Поз.
Артикул
Описание
552
CYLINDER QUANTITY REDUCTION CONTROL,442-486390
552
CYLINDER (POWER CYLINDER)
552
CYLINDER INTERMEDIATE SPEED STOP
552
CYLINDER (POWER CYLINDER)
554
REPAIR KIT POWER CYLINDER
570
BRACKET , Replaced By: A4230700140
570
BRACKET CYLINDER
570
BRACKET CYLINDER
570
BRACKET CYLINDER
570
BRACKET CYLINDER
572
WASHER BRACKET TO INJECTION PUMP
573
PLATE
617
SCREW BRACKET TO INJECTION PUMP
617
SCREW BRACKET TO INJECTION PUMP
617
SCREW BRACKET TO INJECTION PUMP M 10X76
617
SCREW , Replaced By: A4429905901
617
SCREW , Replaced By: N304014010023
617
SCREW SUPPORT TO SIDE MEMBER M 10X75,B 884220
632
PIN POWER CYLINDER TO BRACKET
632
PIN STRAP TO BRACKET
636
NUT POWER CYLINDER TO BRACKET
636
NUT POWER CYLINDER TO BRACKET
638
WASHER , Replaced By: N000125008443
638
WASHER EXHAUST MUFFLER TO STRAP
642
SCREW CLAMP TO BATTERY CASE
644
SCREW OIL PIPE TO SLEEVE VALVE
646
WASHER COMPRESSED AIR LINE TO BRACKET
646
WASHER COVERING TO CAB
646
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
648
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
648
COTTER PIN PULL ROD TO SHIFT LEVER
648
COTTER PIN
648
COTTER PIN LEVER TO ROD
648
COTTER PIN PULL ROD TO LEVER
652
PIN POWER CYLINDER TO BRACKET TO 000 430 48 26,49 26
652
PIN STRAP TO BRACKET
664
WASHER BRACKET TO CROSS MEMBER
664
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
664
WASHER EXHAUST MUFFLER TO STRAP
664
WASHER , Replaced By: N000125008443
666
FITTED WASHER
666
FITTED WASHER POWER CYLINDER
668
COTTER PIN PULL ROD TO SHIFT LEVER
670
SPACER TUBE CYLINDER TO PLATE
672
SCREW FRONT AXLE REGULATING SOLENOID VALVE
672
SCREW , Replaced By: N000933008134
674
WASHER , Replaced By: N000125008443
674
WASHER EXHAUST MUFFLER TO STRAP
676
NUT , Replaced By: N913004008001
676
NUT SWITCH TO FLOOR PLATE
696
THREADED UNION CYLINDER TO LEVER
712
NUT POWER CYLINDER TO LOCKING LEVER
712
NUT
712
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
712
NUT , Replaced By: A0009900851
728
ROD END , FIRST EXHAUST STOCK OF OLD PARTS UP TO ENGINE 393453YEAR OF MANUFACTURE 1995, Replaced By: A0019960340
728
ROD END
744
SPACER TUBE CYLINDER TO LEVER, NOT USED
744
SPACER TUBE REFRIGERANT LINE TO CAB
746
SPACER RING MANUAL FINE CONTROL TO GOVERNOR HOUSING
760
SCREW DELIVERY AND SUCTION LINES TO ENGINE, FRONT M 6X35
760
SCREW LICENSE PLATE TO BRACKET
760
SCREW CLAMPING PIECE TO BRACKET
760
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
760
SCREW , Replaced By: N304017006020
760
SCREW , Replaced By: N000000001479
765
NUT , Replaced By: N913002006009
765
NUT OIL TANK TO BRACKET
765
NUT BALL PIVOT TO LEVER
770
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
806
LEVER MINOR QUANTITY STOP
810
SCREW MINOR QUANTITY STOP
837
SCREW STEERING SUPPORT TO FRAME M 10X75
837
SCREW , Replaced By: A4429905901
837
SCREW , Replaced By: N304014010023
837
SCREW , Replaced By: N304014010015
837
SCREW
837
SCREW DUMPER SHAFT,5 515436
837
SCREW BRACKET TO INJECTION PUMP
837
SCREW REAR EXHAUST PIPE TO MUFFLER
837
SCREW BRACKET TO INJECTION PUMP M 10X76
837
SCREW POWER STEERING PUMP TO BEARING FLANGE M 10X150, TO 699 466 02 01
865
BRACKET ,447-037488
867
BALL PIVOT
867
BALL PIVOT
868
BALL PIVOT ,556500
870
BRACKET ,447-037488
872
BALL PIVOT ,556500
874
DASHPOT
874
DASHPOT , Replaced By: A4470700167
879
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
880
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
880
FITTING , Replaced By: A0009977172
882
HEXAGON NUT. NUT BRACKET TO SIDE MEMBER M 12X1,5
882
NUT BRACKET TO SIDE MEMBER M12X1.5
884
WASHER
886
GLAND BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
888
