Поз.
Артикул
Описание
10
TRANSMISSION CASE
15
RING P.T.O. TO TRANSMISSION
20
GASKET CASE PART I TO CASE PART II
25
CYLINDER PIN P.T.O. HOUSING
30
EXPANSION PLUG ENGINE LEFT AND RIGHT SUPPORTS
40
EXPANSION PLUG EXHAUST FLAP BEARING
60
COVER CASE PART II
65
GASKET CASE COVER
70
SPRING WASHER CASE PART I TO CASE PART II
75
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
75
SCREW , Replaced By: A0099900101
75
SCREW , Replaced By: N000933008337
80
SEAL RING
85
SEAL RING DRIVE SHAFT 30 X 50 MM
90
GASKET CASE PART I
90
GASKET , Replaced By: A3212640080
95
TRANSMISSION CASE COVER CASE PART I TO CASE PART II
100
SPRING WASHER CASE PART I TO CASE PART II
105
SCREW , Replaced By: N304017008021
105
SCREW PIPE CLAMP
110
CONNECTOR , Replaced By: A3812640133
110
CONNECTOR (SHIFTING SHAFT)
115
DRIVE SHAFT , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 391855, Replaced By: A3812641406
115
DRIVE SHAFT (SHIFTING SHAFT)
120
CYLINDRICAL ROLLER (SHIFTING SHAFT),4 395047
125
SPACER TUBE (SHIFTING SHAFT),4 395047
130
NEEDLE BEARING (SHIFTING SHAFT),4 395048
135
ROLLER ASSEMBLY , Replaced By: A0029813412
135
ROLLER ASSEMBLY
135
ROLLER ASSEMBLY
135
ROLLER ASSEMBLY
135
ROLLER ASSEMBLY
135
ROLLER ASSEMBLY
140
SLIDING COLLAR (SHIFTING SHAFT)
145
GEAR
150
GROOVED BALL BEARING (SHIFTING SHAFT)
155
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.05 MM
155
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.10 MM
155
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.20 MM
155
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.40 MM
155
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.80 MM
160
DRIVE SHAFT
165
GROOVED BALL BEARING
170
SNAP RING
175
RETAINING RING BEARING TO DRIVE SHAFT
185
GEAR (SHIFTING SHAFT)
190
CYLINDR. ROLLER BEARING REAR
195
LOCK RING DISC SUPPORT
200
SPACER WASHER AS REQUIRED 2.85 MM
200
SPACER WASHER AS REQUIRED 3.10 MM
205
SPACER WASHER AS REQUIRED 0,20 MM
210
SHAFT , Replaced By: A3812640618, +001A0049975048
210
SHAFT BOTTOM
215
SEAL RING SPRING SUSPENSION
220
GEAR 33/41 TEETH
220
GEAR 33/37 TEETH
220
GEAR 33 TEETH
225
CYLINDR. ROLLER BEARING FRONT
230
CYLINDR. ROLLER BEARING REAR
235
LOCK RING DISC SUPPORT
240
SPACER TUBE , Replaced By: A3812640153
240
SPACER TUBE
245
SPACER WASHER AS REQUIRED 2.85 MM
245
SPACER WASHER AS REQUIRED 3.10 MM
250
SPACER WASHER AS REQUIRED 0,20 MM
255
SHAFT , Replaced By: A3812640518, +001A0049975048
255
SHAFT TOP
260
SEAL RING SPRING SUSPENSION
265
SPRING WASHER CASE PART I TO CASE PART II
270
SCREW , Replaced By: N304017008016
270
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
275
DRIVE SHAFT 12 TEETH
275
DRIVE SHAFT 16 TEETH
275
DRIVE SHAFT 20 TEETH
280
TAPERED ROLLER BEARING FRONT
285
TAPERED ROLLER BEARING , Replaced By: A0019816505
285
TAPERED ROLLER BEARING OUTSIDE
290
SPACER WASHER AS REQUIRED 0.05 MM
290
SPACER WASHER AS REQUIRED 4.00 MM
290
SPACER WASHER AS REQUIRED 4.10 MM
290
SPACER WASHER AS REQUIRED 4.20 MM
290
SPACER WASHER , Replaced By: A3212640852
290
SPACER WASHER AS REQUIRED 4.50 MM
290
SPACER WASHER , Replaced By: A3212640852
290
SPACER WASHER AS REQUIRED 4.50 MM
290
SPACER WASHER AS REQUIRED 4.50 MM
290
SPACER WASHER AS REQUIRED 4.60 MM
290
SPACER WASHER , Replaced By: A3212641152
290
SPACER WASHER AS REQUIRED 4.70 MM
290
SPACER WASHER AS REQUIRED 4.70 MM
290
SPACER WASHER , Replaced By: A3212641452
290
SPACER WASHER AS REQUIRED 4.90 MM
290
SPACER WASHER AS REQUIRED 5.00 MM
290
SPACER WASHER AS REQUIRED 4.90 MM
290
SPACER WASHER AS REQUIRED 5.20 MM
290
SPACER WASHER AS REQUIRED 5.30 MM
290
SPACER WASHER AS REQUIRED 5.40 MM
345
KEY COUPLING FLANGE TO P.T.O.
350
NUT DRAG LINK TO LEVER
355
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
360
GASKET , Replaced By: A3522611180
360
GASKET , Replaced By: A3522611680
360
GASKET P.T.O. TO TRANSMISSION
360
GASKET COVER TO CASE REAR COVER
360
GASKET , Replaced By: A3522611980
365
GASKET
365
GASKET , Replaced By: A3522611780
365
GASKET P.T.O. TO TRANSMISSION
999
SPACER WASHER0.10 MM
999
SPACER WASHER AS REQUIRED 0.40 MM
999
BRACKET
999
P.T.O.
999
P.T.O.
999
CORE BAR CASE PART II
