Поз.
Артикул
Описание
5
PLATFORM SHORT CAB, WITH UNDERRUN PROTECTION 4111 MM
5
PLATFORM SHORT CAB 4111MM
5
PLATFORM SHORT CAB, WITH UNDERRUN PROTECTION 4111 MM
5
8
BOTTOM LAYER-GLUED PLATE 4111 MM
8
11
FRONT PANEL1932 MM
14
RAIL FRONT PANEL,RIGHT
14
RAIL FRONT PANEL,LEFT
17
SIDE PANEL4114 MM
20
RAIL ON LEFT SIDE PANEL AT THE REAR,AND ON RIGHT SIDE PANEL AT THE FRONT
20
RAIL ON LEFT SIDE PANEL AT THE FRONT,AND ON RIGHT SIDE PANEL AT THE REAR
23
REAR PANEL1932 MM
26
RAIL REAR PANEL,LEFT
26
RAIL REAR PANEL,RIGHT
29
CLINCH-PIN RAIL TO FLAP
32
CAP
35
HINGE PLATFORM SIDE AND END PANELS
38
PLATE
41
SCREW FOLDING STEP TO REAR PANEL,546180
44
FASTENER PLATFORM PANEL FASTENER
47
SPRING PLATFORM PANEL FASTENER
50
TAKE-UP DEVICE PLATFORM PANEL FASTENER
53
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
56
EYE ANCHORING LUG
56
59
SPACER REAR FENDER TO PLATFORM
62
FOLDING STEP FOR REAR PANEL
68
RUBBER BUFFER FOLDING STEP AND SIDE PANEL
71
HEXAGON HEAD BOLT BRACKET TO BRACKET
74
WASHER STRUT TO CROSS MEMBER
74
WASHER , Replaced By: N007349010007
77
NUT CROSS MEMBER TO SIDE MEMBERS
80
SCREW STOP TO BATTERY CASE
999
999
999
999
999
999
