Поз.
Артикул
Описание
5
RADIATOR OIL COOLER
7
SCREW BRACKET TO BATTERY/APPARATUS SUPPORT
8
SPRING WASHER SHIFTING CYLINDER TO YOKE
94
TANK CAB,FRONT,5 129373
94
TANK ,5 129372, Replaced By: A6205000349, +001A6205012882, +001N916017020000
97
RADIATOR CAP
100
DRAIN PIPE
103
HOSE OVERFLOW
103
HOSE , Replaced By: A0139978682
106
BRACKET EXPANSION TANK,LEFT
109
BRACKET EXPANSION TANK,RIGHT
112
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
115
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
118
STRAP EXPANSION TANK,LEFT
121
STRAP EXPANSION TANK,RIGHT
124
SHIM EXPANSION TANK,LEFT
127
SHIM EXPANSION TANK,RIGHT
130
SCREW CLAMP MOUNTING M 6X16
130
SCREW , Replaced By: N000000001146
133
WASHER , Replaced By: N009021006208
136
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
137
OIL PIPE. LINE RETURN LINE TO TRANSMISSION
137
OIL PIPE. LINE RETURN LINE TO TRANSMISSION
137
OIL PIPE. LINE RETURN LINE TO TRANSMISSION
138
UNION NUT FEED LINE
139
SEAL CONE LINE MOUNTING
140
NUT. UNION NUT LINE CONNECTION
141
CUTTING RING. GLAND LINE CONNECTION
142
HOSE FROM OIL COOLER TO TRANSMISSION
143
BRACKET OIL LINES
144
CLAMP LINE MOUNTING
145
SCREW AT FILTER BRACKET
145
SCREW COVER PLATE TO BRACKET
146
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
147
BRACKET LINE TO REAR TRANSMISSION CASE,5 537500
147
BRACKET , Replaced By: A6204660940
148
BRACKET OIL LINE MOUNTING
149
CLAMP LINE MOUNTING
150
SCREW AT FILTER BRACKET
150
SCREW COVER PLATE TO BRACKET
151
NUT AT FILTER BRACKET
151
NUT , Replaced By: N913004006001
152
SEAL RING FUEL LINE TO FEED PUMP
153
SCREW-IN FITTING LINE CONNECTION TO TRANSMISSION
