Поз.
Артикул
Описание
5
RADIATOR
15
BRACKET FUEL TANK
20
BRACKET FUEL TANK
30
PLASTIC PIPE AERATION, ORDER BY THE METER
35
SLEEVE LINE CONNECTION
40
GLAND LINE CONNECTION
45
UNION NUT LINE CONNECTION
50
HOSE FROM FEED LINE TO FILTER 240 MM
52
PLASTIC PIPE FUEL SYSTEM 6X2 MM, ORDER BY THE METER
54
HOSE
56
CONNECTION. DISTRIBUTOR
58
LOOM TIE ONLY WITH AUXILIARY HEATER
58
LOOM TIE
60
HOSE FROM VENT VALVE TO VENTILATION LINE ACTIVATED-CARBON FILTER 13.5-15.3X3X510 MM, ORDER BY THE METER
62
LINE RETURN LINE,R 241684
65
HOSE RETURN LINE
70
LOOM TIE
70
HOSE CLAMP HOSE ATTACHMENT
75
HOSE CLAMP HOSE FASTENING 9/13MM
80
BRACKET
85
BRACKET FUEL LINES TO BRACKET
90
BRACKET FUEL LINE
100
BRACKET AT CLUTCH BELL, P 503835 R 000001
100
BRACKET HOSE TO TRANSMISSION
115
RIVET
120
CLAMP. EXTENDABLE SPACER BREATHER LINE
125
CLAMP RETURN LINE TO CLUTCH HYDRAULIC LINE
130
RUBBER BUFFER TO PLUG THE MOUNTING HOLE USED FOR GROUND CONNECTION IN CASE OF R.H.D.
135
CABLE STRAP REAR SWIVEL DOOR
140
CLAMP BRAKE LINING WEAR INDICATOR
140
BRACKET OIL LINES
140
BRACKET CABLE HARNESS ON HYDRAULIC LINE
