Поз.
Артикул
Описание
5
ELECTRIC CABLE FROM ALTERNATOR TO STARTING MOTOR,4 477131
5
ELECTRIC CABLE FROM ALTERNATOR TO STARTING MOTOR,4 477130
5
ELECTRIC CABLE FROM ALTERNATOR TO STARTING MOTOR,4 477130
10
ELECTRIC CABLE FROM REGULATOR TO PLUG CONNECTION AT CAB,4 483482
15
PIN BUSHING HOUSING UNIPOLAR
20
PIN BUSHING HOUSING 3-POLE,4 483482
25
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
28
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
28
PIN BUSHING , Replaced By: A0075458226
30
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
35
LOOM TIE LINE MOUNTING 280 MM
40
ELECTRIC CABLE FROM FRONT PLUG CONNECTION TO ALTERNATOR,4 483482
40
ELECTRIC CABLE FROM FRONT PLUG CONNECTION TO ALTERNATOR,4 483482
40
ELECTRIC CABLE , Replaced By: A3815401227
45
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
50
LOOM TIE LINE MOUNTING 280 MM
55
CLAMP BRAKE HOSE BRACKET
60
BRACKET ALTERNATOR BRANCH-OFF
65
LOOM TIE LINE MOUNTING 280 MM
70
PIN BUSHING HOUSING UNIPOLAR
75
NUT IN CASE OF SUBSEQUENT INSTALLATION
75
NUT , Replaced By: N304032005005
75
NUT
75
NUT BALL PIVOT TO LEVER
80
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
80
SPRING WASHER , Replaced By: N000137008204
80
SPRING WASHER , Replaced By: N000137008212
80
SPRING WASHER HEATER PLUG CABLE HARNESS
80
SPRING WASHER ALTERNATOR CONNECTION W
85
REGULATOR AND CUT-OUT TRANSISTOR,4 483482
90
SCREW CLAMP MOUNTING M 6X16
90
SCREW , Replaced By: N000000001146
95
NUT , Replaced By: N913004006001
95
NUT PUMP TO BRACKET
999
BRACKET CABLE HARNESS MOUNTING
999
BRACKET , Replaced By: A0005462243
999
SPACER TUBE ALTERNATOR BRANCH-OFF TO ALTERNATOR SA 24 439/03/04
999
CLAMP BRACKET TO ALTERNATOR
999
GROMMET ,5 180265
999
ELECTRIC CABLE FROM ALTERNATOR TO STARTING MOTOR,4 477131
999
BRACKET ALTERNATOR BRANCH-OFF
999
BRACKET ALTERNATOR BRANCH-OFF TO ALTERNATOR SA 24 439/03/04
999
ELECTRIC CABLE
999
SCREW CONTROL UNIT TO CAB
999
NUT TWO-WAY VALVE TO BRACKET
