Поз.
Артикул
Описание
12
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING POWER PACKER,4 733732
12
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING POWER PACKER,4 733732
12
CYLINDER , Replaced By: A0015533605
12
CYLINDER , Replaced By: A0015533605
16
GUIDE , Replaced By: A0015534905
16
REPAIR KIT , Replaced By: A0005501535
16
GASKET KIT HYDRAULIC CYLINDER POWER PACKER
16
GASKET KIT HYDRAULIC CYLINDER POWER PACKER
20
BEARING BRACKET HYDRAULIC CYLINDER
24
SCREW BEARING BRACKET TO FRAME
24
SCREW , Replaced By: N000961012051
28
SCREW BEARING BRACKET TO SIDE MEMBER M 14X1.5X28
32
LOCK WASHER FITTING TO BRACKET
36
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
40
BUSHING HYDRAULIC CYLINDER TO BEARING BRACKET
44
WASHER HYDRAULIC CYLINDER TO CAB
48
COTTER PIN6,3X36 MM
52
WASHER HYDRAULIC CYLINDER TO CAB
56
WASHER HYDRAULIC CYLINDER TO CAB
60
WASHER HYDRAULIC CYLINDER TO CAB
64
NUT COMBINATION CYLINDER TO BEARING BRACKET
64
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
68
PUMP , Replaced By: A0005537901
68
PUMP (HAND PUMP) WEBER
72
PUMP , Replaced By: A0005536501
72
PUMP (HAND PUMP) POWER PACKER,4 733732
76
PISTONTO 000 553 39 01,WEBER
76
PISTONTO 000 553 23 01,000 553 37 01,
76
PISTONTO 000 553 79 01,WEBER
80
LEVERTO 000 553 37 01,000 553 39 01,WEBER
84
VALVETO 000 553 79 01,WEBER
84
VALVE , Replaced By: A0005501555
88
SEAL RINGTO 000 553 23 01,000 553 37 01,
92
BUSHINGTO 000 553 37 01,000 553 39 01,WEBER
96
SEAL RINGTO 000 553 23 01,000 553 37 01,
100
CLAMPING SLEEVE4X28 MM,TO 000 553 23 01,,4 250876
104
CLAMPING SLEEVE4X12 MM,TO 000 553 23 01,
108
SCREW , Replaced By: N000000000190
108
SCREW
112
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
116
GASKETTO 000 553 23 01,000 553 37 01,
120
FILTER
124
BOOTTO 000 553 23 01,000 553 37 01,
128
SEAL RINGTO 000 553 23 01,000 553 37 01,,4 250876
132
SEAL RINGTO 000 553 23 01,000 553 37 01,
136
SEAL RINGTO 000 553 37 01,000 553 39 01,WEBER,4 250876
140
GASKET KIT HAND PUMP
140
REPAIR KIT VALVE TO 000 553 54 01,POWER-PACKER,4 733732
144
REPAIR KIT PISTON TO 000 553 54 01,POWER-PACKER,4 733732
148
BRACKET HAND PUMP
152
SCREW , Replaced By: N304017010002
152
SCREW BRACKET TO SIDE MEMBER
156
WASHER , Replaced By: N000125010532
156
WASHER RADIATOR TO RUBBER MOUNTING
160
NUT STRAP TO BRACKET
160
NUT , Replaced By: N910113010000
164
LINE FROM FITTING TO VALVE 6X1 MM, LENGTH AVAILABLE 3000 MM
168
UNION NUT
172
GLAND , Replaced By: A0019901667
172
SEAL CONE
176
HOSE FROM HYDRAULIC LINE TO CYLINDER
180
UNION NUT
184
GLAND , Replaced By: A0019901667
184
SEAL CONE
188
T-FITTING. FITTING AT INJECTION PUMP
192
FITTING , Replaced By: A0019909871
192
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
196
GROMMET AT SHOCK ABSORBER BRACKET AND AT FENDER BRACKET
200
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
208
SCREW PIPE CLAMP
208
SCREW , Replaced By: N304017008021
208
SCREW , Replaced By: N304017008027
208
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
212
WASHER , Replaced By: N000125008443
212
WASHER EXHAUST MUFFLER TO STRAP
216
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
216
NUT , Replaced By: N913004008001
220
CLAMP LINE MOUNTING
224
SCREW COVER PLATE TO BRACKET
228
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
232
NUT PUMP TO BRACKET
232
NUT , Replaced By: N913004006001
236
HOSE FROM HAND PUMP TO HYDRAULIC CYLINDER
240
UNION NUT
244
GLAND , Replaced By: A0019901667
244
SEAL CONE
248
FITTING 3/2-WAY VALVE,CONNECTION: "30"
252
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
252
FITTING , Replaced By: A0019909871
256
SEAL RING PNEUMATIC VALVE
256
SEAL RING , Replaced By: N007603010110
272
LOOM TIE LINE MOUNTING
999
SNAP RINGWEBER,TO 000 553 40 01, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
999
SNAP RING
999
SEAL RINGTO 000 553 23 01,000 553 37 01,
999
FITTED WASHER
999
LOCK RING
999
GASKET KIT , Replaced By: A0005502583
999
SCREW
999
GUIDEWEBER,TO 001 553 45 05
999
GUIDETO 001 553 49 05
999
SCREWTO 000 553 65 01,000 553 69 01,
999
GASKET KIT HAND PUMP TO 000 553 37 01,000 553 39 01,WEBER
