Поз.
Артикул
Описание
5
BRACKET
8
BRACKET FENDER
11
BRACKET BRACKET TO AXLE HOUSING
26
CLAMP ,K 147121, Replaced By: N000000000319
26
CLAMP LINES TO BRACKET
26
CLAMP LINE MOUNTING
26
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
26
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
35
SCREW CAB FLOOR COVERING M 6X25
41
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
41
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
41
SCREW , Replaced By: N304017008039
41
SCREW , Replaced By: N304017008016
44
SCREW , Replaced By: N304017008021
44
SCREW PIPE CLAMP
50
SCREW TAIL LAMP TO BRACKET
56
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
56
WASHER COMPRESSED AIR LINE TO BRACKET
56
WASHER , Replaced By: N009021006208
59
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
62
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
68
NUT PUMP TO BRACKET
68
NUT , Replaced By: N913004006001
71
NUT , Replaced By: N913004008001
74
LOOM TIE LINE MOUNTING
86
BRAKE HOSE BETWEEN THE LINES
89
FITTING BRAKE HOSE TO FITTING
92
T-FITTING REAR AXLE BRAKE CIRCUIT
96
THRUST RING COMPRESSED AIR LINE TO AIR RESERVOIR AND TO T-FITTING
98
SEAL RING TO 18-MM-DIA. COMPRESSED AIR LINES
101
NUT CHECK VALVE TO AIR RESERVOIR
104
WASHER
107
BRAKE HOSE FROM TWO-WAY VALVE TO CONNECTION FITTING
107
BRAKE HOSE , Replaced By: A0004299435
108
NUT BRACKET TO SIDE MEMBER
109
WASHER COILED TUBE TO BRAKE LINE COUPLING SUPPORT
110
FITTING (PARTS KIT),LINE RUPTURE
113
BRAKE HOSE RETARDER
113
BRAKE HOSE SPRING-LOAD ACCUMULATOR CYLINDER TWOWAY VALVE,LEFT
119
FITTING HYDRAULIC LINE TO BRACKET,K 130132
122
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
125
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
125
WASHER , Replaced By: N000125015019
999
BRAKE HOSE FROM AIR COMPRESSOR TO PRESSURE REGULATOR
999
FITTING BRAKE HOSE TO COMPRESSED AIR LINE
999
BRACKET LEFT BRAKE HOSE, IN CASE OF CAST AXLE
999
MUFFLER AT AIR COMPRESSOR
999
SCREW , Replaced By: N304017008016
999
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
