Поз.
Артикул
Описание
432
HOSE FUEL LINE, ORDER BY THE METER
435
TS DOUBLE FITTING (PARTS KIT),LINE RUPTURE 4MM
438
PLASTIC PIPE RISING PIPE 4X6 MM
438
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
441
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
444
UNION NUT
447
GLAND , Replaced By: A0019901667
450
SLEEVE LEAK LINE
459
HOSE , Replaced By: A0009872827
459
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
462
FITTING (PARTS KIT),LINE RUPTURE
465
COUPLING COMPRESSED-AIR-LINE PLUG-CONNECTION
468
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
471
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
474
CONNECTOR DISTRIBUTOR OUTPUT, COMPRESSED AIR LINE PLUG CONNECTION
477
CONNECTOR DISTRIBUTOR TO CAB
480
SEAL RING
483
SCREW CONNECTOR TO CAB
483
SCREW EXHAUST BRAKE SEPARATION POINT
486
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
486
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
486
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
486
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
486
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
489
HOLLOW SCREW HEATING CONNECTION
489
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
489
HOLLOW SCREW LINE CONNECTION
492
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
495
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
495
SEAL RING LINE CONNECTION
495
SEAL RING LINE CONNECTION
495
SEAL RING
498
CONNECTOR HOSE WIDTH, 9 MM,TO M 22
498
CONNECTOR , Replaced By: A0029905378
501
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
504
SEAL RING
507
CONNECTOR
510
CONNECTOR
513
CONNECTOR DISTRIBUTOR OUTPUT, COMPRESSED AIR LINE PLUG CONNECTION
516
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION TO 008 997 90 82
519
CONNECTOR DISTRIBUTOR TO FRAME
519
CONNECTOR , Replaced By: A0019903978
522
SEAL RING CONNECTOR 11.8X2 MM
522
SEAL RING , Replaced By: A0229973948
531
SCREW , Replaced By: N910105006005
531
SCREW CONNECTOR TO TRANSMISSION
534
BREATHER , Replaced By: A3933280065
534
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
537
LOOM TIE LINE MOUNTING
537
LOOM TIE LINE MOUNTING 280 MM
999
SCREW , Replaced By: N000000001441
999
SCREW BRACKET TO FRAME M 10X45
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
