Поз.
Артикул
Описание
534
SUPPORT ALTERNATOR,184180
534
SUPPORT ALTERNATOR
620
SUPPORT ALTERNATOR
624
BUSHING
624
BUSHING
636
BRACKET BRACKET TO TIMING CASE
637
SCREW STRUT TO CROSS MEMBER M 10X25
637
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
638
SPRING WASHER STEERING COLUMN BRACKET TO CAB
639
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
639
NUT , Replaced By: N913023010002
640
SCREW BRACKET TO TIMING CASE
641
HEXAGON HEAD BOLT. SCREW BRACKET TO TRANSMISSION M 10X50
641
SCREW , Replaced By: N304017010053
641
SCREW , Replaced By: N304017010050
641
SCREW PIPE ELBOW TO BRACKET M 10X50
641
SCREW , Replaced By: N304017010055
642
WASHER SUPPORT TO ALTERNATOR TO 352 150 09 73
643
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
646
SPRING WASHER BRACKET TO TIMING CASE
901
BRACKET ,170750
901
BRACKET ,170749
903
SCREW SOLENOID VALVE TO BRACKET
905
SPRING WASHER BEARING BRACKET TO SIDE MEMBER,4 207081
909
SCREW END PIECE TO EXHAUST PIPE M 12X30
911
NUT BRACKET TO SIDE MEMBER
913
SPRING WASHER CAB FLOOR
917
LEVER ,170750
917
LEVER ,170750
919
TIGHTENER PULLEY , Replaced By: A1161300160, +001A4032020328, +001A4355010035, +001A4355040050, +001A4255040166, +001A0039979240, +001N000610014005
919
PULLEY , Replaced By: A1161300460
925
GROOVED BALL BEARING , Replaced By: A0009816225
925
BALL BEARING , Replaced By: A0019810925, +001A3094100430
927
HUB
929
LOCK STEERING KNUCKLE,TOP AND BOTTOM
929
LOCK RING
945
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
949
SEAL RING
949
SEAL RING ,262440
951
WASHER
953
WASHER
966
SCREW IN CASE OF SUBSEQUENT INSTALLATION
968
SPRING WASHER ALTERNATOR CONNECTION D+
999
SUPPORT
999
WASHER , Replaced By: A3149900940
999
CLAMPING BOLT , Replaced By: A4031500572
999
BRACKET COOLING WATER LINE TO ENGINE
999
ALTERNATOR , Replaced By: A0081547802
999
ALTERNATOR , NOT USED
999
BALL BEARING , Replaced By: A0059812225
999
BALL BEARING
999
REGULATOR AND CUT-OUT , Replaced By: A0021546806
999
REGULATOR AND CUT-OUT , Replaced By: A0021545506
999
SCREW , Replaced By: A0009907621
999
SCREW , Replaced By: A0019902120
999
SCREW , Replaced By: A0009907121
999
DIODE , Replaced By: A0015481518
999
SCREW , Replaced By: A0009907921
999
SCREW , Replaced By: A0009908321
999
SCREW , Replaced By: A0009908221
999
DIODE , Replaced By: A0015481118
999
DIODE , Replaced By: A0005489818
999
DIODE , Replaced By: A0005487918
999
PIPE SOCKET , Replaced By: A4071540165
999
PIPE SOCKET , Replaced By: A4031540365
999
GASKET , Replaced By: A4071540280
999
WASHER
