Поз.
Артикул
Описание
47
RELAY DECLUTCHING START UNIT, UP TO IDENT NO. 002373 EXCEPT FOR SEE FOOTN. 23, ALSO INSTALLED ON SEE FOOTN. 24
47
RELAY DECLUTCHING START UNIT
50
TAPPING SCREW RELAY
53
LOCK WASHER LINE MOUNTING
182
BRACKET FUSE BOX,004991
185
FUSE BOX
188
FUSE BOX
191
FUSE BOX 4-POLE
194
COMBINATION BOLT ELECTRIC CABLE TO FUSE BOX
197
FUSE , Replaced By: N072581008101
200
FUSEA16
203
FUSE25 A
203
FUSE , Replaced By: A0015457534
203
FUSE FUSE BOX A 25
206
SCREW COMPRESSED AIR LINE BELOW BATTERY BRACKET
209
LOCK WASHER LINE MOUNTING
212
HEX. NUT M 5 DIN 934-5 S. NUT PLUG SOCKET TO FRAME
747
RELAY OIL PRESSURE GAUGE ECONOMY SWITCHING
750
RESISTOR CHARGE CONTROL,4 477131
753
COMBINATION BOLT , USED WITH HYDRAULIC BRAKE UP TO CHASSIS 209475 EXCEPT FOR 209273,209446,209461,209465,209471,209474.
759
DIODETYP: AK 336.7
762
LOCK WASHER BRACKET TO STEERING COLUMN END
762
LOCK WASHER T-FITTING TO BRACKET
765
SCREW RELAY TO BRACKET M 5X12
768
SHEET METAL SCREW HAZARD WARNING LIGHT SENDER UNIT AND AUDIBLE WARNER TO FUSE BOX SIDE PANEL,209088
771
LOCK , Replaced By: A0029948145
771
LOCK INSTRUMENT PANEL TO PANELLING
774
SENDER UNIT HAZARD WARNING LIGHT 24 V
774
SENDER UNIT HAZARD WARNING LIGHT 24 V
777
LOCK HAZARD WARNING LIGHT SENDER UNIT AND AUDIBLE WARNER TO FUSE BOX SIDE PANEL,209088
800
SHEET METAL SCREW HAZARD WARNING LIGHT SENDER UNIT AND AUDIBLE WARNER TO FUSE BOX SIDE PANEL,209088
878
SCREW BRACKET TO CROSS CONNECTION STRUT
878
SCREW MOUNTING CLAMP TO BRACKET AND TO FRAME
881
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
884
NUT
884
NUT BATTERY CASE
887
HORN , Replaced By: A0025426820
887
HORN , Replaced By: A0025426720
887
HORN , Replaced By: A0045424420
887
HORN , Replaced By: A0045422920
887
HORN
887
HORN
887
HORN
887
HORN , Replaced By: A0045423020
887
HORN , Replaced By: A0045424520
890
SCREW BRACKET TO SIDE MEMBER
890
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
890
SCREW , Replaced By: N304017010002
890
SCREW SWITCH TO BRACKET 8X16
893
WASHER TRANSMISSION TO INTERMEDIATE RING
896
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
896
LOCK WASHER REINFORCEMENT ANGLE TO SIDE MEMBER, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
899
NUT BRACKET TO SUPPORT AND TO END PIECE
899
NUT BATTERY CASE
899
NUT BATTERY CABLE
899
NUT
902
LOCK WASHER T-FITTING TO BRACKET
903
SWITCH , Replaced By: A0015452809
903
SWITCH , Replaced By: A0015451209
903
SWITCH , Replaced By: A0005459109
903
SWITCH LIMITATION OF ENGINE SPEED
904
SEAL RING LINE CONNECTION
905
NUT
906
SCREWR & S, M 4X8
907
SWITCH (FOOT-OPERATED SWITCH),5 220372
908
SWITCH EXHAUST BRAKE
947
SWITCH
999
ELECTRIC CABLE , Replaced By: A6735460013
999
ELECTRIC CABLE FROM BATTERY TO BATTERY SUPPORT, ORDER BY THE METER
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCK WASHER T-FITTING TO BRACKET
999
LOCK WASHER WIPER PULSE SENDER UNIT
999
CLAMP MAIN CABLE HARNESS 20 MM
999
CLAMP WIRE CABLE TO CAB
999
