Поз.
Артикул
Описание
95
PLASTIC PIPE RISING PIPE 4X6 MM
95
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
96
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
97
INSULATING HOSE BLACK 10 MM, ORDER BY THE METER
100
UNION NUT
102
SEAL CONE
102
GLAND , Replaced By: A0019901667
103
SLEEVE LEAK LINE
104
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
104
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
105
HOSE LEAK LINE, ORDER BY THE METER
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
ELBOW FITTING
999
VALVE , Replaced By: A0004310265
999
SLIDETO 000 431 50 14,000 431 24 14
999
FILTER BOTTOMTO 000 431 24 14
999
SCREW
999
GUIDE BUSHINGTO 000 431 43 12,000 431 44 12
999
GUIDE BUSHING
999
LEVER TOOTHED
999
LEVER
999
GUIDE BUSHINGTO 000 431 43 12,000 431 44 12
999
PISTONTO 000 431 43 12,000 431 44 12
999
SEAL RINGTO 000 431 43 12,000 431 44 12
999
SEAL RING
999
FELT STRIPTO 000 431 43 12,000 431 44 12
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
T-FITTING RELAY VALVE,CONNECTION: "12"
999
NUT RETAINER , Replaced By: A3229900091
999
PLUG
999
SPRING
999
SPRING
999
SEAL RINGTO 000 431 43 12,000 431 44 12, NO LONGER AVAILABLE
999
SEAL RING
999
SPHERICAL PIECE , Replaced By: A3025860242
999
NUT RETAINER BRACKET MOUNTING
999
BRACKET , Replaced By: A3604292940
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
PIN , NOT USED
999
ADHESIVE FOIL GUIDE SIGN
999
SCREW , Replaced By: N304017008034
999
SCREW , Replaced By: N304017008040
999
NUT CHECK VALVE TO AIR RESERVOIR
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
999
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
999
CLIP , NOT USED
999
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT , Replaced By: N913004008001
