Поз.
Артикул
Описание
136
PLASTIC PIPE RISING PIPE 4X6 MM
136
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
140
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
140
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
140
BANJO UNION , Replaced By: N915052004006
144
UNION NUT
148
SEAL CONE
148
GLAND , Replaced By: A0019901667
152
SLEEVE LEAK LINE
152
BUSHING , Replaced By: N915062004000
156
FITTING LINE CONNECTION TO FIRE WALL,5 726664
156
FITTING , Replaced By: N915059004000
160
T-FITTING. FITTING AT INJECTION PUMP
164
HOLLOW SCREW LINE CONNECTION
168
SEAL RING LINE CONNECTION
172
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
172
LINE , Replaced By: A0004296201
176
UNION NUT
180
SEAL CONE
180
GLAND , Replaced By: A0019901667
184
TS DOUBLE FITTING SOLENOID VALVE
184
FITTING , Replaced By: A0029906071
184
FITTING , Replaced By: A0039979072
188
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
188
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
192
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
196
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
200
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
204
BRACKET REAR AXLE II
208
FITTING FROM PUMP TO CYLINDER
208
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
208
FITTING , Replaced By: A0019909871
212
HOSE ,4 195522
212
HOSE , Replaced By: N071435006002
216
UNION NUT
220
SEAL CONE
220
GLAND , Replaced By: A0019901667
285
FITTING DELIVERY LINE TO PUMP
286
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
287
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
288
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
288
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
504
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
504
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
504
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
504
BRACKET , Replaced By: A3812950440
508
SCREW PIPE CLAMP
508
SCREW , Replaced By: N304017008021
508
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
508
SCREW , Replaced By: A0099900101
508
SCREW , Replaced By: N000933008337
512
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
512
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
512
NUT , Replaced By: N913004008001
536
VALVE 3/2-WAY VOSS
536
VALVE 3/2-WAY KNORR
536
VALVE 3/2-WAY BOSCH
536
VALVE 3/2-WAY WABCO
537
SPRING INSIDE WABCO
538
SEAL RING INSIDE WABCO
539
SEAL RING TOP WABCO
540
WASHER 3/2-WAY VALVE TO BRACKET
544
UNIT IDENTIFICATION PLATE AT TWO-WAY VALVE
548
UNIT IDENTIFICATION PLATE LONGITUDINAL DIFFERENTIAL LOCK
552
NUT 4/3-WAY VALVE TO SUBSTRUCTURE
556
HOLLOW SCREW LINE CONNECTION
560
SEAL RING PNEUMATIC VALVE
560
SEAL RING , Replaced By: N007603010110
588
CLAMP LINE MOUNTING
592
SCREW COVER PLATE TO BRACKET
596
NUT PUMP TO BRACKET
596
NUT , Replaced By: N913004006001
600
ANGLE LINE MOUNTING
600
ANGLE , Replaced By: A3604280243
602
CLAMP LINE MOUNTING
604
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
604
WASHER , Replaced By: N000433013010
620
BRACKET BRACKET TO TRANSMISSION
624
SCREW CLUTCH TO FLYWHEEL
628
SPACER RING BRACKET TO REAR AXLE HOUSING,5 244591
999
BLEEDER VALVE , 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
PIN
999
GASKETTO 003 429 22 44
999
SEAL RINGTO 000 429 75 30
999
VALVE CONEBOSCH
999
COVERTO 000 429 48 30
999
BRAKE LINE COUPLING , Replaced By: A0004297530
999
BRAKE LINE COUPLING AT REAR CROSS MENBER
999
BRAKE LINE COUPLING AT REAR CROSS MENBER
999
REPAIR KITKNORR
999
VALVE LOAD/NO-LOAD, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
PISTONVOSS
999
COVERTO 000 429 16 30,BOSCH
999
SPRING CAPSULETO 000 429 16 30
999
NUTTO 000 429 16 30
999
VALVE PARTTO 000 429 16 30
999
VALVE TAPPETTO 000 429 16 30
999
VALVE DISCTO 000 429 48 30
999
WICK PARTS KIT TO 000 431 26 15,WEST 432 199 030 0
999
SPRINGTO 000 429 16 30
999
REPAIR KITWABCO
999
BRACKET LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
PLUG TWO-CIRCUIT BRAKE VALVE,CONNECTIONS: "21,22", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
BRACKET LINE MOUNTING,4 4389724 691315
999
BRACKET , Replaced By: A6205243040
999
BRACKET METAL SPRING BELLOWS
999
BRACKET LINE MOUNTING,4 4389724 691315
999
SCREW , Replaced By: N304017006026
