Поз.
Артикул
Описание
2
PLASTIC PIPE RISING PIPE 4X6 MM
2
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
2
HOSE FROM WARNING INDICATOR TO AIR CLEANER, ORDER BY THE METER
4
UNION NUT
6
SEAL CONE
6
GLAND , Replaced By: A0019901667
8
SLEEVE LEAK LINE
8
BUSHING , Replaced By: N915062004000
10
BANJO UNION , Replaced By: N915052004006
10
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
12
BANJO UNION , Replaced By: N915052004003
12
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
14
LOOM TIE LINE MOUNTING 280 MM
16
HOLLOW SCREW LINE CONNECTION
18
HOLLOW SCREW HEATING CONNECTION
20
SEAL RING PNEUMATIC VALVE
20
SEAL RING , Replaced By: N007603010110
22
SEAL RING LINE CONNECTION
24
SCREW BATTERY BASE FRAME
24
SCREW , Replaced By: A3855400226, +001A3855410340, +001N006799009003
26
BRACKET
28
LOCK PLATE
30
ELECTRIC CABLE FROM BATTERY POS.POLE TO STARTING MOTOR 70 MM2, ORDER BY THE METER
30
ELECTRIC CABLE , Replaced By: A6735460013
30
ELECTRIC CABLE , Replaced By: N922002070000
32
SOLDERING TERMINAL BATTERY POS. POLE 70 MM2
34
SOLDERING TERMINAL BATTERY NEG. POLE 70 MM2
36
NEG. CABLE FROM BATTERY TO BATTERY MASTER SWITCH
38
POSITIVE CABLE FROM BATTERY POS. POLE TO BATTERY MASTER SWITCH
42
POSITIVE CABLE FROM BATTERY MASTER SWITCH TO STARTING MOTOR,5 129699
42
POSITIVE CABLE FROM BATTERY MASTER SWITCH TO STARTING MOTOR,4 4363025 129698
42
POSITIVE CABLE FROM BATTERY MASTER SWITCH TO STARTING MOTOR,4 687173
42
POSITIVE CABLE FROM BATTERY MASTER SWITCH TO STARTING MOTOR,4 4363024 687172
48
NEG. CABLE FROM BATTERY MASTER SWITCH TO SIDE MEMBER
52
GROMMET BATTERY CABLES THRU BATTERY CASE
60
PIN BUSHING HOUSING UNIPOLAR
62
ELECTRIC CABLE FROM CHASSIS/CAB CONNECTION POINT TO SWITCH,4 483783
64
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
70
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
74
PIN BUSHING HOUSING UNIPOLAR
79
PIN BUSHING HOUSING UNIPOLAR
84
TRAY BATTERY MASTER SWITCH
87
SHELL BATTERY CASE,4 436302
91
GASKET BATTERY MASTER SWITCH
99
SHIM BATTERY MASTER SWITCH
101
LOOM TIE LINE MOUNTING
103
SCREW , Replaced By: N304017008016
103
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
108
WASHER , Replaced By: N000125008443
108
WASHER EXHAUST MUFFLER TO STRAP
113
SCREW , Replaced By: N000933006226
113
SCREW HOUSING TO PLATE
118
SWITCH (BATTERY MASTER SWITCH),4 475437
118
SWITCH (BATTERY MASTER SWITCH),4 4754384 695240
121
SCREW , Replaced By: N304017008021
121
SCREW PIPE CLAMP
125
NUT
129
WASHER , Replaced By: N000125008443
129
WASHER EXHAUST MUFFLER TO STRAP
133
GASKET FROM BATTERY CHANGE-OVER SWITCH TO BATTERY SUPPORT
137
DIODE RELAY
137
DIODE CASE AUXILIARY HEATER
138
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
139
NUT TWO-WAY VALVE TO BRACKET
141
CURRENT LIMITER , Replaced By: A0025450334
141
CURRENT LIMITER , Replaced By: A0015455434
141
CURRENT LIMITER TACHOGRAPH,5 584018
143
SCREW FUSE,4 739894
148
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
151
WASHER , Replaced By: N000125004319
151
WASHER BRACKET TO SUPPORT
154
NUT SUR BOITIER D'INTERRUPTEUR PRINCIPAL DE BATTERIE
154
SCREW CONNECTION BATTERY MASTER SWITCH
162
BRACKET , Replaced By: A3812950440
162
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
162
BRACKET WITH STABILIZER ROD TO FRAME
163
BRACKET , Replaced By: A3184280240
