Поз.
Артикул
Описание
5
CLUTCH PRESSURE PLATE , 350.004,013 FROM CHASSIS 357728
5
CLUTCH PRESSURE PLATE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
CLUTCH PRESSURE PLATE , Replaced By: A0032502204
23
SPINDLE RELEASE LEVER,CLUTCH PRESSURE PLATE
23
SPINDLE FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
27
BRACKET FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
34
SPINDLE FOR BRACKETS
34
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
34
SPINDLE FOR BEDDING THE LEVERS IN BRACKETS
38
COTTER PINTO 345 460 94 05
42
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
42
ROLLER FOR BEDDING THE LEVERS IN BRACKETS
46
INSULATING WASHER
50
SLEEVE CLUTCH PRESSURE PLATE
54
SCREWTO 003 250 09 04
58
SCREW RELEASE LEVER,BRACKET
62
LOCK WASHER , Replaced By: N912004005103
66
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.5 MM
66
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.5 MM
66
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
66
PRESSURE SPRING SPRING STEEL WIRE DIA., 4.00 MM
70
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
70
SPRING , Replaced By: A0002523227
70
SPRING , Replaced By: A0002523227
74
CLAMP RELEASE FLANGE TO RELEASE LEVER
74
CLAMP , Replaced By: A0002523227
78
FLANGE CLUTCH PRESSURE PLATE
78
FLANGE CLUTCH PRESSURE PLATE
78
FLANGETO 001 250 07 04,003 250 20 04
82
LOCK , Replaced By: A0002521073
86
LOCK WASHER PLUG SOCKET
90
SCREW RELEASE LEVER,BRACKET
94
REPAIR KITTO 350 250 70 04, 350.004,013 FROM CHASSIS 357728
98
LOCK WASHER , Replaced By: N912004010102
102
SCREW CLUTCH TO FLYWHEEL
106
CLUTCH DISC
106
CLUTCH DISC
106
CLUTCH DISC , Replaced By: A0052500103
106
CLUTCH DISC
999
RELEASE BEARING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 758189, Replaced By: A0002507415
999
RELEASE BEARING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 758189, Replaced By: A0002507415
999
PRESSURE PLATE
999
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523819, +002A0002523975
999
RIVET , Replaced By: A0002522075
999
SPINDLE , Replaced By: A0002522816, +001N006799007003
999
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
999
HOUSING
999
RIVET LINING WITH INTERMEDIATE SPRING
999
NUT , Replaced By: A0002523072
999
RIVET LEAF SPRING TO CLUTCH DISC
999
FLANGE , Replaced By: A0002521245
999
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
999
RIVET , Replaced By: A0002523375
999
LEAF SPRING , Replaced By: A0002523319
999
RIVET , Replaced By: A0002524875
999
CLUTCH LINING , Replaced By: A0012522910
999
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523919, +002A0002523975
999
RIVET , Replaced By: A0002523775
999
HOUSING
999
PRESSURE SPRING SPRING STEEL WIRE DIA., 3.75 MM
999
PRESSURE PLATE CLUTCH PRESSURE PLATE
999
HOUSING
999
HOUSINGTO 001 250 07 04,003 250 20 04
999
CLUTCH LINING , Replaced By: A0012522010
999
SCREW , Replaced By: N000085005106
999
CLUTCH LINING
999
CLUTCH PRESSURE PLATE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 850353, Replaced By: A0032503304
999
CLUTCH DISC , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0062507703
999
PRESSURE PLATE CLUTCH BRAKE
999
GUIDE , Replaced By: A3432540216
999
RELEASE YOKE , Replaced By: A3452937111
999
RELEASE YOKE , Replaced By: A3452930111
999
RELEASE YOKE , Replaced By: A3452930211
999
BELL HOUSING , 350.004,013 UP TO CHASSIS 357727
999
BELL HOUSING ,070150, Replaced By: A3502510201, +001A3852510210, +002N000933008268, +002N912004008100
999
REPAIR KIT
999
REPAIR KIT , Replaced By: A0002500913
999
BUSHING ,4 401411, Replaced By: A3852510450, +001A0119978846
999
BELL HOUSING , Replaced By: A3502510001
999
INTERMEDIATE PIECE ,5 190179, Replaced By: A6209970088, +001A6209880135
999
GREASE CUP ,5 190179, Replaced By: A6209880135, +001A6209970088
