Поз.
Артикул
Описание
67
BEARING BRACKET , 393.311 UP TO CHASSIS 4 450302,393.321 UP TO CHASSIS 4 453 074,395.312,322,412,422 UP TO CHASSIS 4 426005
70
BEARING BRACKET , Replaced By: A3465225092
70
BEARING BRACKET AT FRAME 90X64 MM
73
SCREW EXHAUST PIPE TO BRACKET
73
SCREW BRACKET TO SIDE MEMBER
73
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
73
SCREW , Replaced By: N304017010002
73
SCREW BRACKET TO SIDE MEMBER
73
SCREW REAR EXHAUST PIPE TO MUFFLER
73
SCREW END PIECE TO EXHAUST PIPE M 10X25
73
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
76
WASHER RADIATOR TO RUBBER MOUNTING
76
WASHER , Replaced By: N000125010532
79
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
82
NUT , Replaced By: A0009903150
82
NUT , Replaced By: N910113010000
82
NUT STRAP TO BRACKET
82
NUT END PIECE TO EXHAUST PIPE
85
BRACKET , Replaced By: A3935220140
85
BRACKET , Replaced By: A6525222740
85
BRACKET , Replaced By: A3935220140
85
BRACKET , Replaced By: A3935220140
85
BRACKET , Replaced By: A3855220140
85
BRACKET FENDER TO BEARING BRACKET, FRONT, TO BE ADAPTED DURING ASSEMBLY
85
BRACKET , Replaced By: A3935220140
85
BRACKET , Replaced By: A3935220140
85
BRACKET , Replaced By: A3935220140
85
BRACKET , Replaced By: A3935220140
85
BRACKET , Replaced By: A3935220140
85
BRACKET , Replaced By: A3935220140
85
BRACKET RIGHT
85
BRACKET LEFT
85
BRACKET , Replaced By: A3855220140
85
BRACKET , Replaced By: A3935220140
85
BRACKET , Replaced By: A3935220140
85
BRACKET LEFT AND RIGHT,5 453765
85
BRACKET , Replaced By: A3935220140
88
BRACKET , Replaced By: A6525222240
88
BRACKET , Replaced By: A6525221740
88
BRACKET , Replaced By: A6525222340
88
BRACKET LEFT AND RIGHT FRONT
88
BRACKET FENDER TO BEARING BRACKET, FRONT,K 103913 TO BE ADAPTED DURING ASSEMBLY
88
BRACKET , Replaced By: A6525222340
88
BRACKET , Replaced By: A6525221740
88
BRACKET RIGHT
88
BRACKET , Replaced By: A6525222940
88
BRACKET LEFT
88
BRACKET , Replaced By: A6525221740
88
BRACKET , Replaced By: A6525222840
88
BRACKET TAIL LAMP
88
BRACKET , Replaced By: A6525222940
88
BRACKET , Replaced By: A6525222240
88
BRACKET , Replaced By: A6525222240
88
BRACKET RIGHT TAIL LAMP,4 449891
88
BRACKET TAIL LAMP, UP TO IDENT NO. K 279038, FROM IDENT NO. SEE STANDARD VERSION
88
BRACKET , Replaced By: A6525222940
88
BRACKET , Replaced By: A6525222240
88
BRACKET FENDER/TAIL-LAMP FIXTURE, TO BE ADAPTED DURING ASSEMBLY
88
BRACKET , Replaced By: A6525222840
88
BRACKET , Replaced By: A6525222840
88
BRACKET , Replaced By: A6525222240
88
BRACKET , Replaced By: A6525222240
88
BRACKET , Replaced By: A6525222240
88
BRACKET , Replaced By: A6525222240
88
BRACKET TAIL LAMP
88
BRACKET , Replaced By: A6525222640
88
BRACKET , Replaced By: A6525222240
88
BRACKET , Replaced By: A6525222240
88
BRACKET , Replaced By: A6525222240
88
BRACKET , Replaced By: A6525222540
88
BRACKET , Replaced By: A6525222840
88
BRACKET , Replaced By: A6525222840
88
BRACKET , Replaced By: A6525222840
88
BRACKET , Replaced By: A6525222240
88
BRACKET , Replaced By: A6525222540
88
BRACKET , Replaced By: A6525222240
88
BRACKET , Replaced By: A6525222840
88
BRACKET , Replaced By: A6525222840
88
BRACKET , Replaced By: A6525221740
88
BRACKET , Replaced By: A6525222240
88
BRACKET
88
BRACKET , Replaced By: A6525222840
88
BRACKET , Replaced By: A6525222640
91
SCREW RADIATOR M 10X45
94
NUT , Replaced By: N910113010000
94
NUT STRAP TO BRACKET
97
SCREW BRACKET TO BEARING BRACKET, 393.311 FROM IDENT NO.: 4 450303,393.321 FROM IDENT NO.: 4 453074,395.312,322 FROM IDENT NO.: 4 426006
100
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
100
NUT , Replaced By: N913004008001
103
EXPANSION PLUG BRACKET
118
BRACKET FENDER
120
BRACKET COVERING
120
BRACKET FENDER
121
BRACKET FENDER, 393.311 UP TO IDENT NO.: 4 450302,393.321 UP TO IDENT NO.: 4 453073,395.312,322 UP TO IDENT NO.: 4 426005
124
BRACKET RIGHT,4 713379
124
BRACKET LEFT, 393.311 FROM IDENT NO.: 4 450303,393.321 FROM IDENT NO.: 4 453074,395.312,322 FROM IDENT NO.: 4 4260064 713378
124
BRACKET LEFT
124
BRACKET RIGHT
124
BRACKET LEFT,4 713379
124
BRACKET RIGHT
124
BRACKET , Replaced By: A6235200041
124