163
BRACKET LINE MOUNTING
164
BRACKET , Replaced By: A6205242940
164
BRACKET FENDER
166
SCREW , Replaced By: N304017008021
166
SCREW PIPE CLAMP
167
NUT , Replaced By: N913004008001
167
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
170
CLAMPING PIECE , Replaced By: A6205460244
170
CLAMPING PIECE BATTERY CABLE MOUNTING
173
SCREW DISTRIBUTOR TO CAB
176
NUT CLAMPING PIECE TO BRACKET
179
WASHER , Replaced By: N009021006208
179
WASHER COMPRESSED AIR LINE TO BRACKET
184
TAIL LAMP , Replaced By: A0015446903
184
TAIL LAMP , Replaced By: A0025440303
184
TAIL LAMP , Replaced By: A0025440303
184
TAIL LAMP , Replaced By: A0015446803
184
TAIL LAMP , Replaced By: A0025440403
184
TAIL LAMP , Replaced By: A0025440403
184
TAIL LAMP , Replaced By: A0015447003
184
TAIL LAMP , Replaced By: A0025440203
184
TAIL LAMP LEFT "HELLA"
184
TAIL LAMP LEFT "R & S"
184
TAIL LAMP , Replaced By: A0015447103
184
TAIL LAMP RIGHT "HELLA"
184
TAIL LAMP RIGHT "R & S"
186
LENS''HELLA''
186
LENS''R&S''
188
GASKETHELLA
188
GASKETR&S
190
BULB , Replaced By: N072601024192
190
BULB TAIL LAMP 21 W
192
BULB , Replaced By: N072601024704
192
BULB WITH REINFORCED COILED FILAMENT 24 V/10 W
194
ELECTRIC CABLE , Replaced By: A6175400107
194
CABLE HARNESS , Replaced By: A6175400207
194
CABLE HARNESS , Replaced By: A6175401507
194
CABLE HARNESS TAIL LAMP
194
ELECTRIC CABLE , Replaced By: A6175400307
194
CABLE HARNESS RIGHT TAIL LAMP
194
CABLE HARNESS , Replaced By: A6215402207
196
COVERING AT TAIL LAMP
196
COVERING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 351169, Replaced By: A6195400180
198
VALVE BATTERY MASTER SWITCH ACTUATION
198
VALVE CABLE HARNESS MOUNTING
200
WARNING LAMPPLASTMA
200
EMERGENCY LANTERNPLASTMA, Replaced By: A6285830153
200
EMERGENCY LANTERN , Replaced By: A0005833353
200
EMERGENCY LANTERN , Replaced By: A0005833353
202
PIN BUSHING HOUSING UNIPOLAR
204
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
206
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
208
PIN BUSHING HOUSING UNIPOLAR
999
PIN BUSHING , Replaced By: A0075458226
999
BATTERY12V/88AH
999
EDGE GUARD SECTION , ORDER BY THE METER
999
BATTERY , Replaced By: A0025414101
999
BATTERY , Replaced By: A0025411701
999
BATTERY , Replaced By: A0045411501
999
GROMMET OIL DELIVERY LINE THRU FENDER SUPPORT
999
BATTERY , Replaced By: A0045413101
999
BATTERY12V/88AH, Replaced By: A0009823808
999
SOCKET. PIN BUSHING LESS DETENT,BUT WITH CATCH FOR HOUSING 2,5 MM2
999
POSITIVE CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013100
999
GROUND STRAP FROM BATTERY I TO BATTERY II
999
POSITIVE CABLE , Replaced By: N072551070880, +001N072332013100, +001N072332013200
999
BRACKET
999
POSITIVE CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013100
999
NEG. CABLE
999
NEG. CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013200
999
NEG. CABLE , Replaced By: N072551070880, +001N046234010007, +001N072332013200
999
POSITIVE CABLE , Replaced By: N072551070880, +001N072332013100, +001N072332013200
999
SUPPORT BATTERY
999
BRACKET BATTERY MOUNTING
999
CLAMPING PIECE BATTERY CABLE AND CABLE HARNESS TO SIDE MEMBER
999
BRACKET BATTERY CABLE FIXTURE TO FRAME SIDE MEMBER,4 687173
999
GROMMET TO PLUG THE OPENING FOR CABLE AT BATTERY CASE
999
GROMMET JUNCTION BOX BRANCH-OFF
999
GROMMET
