L 1113 B
358.004
42 BRAKE SYSTEM
001 TWO-LINE TRAILER BRAKE AND SPRING-LOAD ACCUMULATOR BRAKE CYLINDER USED WITH TWO- IL.3

Mercedes A0025450628 - КЛЕММА

L 1113 B 358.004

42 BRAKE SYSTEM - 001 TWO-LINE TRAILER BRAKE AND SPRING-LOAD ACCUMULATOR BRAKE CYLINDER USED WITH TWO- IL.3

Поз.
Артикул
Описание
1
A0045428110
TACHOGRAPH
1
A0045428210
TACHOGRAPH
3
A0005420051
SPACER RING
5
A3025402637
ELECTRIC CABLE FROM TACOGRAPH PLUG CONNECTION TO TACHOGRAPH
7
A0025451228
PLUG HOUSING 4-POLE
9
A0025450628
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
10
A0005453726
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
12
A0005451645
BOOT PIN BUSHING
999
A0075458226
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
999
A0015458628
PLUG LESS DETENT,BUT WITH CATCH FOR HOUSING 2.5 MM2
999
A0005453826
PIN BUSHING , Replaced By: A0075458226
