replaced By: A0004705193
50
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
55
PLUG BREATHER VALVE
60
LOCK FUEL GAUGE SENDER UNIT CONNECTION
65
SUPPORT , Replaced By: A9414709042
65
SUPPORT REAR TANK
65
SUPPORT REAR RIGHT TANK
65
SUPPORT FUEL TANK TO FRAME
65
SUPPORT FUEL TANK TO FRAME
65
SUPPORT REAR RIGHT TANK
75
SHIM MOUNTING PARTS 7MM
80
SHIM MOUNTING PARTS 8 MM
85
SHIM MOUNTING PARTS
90
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M 14X1.5X35
90
SCREW. HEXAGON HEAD BOLT SUPPORT TO FRAME M14X1.5X40
90
HEXAGON HEAD BOLT. SCREW SUPPORT TO FRAME M14 X 1.5 X 55
90
SCREW. HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X35,V 207570
90
HEXAGON HEAD BOLT. SCREW SUPPORT TO SIDE MEMBER M 14X1.5X50
90
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X40
90
HEXAGON HEAD BOLT. SCREW BRACKET TO CONSOLE
95
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
100
STRAP FUEL TANK TO CONSOLE
100
STRAP FUEL TANK TO CONSOLE
105
PIN STRAP TO SUPPORT
105
PIN , Replaced By: A9444750074
105
PIN , Replaced By: A9414750074, +002N912007016001
110
COTTER PIN STRAP TO SUPPORT
115
CLIP RESERVOIR TO CAB FRONT PANEL
118
CLIP STRAP TO SUPPORT
120
NUT STRAP TO SUPPORT M12X1.5
120
NUT BRACKET TO SIDE MEMBER M12X1.5
125
PAD STRAP 61 MM
130
PAD BRAKE ANCHOR 35.9MM
130
PAD BRAKE ANCHOR 53 MM
135
LINE FUEL EXPANSION PIPE,TANK I AND TANK II 22X18,4MM
140
PLASTIC PIPE FUEL LINE 3X5MM, ORDER BY THE METER
145
CONNECTOR BREATHER LINE CONNECTION
150
SEAL RING FUEL GAUGE SENDER UNIT CONNECTION
155
HOLLOW SCREW FUEL LINE TO FEED PUMP
160
SEAL RING CLUTCH BOOSTER
165
BRACKET FUEL LINE
170
BRACKET FUEL COMPENSATING LINE
175
HEXAGON HEAD BOLT. SCREW LOCK SPRING TO CROSS MEMBER M14X1.5X30
180
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
185
CLAMP LINE CONNECTION
190
CLAMP , Replaced By: A1109950401
195
RUBBER PAD FUEL LINE TO BRACKET
200
SCREW MOUNTING OF INSTRUMENT PANEL
205
NUT RELAY TO BRACKET M5
