Поз.
Артикул
Описание
1
FUEL TANK
1
FUEL TANK , Replaced By: A3094702801
2
FUEL STRAINER AT TANK
2
FUEL STRAINER AT TANK
2
FUEL STRAINER FUEL TANK
7
SEAL RING FUEL STRAINER SCREEN
8
SEAL RING FUEL STRAINER SCREEN
9
SENDER UNIT FUEL TANK
11
GASKET SENDER UNIT AND COVER TO FUEL TANK
11
GASKET FUEL GAUGE SENDER UNIT TO FUEL TANK
12
SEAL RING SENDER UNIT AND COVER TO FUEL TANK
13
NUT TACHOGRAPH TO BRACKET
15
HOSE FUEL TANK
18
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
18
PLASTIC TUBE , Replaced By: A0089975482
18
HOSE , Replaced By: A0089975582
19
CLAMP , 009094
20
FILLER NECK , 009094
21
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
21
SCREW , Replaced By: N304017008016
24
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
26
FILLER CAP FUEL TANK
26
FILLER CAP , Replaced By: A0004715130
26
FILLER CAP , Replaced By: A0004715130
28
GASKET , Replaced By: A1104710280
28
GASKET
29
SHIM SUPPORT TO SIDE MEMBER
30
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
31
SCREW END PIECE TO EXHAUST PIPE M 10X25
35
STRAP FUEL TANK TO SUPPORT
36
RUBBER STRIP SUPPORT TO SIDE MEMBER
37
NUT , Replaced By: N304032010002
37
NUT
39
LINE FROM FUEL TANK TO "T" CONNECTION FITTING
40
LINE FROM FUEL TANK TO "T" CONNECTION FITTING,303382
40
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
41
UNION NUT
42
RISING PIPE , PRIOR TO INSTALLATION,SHORTEN RISING PIPE TO 323 MM IN LENGTH
43
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
44
SEAL RING CONNECTION: 1,4 719029
46
LINE , Replaced By: A3094702665, +001A0004290801, +001A0004295235, +002A0009971190
46
LINE FROM FUEL TANK TO "T" CONNECTION FITTING
47
LINE , Replaced By: A3094702765, +001A0004290801, +001A0004295235, +002A0009971190
47
LINE FROM FUEL TANK TO HEATER 1000 MM
48
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
49
FIXING CLAMP. CLAMP ,845437
50
HOSE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER 8 X 14 MM, ORDER BY THE METER4 940458
51
SCREW COVER PLATE TO BRACKET
52
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
52
CLAMP , Replaced By: N916017011001
52
CLAMP , Replaced By: N000000000665
53
RISING PIPE , Replaced By: A3094700126
53
RISING PIPE , PRIOR TO INSTALLATION,SHORTEN RISING PIPE TO 323 MM IN LENGTH
54
SEAL RING CONNECTION: 1,4 719029
56
PROTECTIVE PLATE FUEL SYSTEM, UP TO CHASSIS 017560,FROM CHASSIS 017561 SEE SA 19943
57
SCREW , Replaced By: N304017008016
57
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
58
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
59
WASHER , Replaced By: N000125008443
59
WASHER EXHAUST MUFFLER TO STRAP
60
BRACKET FUEL SYSTEM, UP TO CHASSIS 019356,FROM CHASSIS SEE SA 19967
61
SCREW END PIECE TO EXHAUST PIPE M 10X25
62
NUT AIR CLEANER ELEMENT
65
PROTECTIVE PLATE FUEL SYSTEM, UP TO CHASSIS 019356,FROM CHASSIS SEE SA 19967
65
PROTECTIVE PLATE FUEL SYSTEM, UP TO CHASSIS 019356,FROM CHASSIS SEE SA 19967
68
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
68
SCREW , Replaced By: N304017008016
69
NUT , Replaced By: N913004008001
70
TAPPING SCREW FUEL SYSTEM, UP TO CHASSIS 019356,FROM CHASSIS SEE SA 19967
72
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
78
LINE FROM DISTRIBUTOR TO VALVE 3200 MM
78
LINE FROM BRAKE BOOSTER ASSEMBLY TO BRAKE HOSE ON REAR AXLE
79
CLAMP LINE TO CROSS MEMBER,HB746633JB783613
81
GROUND STRAP FROM STARTING MOTOR TO SIDE MEMBER,5 193595
82
BRACKET HORN
85
SCREW END PIECE TO EXHAUST PIPE M 10X25
88
NUT AIR CLEANER ELEMENT
999
LOOM TIE , Replaced By: N916017011000
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SENDER UNIT ,303382
999
SEAL RING
999
PROTECTIVE PLATE PROPELLER SHAFT
999
LINE , Replaced By: A3404204329
999
SUPPORT TANK SUSPENSION
999
LINE
999
SUPPORT , 009094
999
SUPPORT ,349454, Replaced By: A3094703242, +001A1089900340, +001N009021008205
999
FUEL TANK , Replaced By: A3094702801
999
LINE , Replaced By: A3094702765, +001A0004290801, +001A0004295235, +002A0009971190
999
SPACER TUBE FUEL TANK TO CONSOLE, 000918-029081
999
SHIM CONSOLE TO SIDE MEMBER, FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 245436
999
LINE , Replaced By: A3094702665, +001A0004295235, +001A3404705665, +002A0009971190, +001N915001006002
999
WASHER
999
BOOT , Replaced By: A1119900340, +001N000933008153
999
FILLER CAP , Replaced By: A0004716330
999
CLAMP , Replaced By: N916016008200
999
NUT , Replaced By: N913002006009
999
NUT OIL TANK TO BRACKET
999
SEAL CONEB6
