Поз.
Артикул
Описание
5
PLASTIC PIPE RISING PIPE 4X6 MM
5
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
12
BANJO UNION , Replaced By: N915052004006
12
BANJO UNION 3/2-WAY
12
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
14
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
16
BUSHING , Replaced By: N915062004000
16
BUSHING , Replaced By: N915062004000
16
SLEEVE LEAK LINE
17
UNION NUT
18
SEAL CONE
18
GLAND , Replaced By: A0019901667
19
SEAL RING LINE CONNECTION
22
HOLLOW SCREW HEATING CONNECTION
23
HOLLOW SCREW , Replaced By: N915047008100
23
HOLLOW SCREW LINE CONNECTION
26
VALVE 3/2-WAY BOSCH
26
VALVE 3/2-WAY WABCO
26
VALVE 3/2-WAY KNORR
26
VALVE 3/2-WAY VOSS
30
SPRING INSIDE WABCO
34
SEAL RING INSIDE WABCO
38
SEAL RING TOP WABCO
46
SCREW BRACKET TO COVERING
46
SCREW , Replaced By: N000000001145
50
SPRING WASHER LICENSE PLATE TO BRACKET
54
HOLLOW SCREW HEATING CONNECTION
58
SEAL RING LINE CONNECTION
62
VALVE VENT VALVE,4 132790
62
VALVE VENT VALVE,4 132791
70
HANDLE VENT VALVE
74
CLAMPING SLEEVE VENT VALVE
78
REPAIR KIT VENT VALVE TO 001 997 11 36,001 997 92 36
82
SYMBOL PLATE P.T.O. I
86
UNIT IDENTIFICATION PLATE P.T.O.
90
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
92
WASHER AT TWO-WAY VALVE
94
SEAL RING , Replaced By: N007603010110
94
SEAL RING PNEUMATIC VALVE
98
HOLLOW SCREW LINE CONNECTION
102
T-FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
106
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
110
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
110
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
114
SWITCH EXHAUST BRAKE,K 251255
118
SEAL RING LINE CONNECTION
122
SEAL RING , Replaced By: N007603010110
122
SEAL RING PNEUMATIC VALVE
126
FITTING , Replaced By: N915039006100
126
FITTING , Replaced By: N915039008100
126
FITTING , Replaced By: N915040006100
126
FITTING , Replaced By: N915040008100
126
HOLLOW SCREW FITTING AT P.T.O.SHIFTING CYLINDER
126
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
126
HOLLOW SCREW FITTING AT P.T.O.SHIFTING CYLINDER
126
HOLLOW SCREW FITTING AT P.T.O.SHIFTING CYLINDER
142
HOLLOW SCREW HEATING CONNECTION
146
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
150
SEAL RING LINE CONNECTION
154
T-FITTING. FITTING AT INJECTION PUMP
166
FITTING , Replaced By: A0039979072
166
TS DOUBLE FITTING SOLENOID VALVE
166
FITTING , Replaced By: A0029906071
166
DOUBLE FITTING , Replaced By: A0019972872
170
LOOM TIE LINE MOUNTING 280 MM
170
LOOM TIE LINE MOUNTING
999
FITTING , Replaced By: N915039006100
999
FITTING , Replaced By: N915040008100
