Поз.
Артикул
Описание
637
BEARING BRACKET INTERMEDIATE LEVER TO BEARING BRACKET
637
BEARING BRACKET
638
BRACKET INTERMEDIATE LEVER
641
BUSHING LEVER
642
GREASE NIPPLE
643
PIN
644
LOCK RING22X1.2,TO 001 431 71 14
645
SPRING LEVER
646
YOKE POWER CYLINDER TO EXHAUST SHUNT FLAP
647
PIN PULL ROD TO BRAKE LEVER,REAR AXLE
648
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
648
WASHER , Replaced By: N000433013010
651
NUT FROM BRAKE SHAFT TO BRAKE LEVER
651
TURNBUCKLE , Replaced By: A3859960034
652
NUT STRAP TO SUPPORT,5 149419
653
PULL ROD SHIFTING TRANSFER, TO BE ADAPTED DURING ASSEMBLY
654
NUT PULL ROD
656
NUT STRAP TO SUPPORT,5 149419
657
YOKE POWER CYLINDER TO EXHAUST SHUNT FLAP
659
PIN PULL ROD TO BRAKE LEVER,REAR AXLE
660
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
660
WASHER , Replaced By: N000433013010
999
SCREW PLUG , Replaced By: A0004315433
999
PROTECTIVE CAP , Replaced By: A0004217187
999
PROTECTIVE CAPTO 002 420 95 18,045 420 02 18,044348
999
PROTECTIVE CAP , Replaced By: A3164210087
999
PROTECTIVE CAP SHEET METAL VERSION
999
PROTECTIVE CAP ,5 962906
999
PROTECTIVE CAP
999
CONNECTOR , Replaced By: A0004292736
999
BRAKE HOSE , Replaced By: A0024280735
999
BRAKE HOSE
999
BRAKE HOSE , Replaced By: A0024280735
999
LINE , Replaced By: A0005516256
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
LINE , Replaced By: A0005516456
999
LINE , Replaced By: A0004296201
999
ELBOW FITTING PRESSURE REGULATOR,CONNECTION "1"
999
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
999
KAPPENVENTIL. VALVETO 002 430 31 01,344 430 80 01
999
BOTTOM VALVE. VALVE , Replaced By: A0015861543
999
REPAIR KITTO 002 431 15 06,WABCO, 975 300 750 0,5 161700
999
REPAIR KITTO 001 431 06 06,BOSCH 0 481 039 101,5 148812
999
REPAIR KIT DIAPHRAGM PART BOSCH,209
999
PISTONTO 002 430 84 01
999
REPAIR KIT SEAL RING BOSCH,209
999
LOCK
999
VALVE , Replaced By: A3075530107
999
WASHER , Replaced By: A0004311176
999
CONNECTOR , FROM IDENT NO. 001338 EXCEPT FOR 0013438 0000014 2827078 000001-8 001702
999
ANSCHLUSSSTUCK. THREADED UNION
999
COVER. THREADED UNION
999
FILLER RING
999
DICHTSCHEIBE. SEAL RING
999
CUP SECONDARY
999
SPRING RETAINER BRAKE MASTER CYLINDER
999
LOCK
999
WASHERTO 002 430 41 01, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
BRAKE BOOSTER , Replaced By: A0004318814
999
FILLER RINGTO 002 430 41 01, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
WASHER BRAKE MASTER CYLINDER
999
PISTONTO 002 430 21 01,002 430 36 01
999
SPRING BRAKE MASTER CYLINDER
999
PISTON BRAKE MASTER CYLINDER
999
PISTON BRAKE MASTER CYLINDER
999
SPRING BRAKE MASTER CYLINDER
999
BRAKE BOOSTER , Replaced By: A0004318814
999
INSTRUCTION PLATE IN GERMAN
999
REPAIR KIT (TANDEM BRAKE MASTER CYLINDER)
999
REPAIR KITTO 002 430 36 01,002 430 21 01
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
PLASTIC PIPE RISING PIPE 4X6 MM
999
SPRING
999
SPRING
999
SPRING
999
CLAMP , Replaced By: A3604300143
999
SCREW. UNION SCREW LINE CONNECTION
999
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
999
BRAKE HOSE , Replaced By: A0024280735
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
BRAKE MASTER CYLINDER (TANDEM BRAKE MASTER CYLINDER) TEVES, 734559
999
PRESSURE REGULATOR"WABCO",486597
999
PRESSURE REGULATORWABCO
999
PRESSURE REGULATOR , Replaced By: A0024316006
999
REPAIR KIT , Replaced By: A0004303183
999
REPAIR KIT , Replaced By: A0004301107
999
REPAIR KIT , Replaced By: A0004301407
999
FITTING , Replaced By: N915059004001
999
FITTING
999
WHEEL BRAKE CYLINDER , Replaced By: A0024207718
999
WHEEL BRAKE CYLINDER , Replaced By: A0034207818
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
PRESSURE REGULATORBOSCH
999
PRESSURE REGULATOR"WESTINGHOUSE", TO 001 429 60 44
999
PRESSURE REGULATOR , Replaced By: A0024315906
999
REPAIR KIT
999
SEAL RING
999
SEAL RING BRAKE MASTER CYLINDER, UP TO IDENT NO. 734559,FROM CHASSIS,STANDARD EQUIPMENT
999
HOSE FROM FLUID RESERVOIR TO CYLINDER, 600554-600937
999
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
999
DRUCKFEDER. SPRING , Replaced By: A3145860142
999
THRUST SHACKLE , UP TO REAR AXLE029311, Replaced By: A3024201419, +001A3024230874, +001A3024940109, +001N000933008106, +001N912004008102
999
ADJUSTER. REPAIR KIT READJUSTMENT OF REAR WHEEL BRAKE,1 239645
999
SHACKLE
999
PIVOT PIN , Replaced By: A3024210118
999
