Поз.
Артикул
Описание
5
ENGINE SUPPORT FRONT
10
SCREW SUPPORTING ARM TO ENGINE
10
SCREW ALTERNATOR SUPPORT TO CYLINDER CRANKCASE
10
SCREW SUPPORT TO CYLINDER CRANKCASE M 14X120
15
WASHER , Replaced By: N000125015019
15
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
20
NUT , Replaced By: N308673014001
20
NUT , Replaced By: N308675014000
20
NUT , Replaced By: N308675014002
20
NUT RELEASE BEARING LUBRICATION
20
NUT BRACKET TO SIDE MEMBER,K 035196
35
SUSPENSION EYE REAR,565053
40
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
45
SCREW BRACKET TO CONSOLE
45
SCREW SUPPORT TO MOUNTING PLATE,D 180260
