Поз.
Артикул
Описание
141
LINE FROM MASTER CYLINDER TO FRONT AXLE TEST CONNECTION 900 MM
143
GROMMET FUEL LINE THRU FRAME SIDE MEMBER,4 367061
144
GROMMET OIL DELIVERY LINE THRU FENDER SUPPORT
145
GROMMET BATTERY CABLE THRU SIDE MEMBER
148
TEST CONNECTION FRONT AXLE
148
TEST CONNECTION FRONT AXLE
149
SCREW BRACKET TO CROSS CONNECTION STRUT
149
SCREW , Replaced By: N304017008034
150
NUT , Replaced By: N913004008001
150
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
151
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
153
LINE FROM TEST CONNECTION TO LEFT FRONT WHEEL BRAKE HOSE 1300 MM
153
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 2200 MM,4 478329
155
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 1700 MM,4 478329
155
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL BRAKE HOSE
157
BRACKET DELIVERY AND SUCTION LINES
157
BRACKET , Replaced By: A3812711640
158
SCREW , Replaced By: N304017008016
158
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
159
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
160
GROMMET LINE MOUNTING 19/13 MM
165
BRACKET RIGHT FRONT BRAKE HOSE TO FRONT AXLE
165
BRACKET LEFT FRONT BRAKE HOSE TO FRONT AXLE
167
SCREW PIPE CLAMP
167
SCREW , Replaced By: N304017008021
168
NUT , Replaced By: N913004008001
168
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
169
CLAMP ,K 147121, Replaced By: N000000000319
169
CLAMP , Replaced By: N916016008200
170
BRAKE HOSE , Replaced By: A0004288935
170
BRAKE HOSE REAR AXLE
170
BRAKE HOSE REAR
170
BRAKE HOSE650 MM
170
BRAKE HOSE650 MM
171
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
171
BRACKET. LOCK , Replaced By: A6525040038
172
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
173
CONNECTOR OIL DELIVERY LINE
174
LINE FROM DISTRIBUTOR TO VALVE 3600 MM,4 478330
175
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
175
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
176
SPACER TUBE BREATHER LINE TO SIDE MEMBER
176
SPACER TUBE TEST CONNECTION TO SIDE MEMBER,5 307198
176
SPACER TUBE , Replaced By: A4409910040
179
SCREW 3/2-WAY VALVE TO BRACKET M 8X105
179
SCREW REAR AXLE REGULATING SOLENOID VALVE
180
WASHER EXHAUST MUFFLER TO STRAP
180
WASHER , Replaced By: N000125008443
181
NUT , Replaced By: N913004008001
181
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
182
LINE FROM DISTRIBUTOR TO VALVE 3200 MM
182
LINE FROM TEST CONNECTION TO BRAKE POWER REGULATOR,CONNECTION "1",4 478495
238
LINE FROM BRAKE POWER REGULATOR TO REAR BRAKE HOSE 500 MM
245
BRACKET BRAKE HOSE,REAR
246
SCREW , Replaced By: N304017008021
246
SCREW PIPE CLAMP
247
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
247
NUT , Replaced By: N913004008001
248
BRAKE HOSE , Replaced By: A0024280735
248
BRAKE HOSE , Replaced By: A0024280735
248
BRAKE HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 424176, Replaced By: A0024280735
248
BRAKE HOSE , Replaced By: A0024280735
248
BRAKE HOSE600 MM
249
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
249
BRACKET. LOCK , Replaced By: A6525040038
250
TEST CONNECTION FRONT AXLE
250
TEST CONNECTION FRONT AXLE
251
SCREW PIPE CLAMP
251
SCREW , Replaced By: N304017008021
252
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
253
ANGLE LINE MOUNTING
254
CLAMP ,K 147121, Replaced By: N000000000319
254
CLAMP , Replaced By: N916016008200
255
CLAMP FEED LINE TO THERMOSTAT
256
SCREW BRACKET TO CROSS CONNECTION STRUT
256
SCREW , Replaced By: N304017008034
257
NUT , Replaced By: N913004008001
257
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
258
SCREW , Replaced By: N304017006020
258
SCREW LICENSE PLATE TO BRACKET
259
NUT , Replaced By: N910113006001
259
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
260
CLAMP BRAKE LINE MOUNTING
261
HOSE BRAKE LINE TO REAR AXLE,4 644238
262
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
262
SCREW , Replaced By: N304017008016
263
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
264
LINE FROM TEST CONNECTION TO LEFT WHEEL CYLINDER 1350 MM,4 644237
265
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 650 MM
999
NUT , Replaced By: N913004008001
999
CLIP , NOT USED
999
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
999
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
999
SCREW BRACKET TO SIDE MEMBER
999
NUT CHECK VALVE TO AIR RESERVOIR
999
SCREW , Replaced By: N304017008040
999
SCREW , Replaced By: N304017008034
999
ADHESIVE FOIL GUIDE SIGN
999
PIN , NOT USED
999
BRACKET , Replaced By: A3604292940
999
NUT RETAINER BRACKET MOUNTING
999
SPHERICAL PIECE , Replaced By: A3025860242
999
SEAL RING
999
SEAL RINGTO 000 431 43 12,000 431 44 12, NO LONGER AVAILABLE
999
SPRING
999
SPRING
999
PLUG
999
NUT RETAINER , Replaced By: A3229900091
999
T-FITTING RELAY VALVE,CONNECTION: "12"
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
FELT STRIPTO 000 431 43 12,000 431 44 12
999
SEAL RING
999
SEAL RINGTO 000 431 43 12,000 431 44 12
999
PISTONTO 000 431 43 12,000 431 44 12
999
GUIDE BUSHINGTO 000 431 43 12,000 431 44 12
999
LEVER
999
LEVER TOOTHED
999
GUIDE BUSHING
999
GUIDE BUSHINGTO 000 431 43 12,000 431 44 12
999
SCREW
999
FILTER BOTTOMTO 000 431 24 14
999
SLIDETO 000 431 50 14,000 431 24 14
999
VALVE , Replaced By: A0004310265
999
ELBOW FITTING
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