BRACKET RIGHT, 393.311 FROM IDENT NO.: 4 450303,393.321 FROM IDENT NO.: 4 453074,395.312,322 FROM IDENT NO.: 4 4260064 713378
124
BRACKET RIGHT, 393.311 FROM IDENT NO.: 4 450303,393.321 FROM IDENT NO.: 4 453074,395.312,322 FROM IDENT NO.: 4 4260064 713378
124
BRACKET , Replaced By: A6235200141
127
SCREW DELIVERY AND SUCTION HOSES TO COUPLING MOUTH CROSS MEMBER,5 598039
130
NUT , Replaced By: N910113006001
130
NUT PUMP TO BRACKET
130
NUT , Replaced By: N913004006001
130
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
133
SCREW LEFT AND RIGHT CONSOLES TO FRAME M 14X60
136
SPACER WASHER BRACKET TO FRAME, 393.311 UP TO IDENT NO.: 4 450302,393.321 UP TO IDENT NO.: 4 453073,395.312,322 UP TO IDENT NO.: 4 426005
136
SPACER WASHER FIXTURE TO FRAME
137
SCREW BRACKET TO REAR SPRING SADDLE COUNTER PLATE
137
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
138
NUT , Replaced By: N910113014001
138
NUT BRACKET TO SIDE MEMBER
139
SCREW CONSOLE TO SIDE MEMBER
139
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
139
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
142
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
142
SCREW , Replaced By: N308676016014
145
NUT CONSOLE TO SUPPORT
145
NUT SUPPORT TO SIDE MEMBER
145
NUT , Replaced By: N910113016001
163
LEDGE
166
BRACKET
166
BRACKET COVERING
169
COMBINATION BOLT BRACKET TO COVERING
172
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
175
SCREW COVER PLATE TO BRACKET
178
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
181
NUT , Replaced By: N910113006001
181
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
181
NUT , Replaced By: N913004006001
181
NUT PUMP TO BRACKET
193
GROMMET LINE PASSAGE AT SIDE MEMBER
196
LOOM TIE LINE MOUNTING
199
BRACKET LEFT TAIL LAMP
199
BRACKET LEFT TAIL LAMP
199
BRACKET LEFT TAIL LAMP
199
BRACKET LEFT TAIL LAMP, 393.311 FROM IDENT NO.: 4 450303,393.321 FROM IDENT NO.: 4 453074,395.312,322 FROM IDENT NO.: 4 426006
200
BRACKET RIGHT TAIL LAMP
200
BRACKET RIGHT TAIL LAMP, 393.311 FROM IDENT NO.: 4 450303,393.321 FROM IDENT NO.: 4 453074,395.312,322 FROM IDENT NO.: 4 426006
200
BRACKET RIGHT TAIL LAMP
202
SCREW , Replaced By: N304017008043
202
SCREW VALVE TO BRACKET M 8X55
205
WASHER , Replaced By: N000125008443
205
WASHER EXHAUST MUFFLER TO STRAP
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT , Replaced By: N913004008001
224
BRACKET TAIL LAMP
224
BRACKET NAME PLATE, 393.311 FROM IDENT NO.: 4 450303,393.321 FROM IDENT NO.: 4 453074,395.312,322 FROM IDENT NO.: 4 426006
227
SCREW , Replaced By: N304017008016
227
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
230
NUT , Replaced By: N913004008001
230
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
233
SCREW LICENSE PLATE TO BRACKET,4 300861
236
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
236
WASHER COMPRESSED AIR LINE TO BRACKET
239
NUT PUMP TO BRACKET
239
NUT , Replaced By: N913004006001
242
REFLECTOR
245
BRACKET REFLECTOR, 393.311 FROM IDENT NO.: 4 450303,393.321 FROM IDENT NO.: 4 453074,395.312,322 FROM IDENT NO.: 4 426006
248
CLIP FOR STAY, 393.311 UP TO IDENT NO.: 4 450302,393.321 UP TO IDENT NO.: 4 453073,395.312,322 UP TO IDENT NO.: 4 426005
252
BRACKET FOR STAY, 393.311 FROM IDENT NO.: 4 450303,393.321 FROM IDENT NO.: 4 453074,395.312,322 FROM IDENT NO.: 4 426006
255
RIVET4X8 MM
258
WASHER COMPRESSED AIR LINE TO BRACKET
258
WASHER6,4
258
WASHER , Replaced By: N009021006208
261
RIVET TAIL LAMP BRACKET, 393.311 FROM IDENT NO.: 4 450303,393.321 FROM IDENT NO.: 4 453074,395.312,322 FROM IDENT NO.: 4 426006
264
SCREW LICENSE PLATE TO BRACKET,4 300861
267
NUT PUMP TO BRACKET
267
NUT , Replaced By: N913004006001
270
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
270
WASHER COMPRESSED AIR LINE TO BRACKET
999
BRACKET , Replaced By: A6525222240
999
BRACKET , Replaced By: A6525222240
999
BRACKET TAIL LAMP
999
BRACKET TAIL LAMP TO BRACKET
999
BRACKET
999
BRACKET
999
SUPPORT , Replaced By: A3875840051
999
BRACKET REFLECTOR
999
BRACKET TAIL LAMP,5 453766
999
BRACKET TAIL LAMP,5 453766
999
REFLECTOR
999
SCREW , Replaced By: N914112016015
999
SCREW , Replaced By: N914112016340
