Поз.
Артикул
Описание
4
OIL PAN
4
OIL PAN
4
OIL PAN
4
OIL PAN , Replaced By: A4090101413
4
OIL PAN , Replaced By: A4470101313
4
OIL PAN , Replaced By: A4470101213
4
OIL PAN
4
OIL PAN
23
OIL PAN
23
OIL PAN
29
OIL PAN
29
OIL PAN
29
OIL PAN
29
OIL PAN
29
OIL PAN
29
OIL PAN
29
OIL PAN , Replaced By: A4290100413
29
OIL PAN , Replaced By: A4270100813
29
OIL PAN
29
OIL PAN
29
OIL PAN
47
THREADED INSERT REPAIR SIZE, TO BE ADAPTED DURING ASSEMBLY
47
THREADED INSERT
47
THREADED INSERT
51
THREADED INSERT REPAIR PURPOSES M 14X1.5X10.5
59
THREADED INSERT
60
SCREW PLUG , Replaced By: N000908012009
60
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
61
SEAL RING BRAKE POWER REGULATOR,CONNECTION: "41,42",067640
63
SCREW PLUG
64
SEAL RING OIL DRAIN 30X36 MM
87
COVER TO LOCK TURBOCHARGER OIL RETURN LINE CONNECTION
92
GASKET TO LOCK TURBOCHARGER OIL RETURN LINE CONNECTION
92
GASKET , Replaced By: A4470140180
97
SCREW , Replaced By: N304017008016
97
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
102
SEAL RING FUEL LINE TO FEED PUMP
102
SEAL RING VALVE TO VALVE,K 025179
107
SCREW PLUG
107
SCREW PLUG FUEL TANK
107
SCREW PLUG , Replaced By: N007604014110
137
SCREW PLUG , Replaced By: A4039970230
137
SCREW PLUG , Replaced By: A4039970032
137
SCREW PLUG
137
SCREW PLUG
140
SEAL RING OIL DRAIN 26X34 MM
151
GASKET OIL PAN TO CYLINDER CRANKCASE
151
GASKET , Replaced By: A4470140022
151
GASKET , Replaced By: A4490140022
151
GASKET OIL PAN TO CYLINDER CRANKCASE
151
GASKET OIL PAN TO CYLINDER CRANKCASE
161
SCREW BRACKET TO ENGINE
161
SCREW FAN TO CRANKSHAFT PULLEY
161
SCREW INJECTION PUMP DRIVE TO TIMING CASE M 8X140
161
SCREW 3/2-WAY VALVE TO BRACKET M 8X95
161
SCREW BRACKET TO 3/2-WAY VALVE
161
SCREW BRACKET TO ALTERNATOR
161
SCREW , Replaced By: N304017008018
161
SCREW SUPPORT TO FENDER
161
SCREW BRACKET TO INTAKE MANIFOLD M 8X135
161
SCREW BRACKET TO EXHAUST PIPE,5 528482
161
SCREW SUPPORT TO INTAKE PIPE
161
SCREW ANTI-FREEZE PUMP TO BRACKET,950272
179
WASHER EXHAUST MUFFLER TO STRAP
179
SPRING WASHER , Replaced By: N000137008212
179
WASHER , Replaced By: N000125008443
179
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
185
WASHER , Replaced By: N000125008443
185
WASHER EXHAUST MUFFLER TO STRAP
185
WASHER BRACKET TO CROSS MEMBER
195
FLANGE
197
OIL FILLER NECK
203
OIL FILLER NECK
205
GASKET OIL FILLER NECK
205
GASKET , Replaced By: A4420180080
209
GASKET , Replaced By: A4420180080
209
GASKET OIL FILLER NECK
216
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
216
SCREW , Replaced By: N304017008034
216
SCREW , Replaced By: N304017008021
216
SCREW BRACKET TO CROSS CONNECTION STRUT
216
SCREW PIPE CLAMP
220
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
220
SPRING WASHER , Replaced By: N000137008212
236
SEAL RING OIL DRAIN 26X34 MM
239
SCREW PLUG
257
SCREW PLUG , Replaced By: N007604014110
257
SCREW PLUG FUEL TANK
260
SEAL RINGTO 000 553 03 05,000 553 18 05,
282
SCREW PLUGTO 000 553 03 05,000 553 18 05,
282
SCREW PLUG , Replaced By: N007604014110
282
SCREW PLUG , Replaced By: N000908014009
282
SCREW PLUG FUEL TANK
286
SEAL RINGTO 000 553 03 05,000 553 18 05,
286
SEAL RING FROM FUEL TANK TO FUEL TANK
466
FITTING OIL SCAVENGING
999
CLAMP HOSE TO COOLING WATER PIPE
999
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
999
THREADED INSERT ,5 462573
999
SCREW PLUG OIL FILLING
999
SEAL RING OIL LINE TO OIL COOLER
999
SCREW INTAKE MANIFOLD TO CYLINDER HEAD M 8X145
999
COVER OIL PAN
999
OIL PAN , OIL SCAVENGE BORE TO BE LOCKED BY MEANS OF 007603 018101 SEAL RING AND 915048 018000 SCREW PLUG030363 407.913407.907,911
999
FLANGE COOLING WATER FEED LINE LOCK
999
SUCTION PIPE OIL PUMP
999
SUCTION PIPE OIL PUMP
999
HOUSING , 001923-121799
999
OIL PUMP , 001923-121799 TOOTH WIDTH 28 MM PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
GASKET OUTLET TO ENGINE
