Поз.
Артикул
Описание
112
ALTERNATOR
112
ALTERNATOR28V/140A
112
ALTERNATOR24V/100A
112
ALTERNATOR , Replaced By: A0071542802, +001A0001559115, +001A4221550118
112
ALTERNATOR , Replaced By: A0091540802
112
ALTERNATOR , Replaced By: A0111545002
112
ALTERNATOR , Replaced By: A0081547802
120
COVERTO 004 154 79 02
128
SEAL RING , NOT USED
136
SPACER RINGTO 004 154 79 02,004 154 82 02
136
SPACER RING
144
BEARING BODYTO 004 154 79 02
152
GROOVED BALL BEARING LEFT ALTERNATOR MOUNTING,061991
152
CYLINDR. ROLLER BEARING
160
CARBON BRUSH SET ,600808
160
CARBON BRUSH SETTO 007 154 28 02,009 154 08 02
160
CARBON BRUSH SETTO 008 154 78 02
168
GASKETTO 004 154 79 02
176
SEAL RING
176
SEAL RING ,061991
184
CYLINDR. ROLLER BEARING ,061991
192
RECTIFIERTO 004 154 79 02
192
RECTIFIERTO 007 154 28 02
192
RECTIFIERTO 009 154 08 02,008 154 78 02
192
RECTIFIER , Replaced By: A0001549716
200
DIODETO 005 154 01 02
208
DIODETO 005 154 01 02
216
DIODE EXCITER TO 004 154 79 02
224
ELECTRIC CABLETO 004 154 79 02,004 154 82 02
232
ELECTRIC CABLETO 004 154 79 02
240
STUDTO 004 154 79 02,004 154 82 02
248
WASHER
256
BUSHINGTO 004 154 79 02,004 154 82 02
264
CONTACT RAILTO 004 154 79 02
272
CONDENSER THREE-PHASE ALTERNATOR INTERFERENCE SUPPRESSION
272
CONDENSER
272
CONDENSER ,061991
280
GREASE CUP , Replaced By: A0009971988
280
GREASE NIPPLETO 002 154 85 02
288
SPRING WASHER SHIFTING YOKE BEARING
296
NUT SPRING SHACKLE TO SPRING REAR BRACKET
304
PIPE SOCKETTO 004 154 13 02,049382
312
CONNECTOR
320
PULLEY
328
FAN
328
FAN ,600808
999
CLAMPING BOLT ARMATURE TO 004 151 58 01/003 151 87 01
999
REPAIR KIT ROTOR TO 007 154 28 02
999
REPAIR KIT ROTOR TO 009 154 08 02,008 154 78 02
999
PINIONTO 001 151 38 01, 000 151 33 01
999
CONTROL LEVERTO 001 151 96 01
999
CONTROL LEVERTO 004 151 58 01/003 151 87 01
999
BEARINGTO 004 151 58 01
999
SPRINGTO 003 151 87 01
999
BUSHING STARTER PINION TO 004 151 58 01/003 151 87 01
999
BUSHINGTO 001 151 96 01
999
BUSHINGTO 004 151 58 01/003 151 87 01
999
BUSHINGTO 004 151 58 01
999
SPRINGTO 004 151 58 01
999
REPAIR KITTO 003 151 04 01/74 01
999
EXCITER COIL , Replaced By: A0001519255
999
BUSHING STARTER PINION TO 003 151 04 01/74 01
999
PINIONTO 001 151 96 01
999
BUSHINGTO 004 151 58 01
999
BUSHING , Replaced By: A0001512449
999
PINIONTO 003 151 04 01/74 01
999
SOLENOID SWITCHTO 003 151 86 01/88 01,004 151 59 01
999
PIPE SOCKET , Replaced By: A0001540365
999
PIPE SOCKET , Replaced By: A4031540365
999
RECTIFIER , Replaced By: A0001549716
999
GASKET
999
PIPE SOCKET , Replaced By: A4031540365
999
PIPE SOCKET , Replaced By: A4071540165
999
SCREW , Replaced By: A0009907721
999
GASKET
999
CONNECTOR , Replaced By: A0001541918
999
SPRING
999
CARBON BRUSH SET , Replaced By: A0001547214
999
BEARING BODY , Replaced By: A0001550101
999
PULLEY , Replaced By: A0001550215, +001A0059977092
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
999
BOOT , Replaced By: A0005463335
999
SCREW , Replaced By: A0009909130
999
LOCK WASHER
999
SCREWTO 003 151 87 01
999
SCREWTO 003 151 87 01
999
SCREW REGULATOR MOUNTING TO 009 154 07 02
999
SCREW
999
SCREWTO 004 151 58 01
999
PINION , Replaced By: A0011510213
999
PINIONTO 004 151 58 01/003 151 87 01
999
STARTING MOTOR
999
FANTO 011 154 50 02
999
CONDENSER THREE-PHASE ALTERNATOR INTERFERENCE SUPPRESSION
999
PLUG SOCKET , Replaced By: A0005453726
999
SCREWTO 003 151 86 01/88 01
999
SCREWTO 004 151 58 01
999
REGULATOR AND CUT-OUT , Replaced By: A0021549606
999
REGULATOR AND CUT-OUT
999
STARTING MOTOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 105724, Replaced By: A0031517401
999
STARTING MOTOR , Replaced By: A0031518601
999
STARTING MOTOR , Replaced By: A0031518801
999
PLUG , Replaced By: A0015457726
999
PLUG 4-POLE,5 064562
999
ALTERNATOR , MB PART NO.003 154 39 02BOSCH PART NO. 0 120 400 700 MB PART NO.005 154 29 02BOSCH PART NO. 0 120 489 723 MB PART NO.005 154 33 02BOSCH PART NO. 0 120 489 725, Replaced By: A0051543302
999
ALTERNATOR
999
BALL BEARING
999
SPRINGTO 001 151 96 01
999
SEAL RINGTO 001 151 96 01
999
VIBRATION ABSORBER , Replaced By: A3520303103
999
GROUND CABLE , Replaced By: A3835400141
999
BRACKET , 086166, Replaced By: A3521500773, +001A3149900940, +002N000960012258, +001N000985012002
999
SCREENING PLATE , Replaced By: A3521500675
999
GROUND CABLE ,362846
999
CLAMPING BOLT (CLAMPING BOLT)
999
BRACKET ALTERNATOR
999
GROUND CABLE , Replaced By: A4031500732
999
BRACKET ALTERNATOR
999
ALTERNATOR , Replaced By: A0051540102, +002A3601502272, +001A0001540365, +003N000084006137, +002N000936010010, +003N912004006102
999
COVER PLATE , FROM ENGINE 528530 ALSO INSTALLED ON 526958-526960,526991-526996,527139,527190-527198,528000-528057.578966
999
SCREW ALTERNATOR MOUNTING
999
OIL LINE
999
PULLEY , Replaced By: A3522000305
999
FAN
999
HOSE , Replaced By: A0149973382
999
BRACKET CABLE HARNESS MOUNTING
999
GROUND STRAP ,396803
999
GROUND CABLE GENERATOR TO GENERATOR SUPPORT,529890
999
COVER
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
GROOVED BALL BEARING DRIVE END BEARING 005 154 45 02/84 02
999
STUD
999
SCREW ADDITIONAL WORK ON FRAME MOUNTED CABLE HARNESS
999
SCREW , Replaced By: N007985004130
999
SCREW T-FITTING TO BRACKET M4X25
999
SCREW APPARATUS PLATE TO CAB,K 062140
999
SNAP RING