UNION NUT LINE CONNECTIONS
890
SLEEVE LEAK LINE
892
CLAMP SENSOR CABLE TO BRACKET
892
CLAMP CABLE HARNESS MOUNTING
892
CLAMP , Replaced By: N916016010211
892
CLAMP , Replaced By: N000000001045
896
SCREW BRACKET ON LOAD SENSOR
898
NUT BALL PIVOT TO LEVER
900
LOOM TIE LINE MOUNTING 280 MM
900
LOOM TIE , Replaced By: A0019978390
999
STOP INTERMEDIATE SPEED STOP
999
STOP INTERMEDIATE SPEED STOP
999
CYLINDER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 051317, Replaced By: A0000701583
999
CYLINDER , Replaced By: A0000701983, +001A4410721740, +001A4412230641
999
CYLINDER , Replaced By: A0000723212
999
REGULATING UNIT , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 258570/92, Replaced By: A0000720265
999
CYLINDER , 364 021703 366 061186, Replaced By: A0000721512, +001A3649910322, +001N900071008100
999
CYLINDER , Replaced By: A0000720612, +001A4030720574
999
CYLINDER , Replaced By: A0000720812
999
CYLINDER , Replaced By: A0004304826
999
CYLINDER INJECTION PUMP CONTROL
999
CYLINDER , Replaced By: A0000721512
999
CYLINDER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0000720512, +001A4420720624
999
CYLINDER , NOT USED
999
CYLINDER (OPERATING CYLINDER)
999
CYLINDER , Replaced By: A0004302326
999
CYLINDER , Replaced By: A0004304926
999
BUSHING , Replaced By: A0004340850
999
BALL SOCKET PULL ROD TO LEVER
999
FITTING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0069971672
999
TUBE GUIDE TUBE TO CYLINDER HEAD
999
BALL PIVOT LEVER
999
LEVER
999
WASHER , Replaced By: N000988008006
999
BUSHING , Replaced By: A4039920001
999
SPACER TUBE , Replaced By: A6673170253
999
CYLINDER
999
CYLINDER , Replaced By: A0000720112
999
SHAFT ,256464, Replaced By: A4220700323, +001A4073015088
999
CYLINDER , Replaced By: A0000720112, +001A4030720324, +001A4039910022, +002N000934006007
999
BEARING BRACKET , Replaced By: A4030702724, +001A4030721250
999
BEARING BRACKET , Replaced By: A4030702624
999
CYLINDER , Replaced By: A0000720412
999
LEVER , Replaced By: A4410700321
999
BEARING BRACKET
999
BEARING BRACKET , Replaced By: A4220701824
999
BEARING BRACKET CONTROL SHAFT,145362,404 001277
999
LEVER , Replaced By: A4030707621
999
LEVER , Replaced By: A4030708321
999
LEVER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 590957, Replaced By: A4420702521
999
LEVER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 590957, Replaced By: A4420702521
999
PIN , Replaced By: A4030720574
999
PIN , Replaced By: A4221440174, +001N999900008004
999
SPACER TUBE
999
SPRING , Replaced By: A4039931010
999
SPRING , Replaced By: A4229930010
999
SHAFT , Replaced By: A4220700323, +001A4073015088
999
BEARING BRACKET , Replaced By: A4220701524
999
SHAFT , Replaced By: A4220700723
999
SHAFT , 402.910 256465 404.901 005579 422.905 047593460461, Replaced By: A4420700323, +001N071803010102, +001N913004006002
999
SHAFT CONTROL
999
LEVER ,608852, Replaced By: A4420703521
999
PIN , Replaced By: A4421440574
999
SPRING , Replaced By: A4429935110
999
BRACKET , Replaced By: A4410700740, +001A4411400540, +006N000125008418, +004N000931008320, +002N000933008151, +002N000934008010, +004N007349008006
999
BRACKET
999
CYLINDER (OPERATING CYLINDER), NOT USED
999
LEVER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4420705921
999
LEVER LOAD CONTROL, TO BE ADAPTED DURING ASSEMBLY
999
LEVER INJECTION PUMP CONTROL
999
BRACKET
999
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 442 513557, Replaced By: A4420722340
999
BRACKET , Replaced By: A4420722840
999
WOODRUFF KEY INJECTION PUMP
999
BALL PIVOT
999
NUT L.H. THREAD
999
PULL ROD FROM REAR CONTROL LEVER TO CONTROL SHAFT 600 MM, TO BE ADAPTED DURING ASSEMBLY
