Поз.
Артикул
Описание
128
VALVE FUEL FILTER
128
VALVE , Replaced By: A0000920610
134
SEAL RINGTO 000 553 03 05,000 553 18 05,
134
SEAL RING INJECTION PUMP
143
SUPPORT MULTI-STAGE FUEL FILTER
152
THREADED INSERT
200
SUPPORT FUEL FILTER
203
SUPPORT FUEL FILTER
209
THREADED INSERT
212
THREADED INSERT ,5 462573
220
SCREW ENGINE SUPPORT TO CYLINDER CRANKCASE M 12X1.5X55
220
SCREW CONSOLE TO FRAME SIDE MEMBER
220
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBERM 12X1.5X30
220
SCREW SUPPORTING ARM TO ENGINE
222
HEXAGON HEAD BOLT BRACKET TO BRACKET
222
SCREW LEFT AND RIGHT CONSOLES TO CAB
222
SCREW CONNECTOR TO REAR SHIFTING ROD
222
SCREW
222
HEXAGON HEAD BOLT , Replaced By: A0029902704
222
SCREW , Replaced By: N304017010002
224
SPRING WASHER STEERING COLUMN BRACKET TO CAB
224
SPRING WASHER CAB FLOOR
236
HEXAGON HEAD BOLT VIBRATION ABSORBER TO BRACKET
236
SCREW AT SHIFT LEVER M 8 X 45,P 234011
236
SCREW BRACKET TO FRAME SIDE MEMBER
236
SCREW , Replaced By: N304017008042
304
SHIM
308
SCREW ENGINE SUPPORT TO CYLINDER CRANKCASE M 12X1.5X55
308
SCREW CONSOLE TO CROSS MEMBER
308
SCREW SUPPORTING ARM TO ENGINE
310
HEXAGON HEAD BOLT BRACKET TO BRACKET
310
SCREW , Replaced By: N304017010002
316
SPRING WASHER CAB FLOOR
316
LOCK WASHER FITTING TO BRACKET
320
SPRING WASHER STEERING COLUMN BRACKET TO CAB
456
BRACKET (INTERMEDIATE PIECE)
462
SCREW (INTERMEDIATE PIECE)
474
SCREW AIR-DEHYDRATOR BRACKET
474
SCREW LEFT AND RIGHT CONSOLES TO CAB
476
LOCK WASHER FITTING TO BRACKET
488
HOSE LEAK LINE, ORDER BY THE METER
488
SCREENING LEAK CONNECTION SEALING AT NOZZLE HOLDER, 314 494961 352 851898 364 022454 366 063371, Replaced By: A0119977782, +002A4030780074
508
SCREENING NOZZLE HOLDER, TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0119977782, +001A4030780074
508
HOSE LEAK LINE, ORDER BY THE METER
608
BRACKET FUEL LINE
614
SCREW CONNECTOR TO REAR SHIFTING ROD
614
HEXAGON HEAD BOLT BRACKET TO BRACKET
614
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB M 14X45
614
HEXAGON HEAD BOLT. SCREW FRONT EXHAUST PIPE TO BRACKET
614
HEXAGON HEAD BOLT BRACKET TO CROSS MEMBER
614
SCREW , Replaced By: N308676012038
614
SCREW , Replaced By: N304017010002
690
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
760
NUT. UNION NUT RETURN
762
FITTING RETURN
763
FITTING HAND PUMP TO FUEL FILTER
763
FITTING FUEL FILTER
768
INTERMEDIATE PIECE AT INJECTION PUMP
776
INTERMEDIATE PIECE RETURN LINE TO INJECTION PUMP
777
BANJO UNION FEED
777
BANJO UNION , Replaced By: N000000000363
780
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
780
NUT
830
HOSE PLASTIC PIPE,K 223529
830
HOSE LEAK LINE, ORDER BY THE METER
830
HOSE , Replaced By: A0119977782
830
HOSE , Replaced By: A0119977782
830
HOSE , Replaced By: A0119977782
830
HOSE , Replaced By: A0119977782
835
CLAMP
836
LOOM TIE LINE MOUNTING
836
LOOM TIE LINE MOUNTING 280 MM
836
CABLE TIE. LOOM TIE1140 X 8.9 MM
836
LOOM TIE , Replaced By: A0069973090
836
LOOM TIE , Replaced By: A0059974390
836
LOOM TIE , Replaced By: A0019978390
836
LOOM TIE , Replaced By: A0019978390
868
CLAMP , Replaced By: N000000001045
868
CLAMP , Replaced By: N916016010211
868
CLAMP LINE MOUNTING
868
CLAMP CABLE HARNESS MOUNTING
868
CLAMP BATTERY CABLE TO CROSS MEMBER
868
CLAMP AT BRACKET
868
CLAMP HEATER-PLUG/SOLENOID-VALVE BRANCH-OFFS TO NOZZLE HOLDER,K 092646
887
HEXAGON NUT. NUT , Replaced By: N913023008002
887
NUT
887
NUT SPRING-LOADED PUSH ROD
888
WASHER EXHAUST MUFFLER TO STRAP
888
WASHER , Replaced By: N000125008443
890
SCREW , Replaced By: N304014008018
890
SCREW VALVE TO TRANSMISSION CASE COVER
890
SCREW CHARGING AIR ELBOW TO TURBOCHARGER
890
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET M 8X95
999
FITTING WATER SEPARATOR
999
COMBINATION BOLT LEFT & RIGHT CHARGE AIR PIPES TO CYLINDER HEAD M 8X93
999
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
999
SCREW SUPPORT TO FENDER
999
SEAL RING SCREW PLUG
999
WASHER
999
WASHER , Replaced By: N007349008007
999
NUT , Replaced By: N304032008006
999
LOCK WASHER BRACKET TO SUPPORTING ARM
999
WASHER , Replaced By: N000125008443
999
LINE , Replaced By: A4470700332
999
LINE FROM FUEL FILTER TO INJECTION PUMP, NOT USED
999
LINE , Replaced By: A4470700432
999
LINE FROM FEED PUMP TO FILTER, NOT USED
999
LINE FROM INJECTION PUMP OVERFLOW VALVE TO RETURN CONNECTION, NOT USED
999
HOLLOW SCREW FUEL LINE LEADING TO FUEL PUMP
999
LINE
999
PLATE LINE MOUNTING,920657
999
FILTER , Replaced By: A4420900452
999
BRACKET , Replaced By: A4220901241
999
LINE FROM FUEL FEED PUMP TO DISTRIBUTOR,062710
999
LINE FROM FUEL FILTER TO INJECTION PUMP
999
LINE FROM INJECTION PUMP OVERFLOW VALVE TO T-FITTING
999
LINE FROM FUEL DISTRIBUTOR TO FEED PUMP
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
999
HOLLOW SCREW FUEL LINES TO SOLENOID VALVE
999
FITTING FUEL LINE TO HAND PUMP
999
CLAMPING PIECE FUEL FILTER TO BRACKET,012710
999
STUD
999
BANJO UNION FUEL LINES AND BREATHING
999
NUT
999
SEPARATOR (WATER SEPARATOR)
999
CLAMPING BRACKET FILTER HOUSING TO PUMP
