Поз.
Артикул
Описание
10
WATER PUMP WITH GASKETS, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
15
SHAFT ,937666/89, Replaced By: A3662010205, +001N000625900208, +001N000625900209
15
SHAFT
25
THRUST RINGTO 000 201 66 19/72 19
30
BOOTTO 000 201 66 19,000 201 72 19
35
SEAL WITH THRUST RING AND BOOT
35
SEAL , Replaced By: A0012012619
35
SEAL , Replaced By: A0012011919
35
SEAL , Replaced By: A0012011919
35
SEAL , Replaced By: A0012011819
35
SEAL , Replaced By: A0012011719
35
SEAL , Replaced By: A0002019219
35
SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002018019
35
SEAL , Replaced By: A0002019919
40
SEAL RING
45
GROOVED BALL BEARING , FROM ENGINE 937666-999999 YEAR OF MANUFACTURE 1989-1990 FROM ENGINE 100001 YEAR OF MANUFACTURE 1990
45
GROOVED BALL BEARING INTERMEDIATE BEARING
50
GROOVED BALL BEARINGTO 001 466 15 01
50
GROOVED BALL BEARING , FROM ENGINE 937666-999999 YEAR OF MANUFACTURE 1989-1990 FROM ENGINE 100001 YEAR OF MANUFACTURE 1990
60
SEAL RING WATER PUMP
70
SEAL HOLDER
70
SEAL HOLDER
75
SEAL RING
80
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
83
SCREW PLUG STABILIZER
85
HUB
85
FLANGETO 352 200 74 01
90
GASKET WATER PUMP TO CYLINDER CRANKCASE
95
COVERTO 352 200 93 01
95
COVER
95
COVER , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 740566, Replaced By: A3522011803
100
LOCK PLATE , Replaced By: A0000710473
100
LOCK
105
SCREW WATER PUMP COVER TO WATER PUMP HOUSING M 8X28
115
GASKET WATER PUMP TO CYLINDER CRANKCASE, UP TO ENGINE 034435 EXCEPT FOR 034226,034304,034305,034321-034324,034334-034337,034344-034347,034352-034358,034370,034377-034383, 034405-034416,034418-034426.
115
GASKET WATER PUMP COVER
120
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
125
SCREW. HEXAGON HEAD BOLT TRANSMISSION CASE M10X80
130
SCREW CONNECTOR TO REAR SHIFTING ROD
130
SCREW , Replaced By: N304017010047
135
GASKET1 MM
140
HOUSING , Replaced By: A3522031473
140
HOUSING THERMOSTAT HOUSING
147
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
149
SCREW , Replaced By: A4039900210
151
SEAL RING VALVE TO VALVE,K 025179
165
SCREW PLUG
197
GASKET COVER TO THERMOSTAT HOUSING,078816
197
GASKET COVER TO THERMOSTAT HOUSING, NOT USED
213
SCREW AIR COMPRESSOR LINE
213
SCREW , Replaced By: N304017006031
230
GASKET , Replaced By: A3522032680
230
GASKET DE-AERATION LINE TO HEATING LINE
280
THERMOSTAT ELEMENT , Replaced By: A0042038375
280
THERMOSTAT ELEMENT , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 430461YEAR OF MANUFACTURE 1996, Replaced By: A0052032675
280
THERMOSTAT ELEMENT , NOT USED, Replaced By: A0032033275
280
THERMOSTAT ELEMENT , NOT USED, Replaced By: A0032032975
280
THERMOSTAT ELEMENT , 314.9 259272 352.9 437435, Replaced By: A0032033175, +001A3522032280
280
THERMOSTAT ELEMENT ,078816, Replaced By: A0032032875, +001A3522032280
280
THERMOSTAT ELEMENT
280
THERMOSTAT ELEMENT
283
SCREW PLUG ,006116
283
SCREW PLUG ,006116
285
LINE UPPER COOLING WATER LINE TO CYLINDER HEAD
315
SEAL RING CLUTCH BOOSTER
320
SCREW PLUG FUEL TANK
320
SCREW PLUG , Replaced By: N007604014110
325
SEAL RING ON OIL PUMP HOUSING
335
SCREW PLUG
340
GASKET DE-AERATION LINE TO HEATING LINE
340
GASKET , Replaced By: A3522032680
345
FLANGE , 352 849318 353 849318 360 109917, Replaced By: A3522034239, +002N000125008418, +002N000931008322
345
FLANGE HEATING FEED, 352 849319 353 849319 360 109918
353
HEXALOBULAR BOLT BRACKET TO SUPPORT M8X80
353
SCREW VALVE BODY ASSEMBLY TO TRANSMISSION M 8X55
353
SCREW PIPE CLAMP
353
SCREW BRACKET TO CROSS MEMBER
353
HEXAGON HEAD BOLT. SCREW , Replaced By: N910143008016
353
SCREW , Replaced By: N304017008021
353
SCREW FILTER BOWL TO FILTER HEAD M 8X90,841477 ONLY FOR USE WITH BOSCH DOUBLE FILTER
355
WASHER , Replaced By: N000125008443
355
WASHER EXHAUST MUFFLER TO STRAP
365
GASKET PIPE SOCKET TO CYLINDER HEAD, UP TO IDENT NO.5 448662, FROM IDENT NO. 5 448663 SEE UNIT MICROFICHE
370
SCREW DIFFERENTIAL CASE
370
SCREW EXHAUST PIPE TO MUFFLER AND TO HEATER UNIT M 8X55
370
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
375
WASHER , Replaced By: N000125008443
375
WASHER EXHAUST MUFFLER TO STRAP
390
SCREW PLUG , Replaced By: N007604014110
390
SCREW PLUG FUEL TANK
999
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
999
LINE , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 369347, Replaced By: A3522033301
999
HOUSING , Replaced By: A3522031173, +001A3522000354
999
LINE ,000155, Replaced By: A3522032901, +002N000931008061, +002N000931008210
999
HOUSING , 004711-021981, Replaced By: A3522031173, +001N007603018101, +001N007604018101
999
PULLEY
999
WATER PUMP , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 740566, Replaced By: A3532000401
999
WATER PUMP , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO ENGINE 001280, Replaced By: A3522008401
999
LINE , 004711 024899, Replaced By: A3522032901, +002N000931008061, +002N000931008210
999
LOCK
999
FLANGE
999
THRUST RING , Replaced By: A0002010463
