Поз.
Артикул
Описание
12
VALVE (3/2-WAY SOLENOID VALVE) EKS
12
VALVE , Replaced By: A0049975736
12
VALVE SOLENOID VALVE,5 450429 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
18
VALVE PARTTO 004 997 00 36,5 757289 AUSSERDEM EINGEBAUT IN 5 759173
24
PROTECTIVE CAPWABCO
30
SEAL RING VALVE TO VALVE
36
SEAL RINGWABCO
45
SCREW TO PLUG THE FREE CONNECTIONS
48
SEAL RINGBOSCH
54
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
66
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
78
WASHER EXHAUST MUFFLER TO STRAP
78
WASHER , Replaced By: N000125008443
90
FITTING LINE CONNECTION
102
SEAL RING 3/2-WAY VALVE
114
SCREW. UNION SCREW LINE CONNECTION
114
SCREW. UNION SCREW , Replaced By: A0009973734
117
LOCK LINE CONNECTION
117
LOCK , Replaced By: A0009945448
210
VALVE QUICK-RELEASE
216
SEAL RINGWABCO
222
DIAPHRAGMWABCO
234
REPAIR KIT
246
VALVE PRESSURE LIMIT
258
SCREW PIPE CLAMP
270
WASHER TRAILER PLUG SOCKET TO BRACKET
282
FITTING CHECK VALVE
282
FITTING LINE CONNECTION
310
FITTING TWO-WAY VALVE
310
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
324
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "23"
340
PLUG DISTRIBUTOR,CONNECTION: "11",5 411349
360
NUT CHECK VALVE TO AIR RESERVOIR
372
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
384
O-RING CHECK VALVE TO AIR RESERVOIR
396
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
408
SCREW. UNION SCREW LINE CONNECTION
410
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
444
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
456
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
468
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
480
SWITCH EXHAUST BRAKE
514
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
526
SCREW. UNION SCREW LINE CONNECTION
540
FITTING QUICK BREATHER VALVE,REAR, CONNECTION: "23"
550
FITTING BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
560
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
570
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
580
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
