Поз.
Артикул
Описание
3
STRUT BUMPER,RIGHT
3
STRUT BUMPER,LEFT
3
STRUT BUMPER AT TORSION BAR
6
BRACKET , Replaced By: A3604292940
6
BRACKET BRAKE LINES
6
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
9
BRACKET BATTERY CABLE MOUNTING,5 193595
9
BRACKET , Replaced By: A3854290540
12
CONSOLE , Replaced By: A3878912631
12
CONSOLE PEDESTAL
15
SCREW , Replaced By: A9429901304
15
SCREW , Replaced By: N308676014012
15
SCREW CONSOLE AND STRUT TO FRAME
15
SCREW BRACKET TO ENGINE MOUNTING
15
SCREW SUPPORT TO SIDE MEMBER M 14X45
15
SCREW APPARATUS SUPPORT TO FRAME
18
WASHER , Replaced By: N000125015019
18
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
21
NUT , Replaced By: N910113014000
21
NUT TORSION BAR TO BEARING BRACKET,5 904661
21
NUT STEERING SUPPORT TO FRAME
21
NUT CAB ON CONSOLE AT FRAME
21
NUT CONSOLE TO SUPPORT
21
NUT , Replaced By: N910113016001
24
MOUNTING RIGHT SIDE MEMBER
24
MOUNTING CAB, RIGHT
24
MOUNTING RIGHT SIDE MEMBER
24
MOUNTING LEFT SIDE MEMBER
24
MOUNTING LEFT SIDE MEMBER
24
MOUNTING , Replaced By: A6558910420
24
MOUNTING CAB,LEFT
24
MOUNTING , Replaced By: A6558910320
27
MOUNTING CAB, RIGHT
27
MOUNTING CAB,LEFT
30
SPRING , Replaced By: A3878910551, +002A3638910617, +001N071412008200
30
SPRING CAB SUSPENSION,FRONT
33
BUSHING SPRING
36
GREASE NIPPLE CAB SUSPENSION,FRONT,4 493779
42
HEADLESS SETSCREW FOR SPRING
45
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
45
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
45
WASHER BEARING BRACKET
51
WASHER TORSION BAR TO BEARING BRACKET, Replaced By: N007349017003
51
WASHER TORSION BAR TO BEARING BRACKET
54
NUT COMBINATION CYLINDER TO BEARING BRACKET
54
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
57
LEVER (TILTING LEVER),CAB
57
LEVER , Replaced By: A3878912756, +002A6208910017
57
LEVER , Replaced By: A3878912856, +002A6208910017
57
LEVER , Replaced By: A3878912556, +002A6208910017
57
LEVER (TILTING LEVER),CAB
57
LEVER , Replaced By: A3878912856, +002A6208910017
57
LEVER , Replaced By: A3878912556, +002A6208910017
57
LEVER , Replaced By: A3878912856, +002A6208910017
57
LEVER (TILTING LEVER),CAB
60
BUSHING TILTING LEVER
60
BUSHING TILTING LEVER
63
JOINT BEARING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
63
JOINT BEARING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
63
JOINT BEARING , Replaced By: A0019814631
63
BUSHING ON TOGGLE LEVER,FOR HYDRAULIC CYLINDER
66
BUFFER TILTING LEVER
66
LOCK , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
67
BUSHING TILTING LEVER
69
BUSHING TILTING LEVER
69
PIN , NO LONGER AVAILABLE, ORDER RANGE OF DELIVERY THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3875860131
72
MOUNTING , Replaced By: A3878905603
72
MOUNTING STABILIZER TO CAB,RIGHT,4 493779
72
MOUNTING , Replaced By: A3878905303
72
MOUNTING ,5 178428, Replaced By: A6218900403, +001A6203100177
72
MOUNTING ,5 178428, Replaced By: A6218900503, +001A6203100177
72
MOUNTING STABILIZER TO CAB,LEFT,5 094188
72
MOUNTING SPRING AND STABILIZER,RIGHT
72
MOUNTING SPRING AND STABILIZER,LEFT
73
PIN
75
BRACKET BUFFER
78
SCREW , Replaced By: N308676012026
78
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
81
SCREW CONSOLE TO SIDE MEMBER
84
NUT SUPPORT TO SIDE MEMBER
87
BUFFER , FIRST EXHAUST STOCK OF OLD PARTS,10/20 UP TO IDENT NO. 4 253140,50/60 UP TO IDENT NO. 4 257207, Replaced By: A3348910072
87
MOUNTING (RUBBER BUFFER)
90
SCREW , Replaced By: N304017008034
93
WASHER BRACKET TO LEFT SIDE MEMBER
93
WASHER , Replaced By: N009021008213
96
NUT , Replaced By: N913004008001
96
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
99
STABILIZER , Replaced By: A3878900404
99
STABILIZER , Replaced By: A3878900404
99
STABILIZER CAB SUSPENSION,FRONT,5 094188
99
STABILIZER CAB SUSPENSION,FRONT
99
STABILIZER , Replaced By: A6528900104
102
GREASE NIPPLE CAB SUSPENSION,FRONT,4 493779
105
BUSHING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3875860531
105
MOUNTING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3875860531
105
SCREW PLUG STABILIZER
108
JOINT BEARING
108
JOINT BEARING , Replaced By: A0009817331
108
JOINT BEARING , Replaced By: A0019814631
108
JOINT BEARING
108
JOINT BEARING , Replaced By: A0009817231
108
JOINT BEARING , Replaced By: A0009817231
