Поз.
Артикул
Описание
1
T-FITTING COMPRESSED AIR VALVE CONNECTION
5
VALVE (OVERFLOW VALVE)
5
VALVE (OVERFLOW VALVE)
5
VALVE (OVERFLOW VALVE)
5
VALVE (OVERFLOW VALVE)
5
VALVE , Replaced By: A0014295244
10
DIAPHRAGMTO 344 429 73 44
10
DIAPHRAGM
15
REPAIR KITTO 003 429 02 44
15
REPAIR KITTO 003 429 02 44
15
REPAIR KITTO 001 429 52 44
15
REPAIR KITTO 001 429 52 44
15
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
15
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
15
REPAIR KITTO 000 429 63 44,000 429 59 44
20
O-RING CHECK VALVE TO AIR RESERVOIR
25
THRUST RING CHECK VALVE TO AIR RESERVOIR
25
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
30
NUT CHECK VALVE TO AIR RESERVOIR
35
ELBOW FITTING AT OVERFLOW VALVE
40
T-FITTING AT DISTRIBUTOR,4 481288
40
T-FITTING AT DISTRIBUTOR,4 481288
45
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
45
LINE , Replaced By: A0004296201
50
TS DOUBLE FITTING SOLENOID VALVE
50
TS DOUBLE FITTING SOLENOID VALVE
50
FITTING , Replaced By: A0029906071
50
FITTING , Replaced By: A0039979072
55
SEAL RING LINE CONNECTION
57
TS DOUBLE FITTING SOLENOID VALVE
57
FITTING , Replaced By: A0029906071
57
FITTING , Replaced By: A0039979072
60
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
60
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
60
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH
60
VALVE EXHAUST BRAKE OPERATING MECHANISM BOSCH, OPTIONAL WITH 000 434 08 01
61
VALVE EXHAUST BRAKE OPERATING MECHANISM WESTINGHOUSE
61
VALVE , Replaced By: A0004342301
61
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 422115, Replaced By: A0004342301
62
CUP 3/2-WAY VALVE WABCO
63
HANDLETO 000 434 23 01
63
HANDLETO 000 434 23 01
64
REPAIR KIT 3/2-WAY VALVE WABCO
64
REPAIR KIT 3/2-WAY VALVE WABCO
64
REPAIR KIT 3/2-WAY VALVE WABCO
65
GUIDE
65
GUIDE
67
SPRING WASHER OPERATING VALVE TO SIDE MEMBER SHELL
67
SPRING WASHER OPERATING VALVE TO SIDE MEMBER SHELL
69
PROTECTIVE PLATE OPERATING VALVE TO SIDE MEMBER SHELL
71
BRACKET
75
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
77
CLAMP LINE MOUNTING
85
BRACKET CAB,LEFT
90
CLAMP SENSOR CABLE TO BRACKET
105
CLAMP BRAKE LINE TO SIDE AND CROSS MEMBERS
105
CLAMP LINE MOUNTING
110
PLATE
115
MUFFLER MUFFLER TO BRACKET,4 775769
120
SHAFT
125
FITTED WASHER , USED WITH AIR BRAKE
130
LEVER
130
LEVER
135
LOCK RING PIN TO BEARING BRACKET, 380.017,080,081,180,181 ONLY FOR SHORT CAB MERCEDES-BENZ
140
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
145
SCREW
145
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
145
SCREW , Replaced By: N304017008016
150
YOKE
155
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
999
ADAPTER FITTING , Replaced By: A0039972072
999
VALVE
999
STRAINERTO 000 434 21 01
999
PROTECTIVE CAPTO 000 434 08 01,345 434 71 01
999
CUP , Replaced By: A0004340486
999
CUPTO 000 434 10 01
999
BUSHINGTO 000 434 10 01
999
VALVE , Replaced By: A0004342401
999
VALVE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 422115, Replaced By: A0004342101
999
VALVE , Replaced By: A0004342601
999
VALVE"WESTINGHOUSE"
999
VALVEWABCO
999
SWITCH 3/2-WAY VALVE
999
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
999
VALVE , NOT USED
999
T-FITTING CONTROL UNLOCKING MECHANISM HIGHPRESSURE HOSE TO OIL DELIVERY LINE, 415 5 014669 416 5 000516 417 4 9720245 144227, Replaced By: N000000006204
999
ELBOW FITTING LINE CONNECTION, UP TO CHASSIS 4 329112,FROM CHASSIS SEE SA 25 009
999
CLAMP , Replaced By: N916016006201
999
HANDLETO 000 434 24 01
999
SPRINGTO 000 434 21 01
999
REPAIR KITTO 000 434 10 01, FOR VALVE HAVING THE BOSCH CHARACTERISTIC NUMBER 427
999
REPAIR KITTO 000 434 10 01, FOR VALVE HAVING THE BOSCH CHARACTERISTIC NUMBER 428
999
VALVE
999
REPAIR KIT 3/2-WAY VALVE BOSCH
999
REPAIR KITTO 001 431 79 05, FROM CHASSIS 4 375194-4 428563
999
REPAIR KITTO 000 434 11 01
999
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
SEAL RINGTO 000 434 21 01
999
AIR CLEANER , Replaced By: A0080944802
999
SEAL RINGTO 000 434 23 01
999
SEAL RINGTO 000 434 23 01
999
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
BALL PIVOT LEVER
999
CLAMP
999
VALVE , Replaced By: A3454347001
999
WASHER OPERATING VALVE TO SIDE MEMBER SHELL
999
WASHER , UP TO IDENT NO. 4 667209,FROM IDENT NO. SEE SA 25011
999
BRACKET , Replaced By: A3604312140
999
BRAKE CAMSHAFT BEARING , Replaced By: A3604312140
999
YOKE
999
BRACKET , Replaced By: A3604312140
999
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
WASHER , Replaced By: N001440027000
999
FITTING CONTROL UNLOCKING MECHANISM HIGHPRESSURE HOSE TO OIL DELIVERY LINE, 415 5 014669 416 5 000516 417 4 9720245 144227
999
SCREW CONTACTOR
999
SCREW STEERING COLUMN PANELLING M 5X12
999
SCREW BRACKET TO CAB CROSS MEMBER
999
SCREW , Replaced By: N000933008337
999
SCREW , Replaced By: N304017008021
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: A0099900101
999
NUT BALL PIVOT TO LEVER
999
WASHER VALVE TO BRACKET
999
CONNECTION FITTING , Replaced By: A0039979172
999
FITTING , Replaced By: A0009907171
999
SEAL RING LINE CONNECTION
999
GREASE NIPPLE
999
BALL PIVOT , Replaced By: A3129910120
999
DOUBLE FITTING , Replaced By: A0019972872
999
NUT , Replaced By: N080705026003
999
NUT 3/2-WAY VALVE TO CAB,4 685151
999
SCREW PIPE CLAMP
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
NUT , Replaced By: N304032005005
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
NUT
999
LOCK WASHER LINE MOUNTING
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
