Поз.
Артикул
Описание
185
TRANSMISSION CASE TELMA BRAKE
190
THREADED PIN TRANSMISSION CASE
195
SCREW TRANSMISSION CASE M 12X1.5X50
200
SCREW TRANSMISSION CASE TO TRANSMISSION CASE M 12X48
200
STUD TRANSMISSION CASE
205
STUD TRANSMISSION CASE
205
SCREW TRANSMISSION CASE M14X50
215
NUT BATTERY CABLE
220
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
225
SCREW PLUG
230
SEAL RING OIL FILLING AND OIL DRAIN
235
SCREW PLUG CASE,LEFT
240
TRANSMISSION CASE COVER , Replaced By: A3892611920, +001A9029970032, +001N007603018100
240
TRANSMISSION CASE COVER OUTPUT SHAFT,REAR,218760
245
SCREW PLUG, FILLING HOUSING,BOTTOM M18X1.5
245
SCREW PLUG HOUSING,BOTTOM, Replaced By: N000908018011
250
SEAL RING SWITCH TO CASE COVER
265
SEAL RING TRANSMISSION CASE REAR COVER
275
SPACER WASHER HOUSING COVER, AS REQUIRED 0.15MM
275
SPACER WASHER HOUSING COVER, AS REQUIRED 0.10MM
275
SPACER WASHER HOUSING COVER, AS REQUIRED 0.40MM
275
SPACER WASHER HOUSING COVER, AS REQUIRED 0.20MM
275
SPACER WASHER HOUSING COVER, AS REQUIRED 0.60MM
275
SPACER WASHER HOUSING COVER, AS REQUIRED 1.40MM
280
SCREW , Replaced By: A9459901001
280
SCREW TRANSMISSION CASE REAR COVER TO TRANSMISSSION CASE
450
PIPE OIL DISTRIBUTION
450
PIPE OIL DISTRIBUTION
460
SEAL RING SUCTION LINE
465
BUSHING OIL STRAINER
470
SPRING OIL STRAINER
475
VALVE INSERT OIL FLOW CONTROL
475
VALVE INSERT OIL FLOW CONTROL
480
BUSHING PLANETARY GEAR CLUSTER SHIFT
480
BUSHING PLANETARY GEAR CLUSTER SHIFT
490
SPRING OIL FLOW CONTROL
495
SELECTOR VALVE OIL FLOW CONTROL
495
SELECTOR VALVE OIL FLOW CONTROL
500
SEAL RING OIL FLOW CONTROL 2.4X13.3 MM
500
SEAL RING
510
BOOT TRANSMISSION CASE
520
BUSHING TRANSMISSION CASE
525
ROD PLANETARY GEAR CLUSTER SHIFT
525
ROD PLANETARY GEAR CLUSTER SHIFT
525
ROD PLANETARY GEAR CLUSTER SHIFT
550
PISTON
560
SEAL RING PISTON
565
SEAL RING INTERMEDIATE FLANGE TO P.T.O.
565
SEAL RING INTERMEDIATE FLANGE TO P.T.O.
570
SHIFTING CYLINDER PLANETARY GEAR CLUSTER SHIFT
575
SEAL RING SHIFTING CYLINDER 5X3
575
SEAL RING SHIFTING CYLINDER
580
SCREW PLUG, FILLING OIL COOLER
585
SCREW. UNION SCREW LINE CONNECTION
590
LOCK LINE CONNECTION
595
LOCK RING LINE CONNECTION
600
PIN INTERLOCK
605
SPRING INTERLOCK
610
SCREW PLUG INTERLOCK
615
BEARING BOLT SHIFTING FORK TO TRANSMISSION CASE
615
BEARING BOLT SHIFTING FORK TO TRANSMISSION CASE, Replaced By: A9452653074
615
PIN SHIFTING FORK TO TRANSMISSION CASE, Replaced By: A9452652674
620
SLIDE SHIFTING FORK, Replaced By: A9452650349
620
SLIDING BLOCK SHIFTING FORK
625
BRACKET SHIFTING CYLINDER TO TRANSMISSION CASE
635
GEAR RETARDER
635
DRIVE GEAR RETARDER
640
SEAL RING RETARDER
999
LINE DELIVERY LINE
999
LINE SUCTION LINE
999
PIPE LINE RETARDER COOLING WATER FEED
999
PIPE LINE
999
LINE