109
GREASE NIPPLE CAB SUSPENSION,FRONT,4 493779
110
SCREW PLUG STABILIZER
111
CONSOLE CAB SUSPENSION,FRONT RIGHT
111
CONSOLE , Replaced By: A6208910631
111
CONSOLE , Replaced By: A6208910731
111
CONSOLE CAB SUSPENSION,FRONT LEFT
123
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
123
SCREW , Replaced By: N308676012015
123
SCREW , Replaced By: N308676012011
123
SCREW , Replaced By: N308676012031
123
SCREW LEFT AND RIGHT CONSOLES TO CAB
126
SCREW LEFT AND RIGHT CONSOLES TO CAB M 12X30
126
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
129
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
129
SCREW , Replaced By: N308676014020
132
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
132
SCREW BRACKET TO CAB CONSOLE,K 035197
135
LOCK WASHER FITTING TO BRACKET
138
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
141
WASHER LEFT AND RIGHT CONSOLES TO CAB
145
SCREW STABILIZER TO BEARING
147
NUT , Replaced By: N910113014001
147
NUT BRACKET TO SIDE MEMBER
150
WASHER BRACKET TO SIDE MEMBER,5 703114
153
NUT , Replaced By: N910113014001
153
NUT BRACKET TO SIDE MEMBER
156
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
156
WASHER , Replaced By: N000125015019
158
SCREW BRACKET TO SIDE MEMBER
158
SCREW , Replaced By: N000961014064
159
NUT BRACKET TO SIDE MEMBER
159
NUT , Replaced By: N910113014001
161
WASHER BRACKET TO SIDE MEMBER,5 703114
161
SCREW STABILIZER TO BEARING
162
WASHER STABILIZER TO BEARING
165
SCREW BRACKET TO CAB CONSOLE,K 035197
165
SCREW , Replaced By: N308676014020
165
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
168
SCREW BEARING BRACKET TO CAB M 14X35
168
SCREW FRONT SPRING REAR BRACKET TO SIDE MEMBER M 14X1.5X75
168
SCREW BEARING BRACKET TO CAB M 14X35
168
SCREW , Replaced By: N000961014148
171
WASHER SPARE WHEEL CARRIER
174
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
177
SCREW , Replaced By: N304017008034
180
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
180
NUT , Replaced By: N913004008001
183
SHOCK ABSORBER CAB SUSPENSION,REAR,4 330046
183
SHOCK ABSORBER , Replaced By: A0008911805
183
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
183
SHOCK ABSORBER CAB SUSPENSION,REAR,4 330046
186
BUSHING ,4 330046
186
BUSHING , Replaced By: A0008910117
186
BUSHING , Replaced By: A0008910617
186
BUSHING
189
RUBBER MOUNTING , Replaced By: A0008910501
189
RUBBER MOUNTING
189
RUBBER MOUNTING , Replaced By: A0008910001
189
RUBBER MOUNTING ,4 330046
192
WASHER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A6203170176
192
WASHER SHOCK ABSORBER TO CAB,4 172502 10/20 UP TO IDENT NO. 4 253140,50/60 UP TO IDENT NO. 4 257207
192
WASHER SHOCK ABSORBER TO CAB,4 172501
192
WASHER VIBRATION ABSORBER TO BEARING AND TO CAB
195
WASHER
195
WASHER RADIATOR TO RUBBER MOUNTING
195
WASHER , Replaced By: N000125013008
195
WASHER , Replaced By: N000125010532
198
NUT SUPPORT TO SIDE MEMBER
198
NUT , Replaced By: N910113010000
198
NUT STRAP TO BRACKET
201
MOUNTING CAB TILTING LEVER
201
MOUNTING , Replaced By: A3878913220
201
MOUNTING , MODEL 416,417 FOR USE WITH MEDIUM-LENGTH MERCEDES-BENZ CAB FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 837892, Replaced By: A6208901603
210
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
210
SCREW , Replaced By: N308676012012
210
HEXAGON HEAD BOLT BRACKET TO TRANSMISSION
210
SCREW BRACKET TO TRANSMISSION CASE
210
SCREW END PIECE TO EXHAUST PIPE M 10X25
213
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
213
LOCK WASHER FITTING TO BRACKET
216
SCREW , Replaced By: N308676012012
216
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
219
LOCK WASHER FITTING TO BRACKET
222
SHIM , Replaced By: A3878910498
222
SHIM MOUNTING TO CONSOLE
223
SHIM STRUT TO CONSOLE
225
SCREW MOUNTING TO CONSOLE M 14X35
225
SCREW HYDRAULIC CYLINDER BEARING BRACKET TO FRAME M 16X25
225
SCREW , Replaced By: N308676014008
225
SHIM , Replaced By: A3878910498
225
SCREW BRACKET TO SUPPORT
228
DOWEL PIN MOUNTING TO CONSOLE
231
SHIM , Replaced By: A3878910498
231
SHIM MOUNTING TO CONSOLE
234
SCREW STEERING SUPPORT TO FRAME M 14X55
234
SCREW , Replaced By: A9429901304
234
SCREW APPARATUS SUPPORT TO FRAME
237
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
