Mercedes A9061503570 -

OM 924 LA - EURO 5 924.995

15 ENGINE ELECTRICAL EQUIPMENT - 045 ATTACHMENT PARTS FOR STARTING MOTOR & ALTERNATOR

Поз.
Артикул
Описание
10
A9061503870
SUPPORT ADDITIONAL, USED WITH AIR CONDITIONER
20
N007346016001
CLAMPING SLEEVE
55
N910105010028
HEXAGON HEAD BOLT ALTERNATOR TO SUPPORT M10X130
55
N910105010029
HEXAGON HEAD BOLT P.T.O. TO TRANSMISSION M10X150
70
N910112010001
NUT , Replaced By: N913023010002
80
A9061841140
BRACKET
85
N910105010009
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
90
N910105012025
HEXAGON HEAD BOLT BRACKET TO BEARING BRACKET M12X35
95
A6019920625
SLEEVEFRIGOBLOCK
100
N910105010003
HEXAGON HEAD BOLT AUTOMATIC TRANSMISSION AT ENGINE M10X60
100
N910105010001
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
105
A9061503570
SUPPORT
110
N910105012028
SCREW SUPPORT TO CYLINDER CRANKCASE M 12X65, UP TO ENGINE 739270
115
N910105010001
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
