Поз.
Артикул
Описание
408
GROMMET GROUND CABLE
416
T-FITTING COMPRESSED AIR VALVE CONNECTION
424
VALVE (OVERFLOW VALVE)
424
VALVE (OVERFLOW VALVE)
424
VALVE
424
VALVE (OVERFLOW VALVE)
432
VALVE
432
VALVE
440
DIAPHRAGM
440
DIAPHRAGMTO 000 429 63 44
464
SPRINGTO 000 429 63 44,000 429 59 44
472
SPRING RETAINERTO 000 429 63 44,000 429 59 44
480
REPAIR KITTO 000 429 63 44,000 429 59 44
480
REPAIR KITBOSCH
480
REPAIR KITTO 001 429 52 44
488
FITTING BRAKE LINE COUPLING,CONNECTION: "11,12"
496
FITTING TWO-WAY VALVE "12",4 4121264 691315
504
SEAL RING LINE CONNECTION
512
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
520
SCREW PLUG , Replaced By: N007604014110
528
GLAND , Replaced By: A0019901667
536
SLEEVE LEAK LINE
544
UNION NUT
552
HOLLOW SCREW
560
SEALING RING. SEAL RING ENGINE BREATHING
568
VALVE"WESTINGHOUSE"
568
VALVE"WABCO DO BRASIL"
576
HANDLETO 000 434 24 01
584
CUP 3/2-WAY VALVE WABCO
592
PROTECTIVE CAPTO 000 434 08 01,345 434 71 01
600
SEAL RINGTO 000 434 23 01
608
CLEANERTO 000 434 22 01
616
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
616
REPAIR KIT SMALL SCOPE TO 345 434 71 01
616
REPAIR KIT 3/2-WAY VALVE WABCO
616
REPAIR KIT , Replaced By: A0034301281
624
GROMMET
640
CONNECTOR SOLENOID VALVE,CONNECTION: "2" TOA388 997 81 36 / 88 36
648
SEAL RING LINE CONNECTION
656
PROTECTIVE PLATE OPERATING VALVE TO SIDE MEMBER SHELL
664
SPRING WASHER AT CAB FLOOR
672
NUT , Replaced By: N080705026003
680
LINE FROM DOUBLE FITTING TO BRAKE VALVE
688
UNION NUT
696
GLAND , Replaced By: A0019901667
704
HOSE PRESSURE GAUGE
712
ELBOW FITTING AT CYLINDER
712
ELBOW FITTING TEST CONNECTION TO BRACKET
720
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
728
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
728
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
736
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
744
LOOM TIE , Replaced By: A0019978390
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
999
BALL PIVOT