SLIDE IN ITS PLACE,YOU MAY ALSO USE MERCEDES-BENZ PART NO.: 302 421 01 29
999
PIN , Replaced By: A3024210174
999
THRUST PIN
999
SLIDE , Replaced By: A3024210229
999
SLIDE , Replaced By: A3024210329
999
SLIDE BRAKE READJUSTMENT
999
BRAKE CAMSHAFT , 000435, Replaced By: A3024230636, +001A3414230186
999
REPAIR KIT , Replaced By: A3024202938
999
SPRING , Replaced By: A3385860342
999
VALVE CLUTCH SLAVE CYLINDER
999
RIVET BRAKE LINING 15 MM
999
PIPE BRACKET PRESSURE GAUGE LINE TO BRACKET
999
LOCK , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
999
SPRING , Replaced By: A3029930310
999
SPACER RING , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
PAWL , Replaced By: A3145860142
999
BUSHING , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
PLATE , Replaced By: A3145860142
999
HOSE
999
REPAIR KIT
999
REPAIR KIT , Replaced By: A3144200092
999
GROMMET , Replaced By: A3359970081
999
PROTECTIVE CAP , Replaced By: A0004210887
999
LINE , Replaced By: A3524206828
999
LINE , Replaced By: A3524207028
999
CONSOLE , Replaced By: A3224320215, +001A3224300240, +002N913004012000
999
CONSOLE , Replaced By: A3224320215, +002N913004012000
999
SPHERICAL PIECE , Replaced By: A3025860242
999
REPAIR KIT , Replaced By: A3124201338, +001A1869904540, +001A3129934901, +001N001473004012
999
REPAIR KIT , Replaced By: A3284200138
999
REPAIR KIT BRAKE SHOE SHACKLE SPACER PIN
999
REPAIR KIT , Replaced By: A3384200082
999
BRAKE SHOE , Replaced By: A3414200319
999
BRAKE SHOE , Replaced By: A3414200319
999
BRAKE SHOE , Replaced By: A3414200319
999
SPRING , Replaced By: A3029930610
999
BRAKE LINING (PARTS KIT),REPAIR SIZE II (ASBESTOS-FREE BRAKE LINING) 17.30 MM
999
REPAIR KIT , Replaced By: A3585860242
999
LINE , Replaced By: A3524206628
999
BRAKE INTERMEDIATE SHAFT , Replaced By: A3524201080
999
LINE , Replaced By: A3524206628
999
LINE , Replaced By: A3524206628
999
LINE FROM FLUID RESERVOIR TO CYLINDER, 600553
999
LINE , Replaced By: A3404202429
999
LINE , Replaced By: A3404201029
999
LINE , Replaced By: A3524207730
999
LINE , Replaced By: A3524207830
999
LEVER , Replaced By: A3604260711
999
SPHERICAL PIECE , Replaced By: A3025860242
999
BRACKET INTERMEDIATE LEVER
999
BRACKET AT CAB CONSOLE, 600553
999
BRACKET ,845437
999
BRACKET BRAKE FLUID RESERVOIR
999
BRACKET OIL LINE MOUNTING
999
LINE , Replaced By: A0004290201
999
LEVER , Replaced By: A3524301423
999
BUSHING , Replaced By: A3529920801
999
BRACKET , Replaced By: A3524315340
999
BRACKET , Replaced By: A3524315340
999
ELECTRIC CABLE , Replaced By: A0089976082, +002A0019973472, +002A0019975072, +001N040621010200, +002N915001004003
999
HOSE , Replaced By: A3074290035, +001A0019909871, +001A0029906071
999
NUT , Replaced By: A3589900051
999
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
999
BRAKE SHOE , Replaced By: A3534200819
999
BRAKE SHOE , Replaced By: A3534200019
999
LINE , Replaced By: A3404202429
999
ROD FROM DOUBLE LEVER TO REAR AXLE II, USED WITH HYDRAULIC BRAKE,UP TO CHASSIS 588185
999
BRAKE SHOE ,910369 EXCEPT FOR 501456-599999910370 ALSO INSTALLED ON 501456-599999, SEE SPARE PARTS LIST 731.3, Replaced By: A3524200019, +002A3534232710, +016A3079900197
999
BRAKE SHOE ,910369 EXCEPT FOR 501456-599999910370 ALSO INSTALLED ON 501456-599999, SEE SPARE PARTS LIST 731.3, Replaced By: A3534200019, +002A3534232810, +016A3079900197
999
LINE , Replaced By: A3404201029
999
BRAKE SHOE , Replaced By: A3534200819
999
SCREW , Replaced By: N900170012019, +001N913001012000
999
SCREW , Replaced By: N900170012001, +001N913001012000
999
SCREW , Replaced By: N900170012019, +001N913001012000
999
REPAIR KIT BRAKE SHOE MOUNTING BOLT
999
RATCHET ROD , Replaced By: A3604200188
999
LOCK BRAKE SHOE ADJUSTMENT,1 239645
999
REPAIR KIT , Replaced By: A3584200182
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
LEVER , Replaced By: A3604260711
999
CLAMP LINE MOUNTING
999
CLAMP LINE MOUNTING
999
CLAMP , Replaced By: A6739950001
999
ADHESIVE FOIL GUIDE SIGN
999
CLAMP DELIVERY AND SUCTION LINES TO STEERING
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
SCREW ,374026
999
SCREW PROTECTION PLATE TO BRACKET
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
COTTER PIN VIBRATION ABSORBER TO BRACKET,5 117575
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PINROCKINGER TYP 260 G140
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
