Поз.
Артикул
Описание
59
OIL LINE TURBOCHARGER
59
OIL LINE , Replaced By: A3761800120
68
GASKET FLANGE TO TURBOCHARGER
77
SCREW PULLEY
86
SEAL RING
89
INTERMEDIATE PIECE EXTENSIBLE BRAKE VALVE,CONNECTIONS: "10,20"
89
SCREW PLUG (REDUCTION FITTING),OIL DELIVERY LINE CONNECTION M 22X1.5, M 14X15
95
HOLLOW SCREW
96
BRACKET OIL LINE TO TURBO-CHARGER
98
BEFESTIGUNGSSCHELLE. CLAMP LINES TO ENGINE
101
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
102
WASHER BRACKET TO INJECTION PUMP
103
LOCK WASHER CLAMP TO BRACKET
104
NUT
107
OIL LINE INJECTION PUMP LUBRICATION
110
SEAL RING BRAKE CYLINDER STROKE INDICATOR
113
HOLLOW SCREW COMPRESSED AIR LINE TO OPERATING CYLINDER
116
OIL LINE OIL RETURN LINE,670364
116
OIL LINE OIL RETURN LINE,670363
119
GASKET OIL RETURN LINE TO TURBOCHARGER
119
GASKET OIL RETURN LINE TO TURBOCHARGER
122
SCREW BRACKET TO INTAKE MANIFOLD
131
PIPE ELBOW OIL RETURN LINE TO CYLINDER CRANKCASE,585512
134
NUT , Replaced By: N080705026003
137
CLAMP ,B 862667
137
CLAMP , Replaced By: A0069970490
137
LOOM TIE BREATHER VALVE
140
HOSE FROM RETURN LINE CONNECTION TO CYLINDER CRANKCASE, UP TO ENGINE 230907 YEAR OF MANUFACTURE 1992 FROM ENGINE 432714 YEAR OF MANUFACTURE 1996
140
HOSE FROM RETURN LINE CONNECTION TO CYLINDER CRANKCASE, ORDER BY THE METER FROM ENGINE 230908 YEAR OF MANUFACTURE 1992 UP TO ENGINE 432713 YEAR OF MANUFACTURE 1996
146
OIL LINE LUBRICATION OF AIR COMPRESSOR AND INJECTION PUMP
149
OIL LINE OIL RETURN LINE AIR COMPRESSOR IN CENTRAL HOUSING
152
LOOM TIE. CLAMP HOSE TO FLANGE AND TO VALVE
152
CLAMP HOSE TO HEATING PIPE
152
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
152
CLAMP PRESSURE REGULATOR
152
LOOM TIE , Replaced By: N916017020000
152
CLAMP , Replaced By: N000000000667
155
BRACKET BRACKET TO FUEL FILTER
