Поз.
Артикул
Описание
2
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
4
UNION NUT LINE CONNECTION
4
UNION NUT , Replaced By: N915017008100
6
GLAND LINE CONNECTION
8
SLEEVE LINE CONNECTION
8
SLEEVE , Replaced By: N915062006000
10
BANJO UNION HEATING CONNECTION,K 169122
10
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
12
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
12
HOSE , Replaced By: A0009872827
14
UNION NUT LINE CONNECTION, Replaced By: N000000006239
14
UNION NUT , Replaced By: N915017012100
14
UNION NUT LINE CONNECTION
16
SEAL CONE LINE CONNECTION
16
GLAND , Replaced By: A0019901967
18
BUSHING , Replaced By: N915062009000
18
SLEEVE LINE CONNECTION
19
PLASTIC PIPE RISING PIPE 4X6 MM
19
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
20
LINE FROM FOUR-CIRCUIT PROTECTIVE VALVE TO AIR RESERVOIR 9X12 MM, LENGTH AVAILABLE 3000 MM
22
BANJO UNION , Replaced By: N000000000364
22
BANJO UNION HOSE WIDTH, / I.D., 4/14 MM,K 169123
25
GLAND , Replaced By: A0019901667
25
SEAL CONE
28
SLEEVE LEAK LINE
31
UNION NUT
31
UNION NUT LINE CONNECTION
31
UNION NUT LINE CONNECTION, Replaced By: N000000006239
34
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
37
SEAL CONE
37
SEAL CONE LINE CONNECTION
37
GLAND , Replaced By: A0019901967
37
GLAND , Replaced By: A0019901667
40
UNION NUT
41
T-FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
42
FITTING DELIVERY LINE TO PUMP
43
SLEEVE LEAK LINE
46
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
47
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
49
VALVE , Replaced By: A0024295344
49
VALVE , Replaced By: A0054290644
52
HANDLE 3/2-WAY
55
REPAIR KITTO 002 429 53 44
58
ELBOW FITTING ,4 412125
61
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
64
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
67
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
70
HOLLOW SCREW FUEL LINE TO FEED PUMP
70
HOLLOW SCREW , Replaced By: N915036010108
70
HOLLOW SCREW , Replaced By: N915036010100
73
SEAL RING FUEL LINE TO FEED PUMP
76
FITTING 3/2-WAY VALVE,CONNECTION: "30"
79
SEAL RING PNEUMATIC VALVE
79
SEAL RING , Replaced By: N007603010110
82
SCREW HOOK TO BRACKET
85
WASHER , Replaced By: N000433005304
85
WASHER BOOT TO CAB FLOOR
88
HOLLOW SCREW HEATING CONNECTION
91
SEAL RING LINE CONNECTION
94
NUT CHECK VALVE TO AIR RESERVOIR
97
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
97
THRUST RING CHECK VALVE TO AIR RESERVOIR
100
O-RING CHECK VALVE TO AIR RESERVOIR
103
T-FITTING RIGHT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
106
FITTING SPRING LOAD ACCUMULATOR CYLINDER,4 412126
106
T-FITTING. FITTING AT INJECTION PUMP
109
SWITCH SUPPLY PRESSURE,5 966147
112
CROSS FITTING LEFT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
112
ELBOW FITTING DELIVERY LINE TO PUMP
113
T-FITTING RIGHT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
115
CROSS FITTING LEFT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
118
VALVE BODYTO 002 429 95 44
118
VALVE TWO-WAY VOSS
118
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
121
BALLTO 003 429 22 44
124
VALVE TWO-WAY VOSS
124
GASKETTO 003 429 22 44
127
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
128
FITTING SHUTTLE VALVE
128
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
128
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
130
NUT CHECK VALVE TO AIR RESERVOIR
131
THRUST RING CHECK VALVE TO AIR RESERVOIR
131
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
133
O-RING CHECK VALVE TO AIR RESERVOIR
135
CROSS FITTING AT LEFT TRISTOP CYLINDER
136
SWITCH SUPPLY PRESSURE,5 966147
137
FITTING AT RIGHT TRISTOP CYLINDER
138
HOLLOW SCREW , Replaced By: N915036010108
138
HOLLOW SCREW FUEL LINE TO FEED PUMP
139
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
139
FITTING , Replaced By: A0009970171
139
FITTING , Replaced By: A0019970172
142
ELBOW FITTING TWO-WAY VALVE,CONNECTION "1.2"
145
NUT CHECK VALVE TO AIR RESERVOIR
148
THRUST RING CHECK VALVE TO AIR RESERVOIR
148
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
151
O-RING CHECK VALVE TO AIR RESERVOIR
153
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0024299544
154
VALVE BODYTO 002 429 95 44
155
BALLTO 003 429 22 44
156
GASKETTO 003 429 22 44
157
NUT CHECK VALVE TO AIR RESERVOIR
160
THRUST RING CHECK VALVE TO AIR RESERVOIR
160
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
163
O-RING CHECK VALVE TO AIR RESERVOIR
166
ELBOW FITTING AIR RESERVOIR,CONNECTIONS: "31,32"
169
NUT CHECK VALVE TO AIR RESERVOIR
172
THRUST RING CHECK VALVE TO AIR RESERVOIR
172
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
175
O-RING CHECK VALVE TO AIR RESERVOIR
178
HOLLOW SCREW FUEL LINE TO FEED PUMP
178
HOLLOW SCREW , Replaced By: N915036010108
178
HOLLOW SCREW , Replaced By: N915036010100
184
SEAL RING FUEL LINE TO FEED PUMP
187
O-RING CHECK VALVE TO AIR RESERVOIR
190
BRACKET TWO-WAY VALVE
193
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
193
SCREW , Replaced By: N304017008027
196
FITTING BRAKE LINE COUPLING TO BRACKET
199
THRUST RING CHECK VALVE TO AIR RESERVOIR
199
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
202
O-RING CHECK VALVE TO AIR RESERVOIR
205
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
208
SWITCH SUPPLY PRESSURE,5 966147
999
FITTING ,4 667210
999
CONNECTION FITTING , Replaced By: A0039979172
999
UNION NUT , Replaced By: N915017012100
999
FITTING , Replaced By: A0009970171
999
FITTING , Replaced By: A0019970172
999
BUSHING , Replaced By: N915062004000
999
ELBOW FITTING , Replaced By: A0019904371
999
BANJO UNION , Replaced By: N915052006005
999
VALVE , Replaced By: A0004291182
999
VALVE , Replaced By: A0004290782
