Поз.
Артикул
Описание
15
AIR DEHYDRATOR WITH HEATING KNORR
15
AIR DRIER WITH PRESSURE REGULATOR AND HEATING
15
AIR DEHYDRATOR WITH PRESSURE REGULATOR AND HEATING WABCO, 6.12
15
15
15
AIR DEHYDRATOR WITH PRESSURE REGULATOR AND HEATING KNORR, 6.12
15
AIR DEHYDRATOR WITH PRESSURE REGULATOR WITHOUT HEATING KNORR, 6.12,V 207570V 213867
15
AIR DEHYDRATOR WITH PRESSURE REGULATOR AND HEATING KNORR6.12, FOR COMPONENT PARTS SEE SPARE PARTS LIST
18
REPAIR KIT. AIR CLEANERTO 693 420 75 71
18
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
18
AIR CLEANER COMPLETE TO BOSCH,KNORR
20
REPAIR KIT. AIR CLEANERTO 693 420 75 71
20
AIR CLEANER WITH OIL SEPARATOR WABCO
20
AIR CLEANER WITH OIL SEPARATOR KNORR
21
HEATER PARTS KIT WABCO
21
HEATER PARTS KIT KNORR
30
TEST CONNECTIONWABCO
35
PARTS KIT PRESSURE REGULATOR TO 693 420 73 71,75 71
40
BOOT ON AIR DRIER
40
PLUG
45
REPAIR KIT AIR DEHYDRATOR WABCO
45
REPAIR KITTO 695 430 15 15
45
REPAIR KIT AIR DEHYDRATOR KNORR
50
PARTS KIT AIR DEHYDRATOR,CONNECTION: "30", KNORR
55
GASKET KIT AIR DEHYDRATOR TO 693 420 75 71
60
SEAL RING FOUR-CIRCUIT PROTECTION VALVE TO AIRDRIER KNORR
60
DS PROTECTION VALVE FOUR-CIRCUIT PROTECTION VALVE TO AIRDRIER KNORR
65
SEAL RINGTO 693 420 73 71
70
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) KNORR, 4.05
70
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO, FOR COMPONENT PARTS SEE SPARE PARTS LIST
70
VALVE , Replaced By: A0034316806
72
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) KNORR
75
75
SENDER UNIT , Replaced By: A0035427418
75
SENDER UNIT AT FOUR-CIRCUIT PROTECTIVE VALVE WABCO, Replaced By: A0004303907
75
PRESSURE SENSOR AT FOUR-CIRCUIT PROTECTIVE VALVE
78
ATTACHMENT PARTS KIT
80
SEAL RING SENDER UNIT WABCO
85
SEAL RING CHECK VALVE WABCO
90
REPAIR KIT CHECK VALVE AT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
90
100
HEXAGON HEAD BOLT AIR DEHYDRATOR TO BRACKET M12X55,V 207570
100
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
105
NUT BRACKET TO SIDE MEMBER M12X1.5
120
120
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
123
THRUST RING CHECK VALVE TO AIR RESERVOIR
126
O-RING CHECK VALVE TO AIR RESERVOIR
130
SCREW PLUG , Replaced By: N000908012009
133
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
133
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
136
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
140
SCREW. UNION SCREW LINE CONNECTION
140
SCREW. UNION SCREW LINE CONNECTION
140
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
140
SCREW. UNION SCREW , Replaced By: A0009973734
140
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M16, VOSS 232
143
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
143
SEAL RING , Replaced By: A0009940747
143
LOCK RING LINE CONNECTION
146
LOCK , Replaced By: A0009945448
146
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
146
LOCK LINE CONNECTION
170
MUFFLER , Replaced By: A0004302970
170
MUFFLER AIR DEHYDRATOR,CONNECTION: "30"
175
SEAL RING MUFFLER
180
SCREW PLUG AIR RESERVOIR
190
SCREW. UNION SCREW LINE CONNECTION
190
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 22, VOSS 232