CLAMP
999
CLAMP WATER TEMPERATURE GAUGE CABLE TO FIRE WALL
999
CABLE SHOE BATTERY CABLE 10-70 MM
999
CABLE SHOEA 10-35
999
CABLE SHOE NEG. CABLE
999
CABLE SHOE6 - 25 MM
999
SCREW , Replaced By: N000000001145
999
SCREW REGULATOR AND CUT-OUT M 6X12
999
SCREW HOOK TO BRACKET
999
SCREW STEP SWITCH
999
SCREW ELECTRIC CABLE TO PIPE BEND
999
SCREW ELECTRIC CABLE TO FUSE BOX
999
SCREW WIPER PULSE SENDER UNIT TO APPARATUS PLATE
999
SCREW , Replaced By: N007985004107
999
SHEET METAL SCREW BRACKET TO CAB
999
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
NUT TACHOGRAPH TO BRACKET
999
WASHER , Replaced By: N000125008443
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
SCREW BRACKET TO CONTACT PLATE M 4X8,A 061071
999
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
999
BOOT CABLE HARNESS EXTENSION
999
PLUG SOCKET PRESSURE SWITCH SCREW-CONNECTION TO M 24X1
999
LOOM TIE
999
LOOM TIE COMPRESSED AIR LINE MOUNTING
999
GROMMET
999
NUTTO A 373 542 01 17,209099
999
COILTO 3735427021
999
AIR HORN
999
VALVETO 3735427021
999
AIR HORN
999
999
999
999
BRACKET FUSE BOX
999
GROMMET
999
GROMMET , Replaced By: A3359970081
999
CLAMP , Replaced By: A1109950401
999
CLAMP MAIN CABLE HARNESS
999
CLAMP , Replaced By: A3205465175
999
NEG. CABLE , Replaced By: N922002070000, +002N046234010007
999
POS.CABLE. POSITIVE CABLE , FOR THE NEW PART NO.,SEE STANDARD VERSION, Replaced By: N072551070880, +001N072332013100, +001N072332013200
999
NEG. CABLE , Replaced By: N922002070000, +001N046234010007, +001N072332013200
999
NUT , Replaced By: A0009903654
999
NUT , Replaced By: A0009902054
999
CLAMP FLEXIBLE SHAFT
999
CLAMP
999
TACHOGRAPH
999
LENS PARKING BRAKE,008096
999
SWITCH,AUTOMATIC , Replaced By: A0055459024
999
LENS HIGH BEAM
999
TELL-TALE LAMP. LENS CHARGE CONTROL
999
SWITCH STARTING AT ENGINE
999
PIN BUSHING HOUSING 3-POLE,4 483482
999
SWITCH DOOR CONTROL
999
RELAY AT APPARATUS PLATE 50 A
999
ROUND PIN BUSHING REAR "ENR" SOLENOID VALVE BRANCH-OFF 0.75-2.5MM2
999
SWITCH , Replaced By: A0035452314
999
SWITCH SIGN BOX LIGHTING AND FOGLAMPS,215254
999
LENS RETARDER
999
LENS TIRE PRESSURE
999
TELL-TALE LAMP , Replaced By: A0005451630, +001A0005452319
999
SWITCH , Replaced By: A0015454914
999
GROMMET BATTERY CABLE TO BATTERY MASTER SWITCH
999
GROMMET HOSE LINE PROTECTION TO 000 546 16 30,71 30
999
GROMMET4.0 MM
999
WASHER PRESSURE SWITCH SCREW-CONNECTION TO M 24X1,5 129167
999
NUT PRESSURE SWITCH SCREW-CONNECTION M 24X1,5 129167
999
SWITCH (FOOT-OPERATED SWITCH),5 220373
999
PLUG SOCKET , Replaced By: A0005454426
999
SWITCH , Replaced By: A0025456014
999
SWITCH , Replaced By: A0005458009
999
PLUG SOCKET , Replaced By: A0005454426
999
BUTTON , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO CHASSIS 027345, Replaced By: A0005454937
999
BOOT SWITCH TO 001 545 46 14
999
LENS TRUCK-TRACTOR BLINKER,008096
999
CONNECTION PLATE
999
DIAGRAM PAPER SET100 PIECES
999
CONNECTOR FLEXIBLE SHAFT
999
COUPLER FLEXIBLE SHAFT
