Поз.
Артикул
Описание
5
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
5
HOSE , Replaced By: A0009872827
10
UNION NUT , Replaced By: N915017012100
10
UNION NUT LINE CONNECTION, Replaced By: N000000006239
10
UNION NUT LINE CONNECTION
15
GLAND , Replaced By: A0019901967
15
SEAL CONE LINE CONNECTION
20
BUSHING , Replaced By: N915062009000
20
SLEEVE LINE CONNECTION
25
BANJO UNION , Replaced By: N915052009009
25
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
30
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
55
BANJO UNION , Replaced By: N915052006005
55
BANJO UNION HEATING CONNECTION,K 169122
60
FITTING , Replaced By: N915059006000
60
FITTING
65
INSULATING HOSE BLACK 10 MM, ORDER BY THE METER
95
T-FITTING POWER STEERING
95
FITTING , Replaced By: A0019900970
100
FITTING ,4 667210
100
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
105
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
110
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
115
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
115
SEAL RING
120
ELBOW FITTING
125
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
130
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
135
VALVE PARKING BRAKE VALVE WABCO
135
VALVE PARKING BRAKE VALVE GRAU
135
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
135
VALVE PARKING BRAKE VALVE GRAU
140
HANDLETO 000 430 85 81,WABCO,004 0
142
GASKET KIT PARKING BRAKE VALVE GRAU
145
REPAIR KITTO 000 430 85 81,WABCO,004 0
145
REPAIR KITTO 000 430 86 81,WABCO
150
HOLLOW SCREW , Replaced By: N915036010108
150
HOLLOW SCREW FUEL LINE TO FEED PUMP
155
SEAL RING FUEL LINE TO FEED PUMP
160
BRAKE VALVE TRAILER CONTROL VALVE WABCO,4 375193
160
BRAKE VALVE TRAILER CONTROL VALVE, FROM CHASSIS 4 375194-4 412020 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
160
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034313505
160
BRAKE VALVE , Replaced By: A0014313705
160
BRAKE VALVE TRAILER CONTROL VALVE BOSCH,4 375193 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
240
REPAIR KITTO 001 431 34 05,4 375193
240
REPAIR KITTO 001 431 37 05,4 375193
240
REPAIR KIT , Replaced By: A0024306581
240
REPAIR KIT , Replaced By: A0004304606
240
REPAIR KIT , Replaced By: A0024301660
240
BRAKE VALVE SEAL RING TO 001 431 18 05,4 412020
240
REPAIR KITTO 001 431 79 05, FROM CHASSIS 4 375194-4 428563
240
REPAIR KITTO 001 431 48 05,4 375193
240
REPAIR KITTO 001 431 95 05
240
REPAIR KIT VALVE KIT TO 001 431 37 05,4 375193
250
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
265
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
285
FITTING ,4 412020
305
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
310
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
315
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
315
SEAL RING
320
FITTING , Replaced By: A0019902771
320
ELBOW FITTING DELIVERY LINE TO PUMP
325
FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
335
T-FITTING
345
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
350
ELBOW FITTING
355
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
360
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
365
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
365
SEAL RING
420
NUT , Replaced By: N913004008001
420
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
425
BRACKET TRAILER CONTROL VALVE,4 719029
430
SCREW END PIECE TO EXHAUST PIPE M 10X25
435
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
440
VALVE ,4 412020
445
REPAIR KIT ,4 412020
450
FITTING ,4 412020
455
SEAL RING FUEL LINE TO FEED PUMP
460
FITTING , Replaced By: A0019902771
460
ELBOW FITTING DELIVERY LINE TO PUMP
465
FITTING ,4 412020
470
SEAL RING FUEL LINE TO FEED PUMP
475
HOLLOW SCREW LINE CONNECTION
475
HOLLOW SCREW PNEUMATIC AND HYDRAULIC CYLINDERS, CONNECTION: "21,22"
480
SEAL RING , Replaced By: N007603010110
480
SEAL RING PNEUMATIC VALVE
485
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
490
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
500
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
500
SEAL RING
505
SCREW TWO-WAY VALVE TO CONTROL VALVE,4 719029
510
WASHER , Replaced By: N009021005205
510
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
515
NUT TWO-WAY VALVE TO BRACKET
520
BRAKE LINE COUPLING SUPPLY, RED
520
BRAKE LINE COUPLING SUPPLY, RED
520
BRAKE LINE COUPLING SUPPLY, RED
520
BRAKE LINE COUPLING , Replaced By: A0004297830
520
BRAKE LINE COUPLING SUPPLY, RED
525
SEAL RING"GRAU"
530
COVER SUPPLY, RED "WABCO"
530
COVERTO 000 429 49 30
535
REPAIR KITTO 000 429 63 30
535
REPAIR KITTO 000 429 78 30,4 434236
535
REPAIR KITTO 000 429 37 30
535
REPAIR KIT , TO 000 429 49 304 434235
540
FITTING BRAKE LINE COUPLING TO BRACKET
545
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
550
NUT BRACKET TO SIDE MEMBER
555
BRACKET BRAKE LINE COUPLING,"SUPPLY"
560
SCREW , Replaced By: N304017008034
565
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
565
NUT , Replaced By: N913004008001
570
BRAKE LINE COUPLING , Replaced By: A0004297930
570
BRAKE LINE COUPLING BRAKE,YELLOW BOSCH
570
BRAKE LINE COUPLING BRAKE,YELLOW WESTINGHOUSE
570
BRAKE LINE COUPLING BRAKE,YELLOW GRAU
570
BRAKE LINE COUPLING BRAKE,YELLOW KNORR
575
BRAKE LINE COUPLINGTO 000 429 38 30
575
SEAL RING"WABCO"
575
SEAL RING , Replaced By: A0004296930
580
SEAL RINGTO 000 429 38 30
585
GROOVED PINTO 000 429 51 30,4 434235
595
COVER"WABCO", NOT USED
595
COVERTO 000 429 51 30,4 434235
598
REPAIR KIT"KNORR"
600
FITTING BRAKE LINE COUPLING TO BRACKET
605
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
610
NUT BRACKET TO SIDE MEMBER
615
BRACKET (REAR CROSS MEMBER)
620
SCREW , Replaced By: N304017008034
625
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
625
NUT , Replaced By: N913004008001
